Ajax Spain Vertical Milling Machine

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Ajax Spain Vertical Milling Machine Specification

Rotation
Clockwise & Counterclockwise

Model
Ajax Spain

Product Type
Vertical Milling Machine

General Use
Industrial Milling Operations

Material
Cast Iron

Type
Vertical

Capacity
High

Weight (kg)
1100 kg

Computerized
No

Automatic
No

CNC Or Not
Not CNC

Control System
Manual

Table Size
600 mm x 180 mm

Table Slide Way
V & Flat Slideway

Magnetic Chuck Size
300 mm x 150 mm

Grinding Wheel Size
200 mm x 20 mm x 31.75 mm

Grinding Wheel Speed
2800 RPM

Grinding Length
400 mm

Floor Space
1600 mm x 1200 mm

Fuel Tank Capacity
40 Litres

Spindle Speed
Variable

Power
2.2 kW

Voltage
415 V

Dimension (L*W*H)
1600 mm x 1200 mm x 1700 mm

Feature
Rigid Construction, High Precision

Color
Blue & White

Ajax Spain Vertical Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Ajax Spain Vertical Milling Machine

Make - Ajax (Spain)

Model - AJT-1

Table Size - 1270 mm x 255 mm

Longitudinal Travel - 710 mm (Motorized)

Cross Travel - 360 mm

Spindle Speeds - 48 rpm to 3750 rpm

Spindle Feed Travel - 127 mm

Spindle Taper - ISO 40

Spindle Diameter - 85 mm

Spindle Feed Rates - 0.04 mm/revolution to 0.16 mm/revolution

- Automatic Motorized Feed & Rapid Movements in Longitudinal Travel.

- Equipped with a 3-Axis DRO.

- Machine is in excellent working condition.

Vidoe of The Machine -

https://youtu.be/1h8I4L_fJKQ

Designed for Industrial Precision

Engineered for high-precision milling, this vertical machine is ideally suited for industrial operations requiring accuracy and reliability. With a grinding length of 400 mm and a spindle-to-table distance of up to 450 mm, the Ajax Spain model supports a variety of complex tasks. Its sturdy cast iron design and automatic lubrication system ensure smooth and consistent performance during prolonged use.

User-Friendly Operation and Versatility

The Ajax Spain Vertical Milling Machine operates via a manual control system, making it easy to adjust spindle speeds and table feeds as needed. The integrated coolant system, variable spindle rotation, and wide range of optional accessories, such as a digital readout and power feed, deliver versatility for different milling and grinding operations.

Comprehensive Standard and Optional Accessories

This machine is supplied with essential accessories like a vice, wrenches, and a user manual for stress-free setup and usage. Optional upgrades, including a digital readout and power feed, further expand its capability, allowing for improved measurement accuracy and automation in select processes.

FAQs of Ajax Spain Vertical Milling Machine:

Q: How is the Ajax Spain Vertical Milling Machine operated?

A: The machine is manually operated, with all movements and settings controlled directly by the operator. It does not feature CNC capabilities, ensuring hands-on precision and ease of adjustment during industrial milling tasks.

Q: What materials can be processed using this machine?

A: Designed with robustness in mind, the Ajax Spain Vertical Milling Machine is suitable for machining a wide range of materials typically encountered in industrial environments, especially metals, owing to its rigid cast iron construction.

Q: When should the integrated coolant system be used?

A: The integrated coolant system should be engaged whenever performing milling or grinding operations that generate significant heat. This helps maintain workpiece integrity, ensures dimensional stability, and prolongs both tool and machine life.

Q: Where can the Ajax Spain Vertical Milling Machine be installed?

A: This machine requires a floor space of 1600 mm x 1200 mm and is compatible with three-phase, 415 V industrial electrical systems, making it best suited for factory floors, workshops, and other industrial settings.

Q: What are the benefits of the automatic lubrication system?

A: The automatic lubrication system keeps all moving parts well-oiled, minimizing wear and tear. This feature is essential for maintaining long-term accuracy and reliability, reducing maintenance requirements, and enhancing operational longevity.

Q: How can the machines performance be enhanced?

A: Performance can be optimized by utilizing available optional accessories such as a digital readout for precise measurement and a power feed for automated table movement, thereby increasing accuracy and efficiency during complex milling operations.

Q: What makes the Ajax Spain Vertical Milling Machine suitable for industrial use?

A: With high load capacity, variable spindle speeds, a rugged cast iron body, automatic lubrication, and an integrated coolant system, this model provides the precision, durability, and reliability required for continuous industrial milling and grinding processes.
