Anselmi Manofap Lathe Machine

Get a Price/Quote

MOQ : 1 Piece

Anselmi Manofap Lathe Machine Specification

Product Type
Manual Precision Lathe Machine

Material
Cast Iron Body with Hardened Steel Bed

Cutting Thickness
Up to 30 mm

Cutting Speed
40-1500 RPM Variable

CNC Or Not
Not CNC (Manual Operation)

Automatic Grade
Manual

Control System
Manual Handwheel & Lever

Max. Swing Diameter
360 mm

Voltage
415V, 3-Phase

Weight (kg)
780 kg

Dimension (L*W*H)
1680 mm x 600 mm x 1200 mm

Capacity
Variable based on operation (Light to Medium Duty)

Feature
High Accuracy, Rigid Construction, Efficient Chip Removal

Color
Grey-Green

Lead Screw Diameter
35 mm

Spindle Bore
52 mm

Distance Between Centers
1000 mm

Main Motor Power
3 HP

Application
Metal Turning, Facing, Drilling, Thread Cutting

Chuck Size
200 mm

Tailstock Travel
200 mm

Bed Type
Hardened & Ground

Coolant Pump
Included

About Anselmi Manofap Lathe Machine

Make - Antonio-Anselmi (Italy)

Model - ManoFap 325 EA

Center Height - 335 mm

Max. Length of Job - 1500 mm

Max. Diameter of Job over Bed - 670 mm

Max. Diameter of Job over Cross-Slide - 430 mm

Bed Width - 440 mm

Spindle Speeds - 10 rpm to 1000 rpm

Spindle Bore - 65 mm

Chuck Diameter - 350 mm

Max. Diameter of Job over Gap-Bed - 850 mm

- Equipped with 2-Axis D.R.O.

- Machine is in excellent working condition.

video link - https://youtu.be/pVnXkiUdzrE

Precision and Performance

Designed with a hardened steel bed and cast iron construction, this lathe machine excels in delivering consistent high-accuracy results. It manages a maximum swing diameter of 360 mm and a cutting thickness up to 30 mm, ideal for a diverse range of metal machining tasks. The variable speed system broadens its flexibility for various materials and operations.

Versatile Applications

The Anselmi Manofap Lathe Machine adapts seamlessly to metal turning, facing, drilling, and thread cutting. Its 1000 mm distance between centers and 52 mm spindle bore make it suitable for a range of workpiece sizes. Whether for repair shops or manufacturing setups, its capabilities meet both light and medium-duty needs.

Durability and Efficiency

Constructed with a rigid, grey-green cast iron body and hardened & ground bed, this lathe is built to endure heavy usage. The inclusion of a coolant pump and efficient chip removal maintain smooth, uninterrupted operations and prolong tool life. Its 3-phase, 415V operation ensures stable performance in industrial environments.

FAQs of Anselmi Manofap Lathe Machine:

Q: How do I operate the Anselmi Manofap Lathe Machine for different metalworking applications?

A: Operation is entirely manual, using the provided handwheel and levers. The variable cutting speed (40-1500 RPM) allows you to adapt the machine for tasks like turning, facing, drilling, or thread cutting by adjusting speed and tool positioning accordingly.

Q: What materials can be processed with this lathe machine?

A: The lathe is built for metalworking, suitable for steels and non-ferrous metals. Its rigid cast iron body and hardened steel bed provide the required stability and durability for precise machining of various metals.

Q: When is it appropriate to use this machine for a particular cutting thickness or diameter?

A: This lathe machine can handle cutting thicknesses up to 30 mm and workpieces with a maximum swing diameter of 360 mm. Use these parameters as a guideline to ensure optimal performance without overloading the machine.

Q: Where can the Anselmi Manofap Lathe Machine be installed?

A: Given its dimensions (1680 mm x 600 mm x 1200 mm) and weight (780 kg), its best installed in well-ventilated workshops or industrial facilities with a stable 415V, 3-phase electrical supply. The location should allow easy access for material handling and chip removal.

Q: What is the process for maintaining the machines accuracy and longevity?

A: Regular cleaning after each operation, timely lubrication, and checking alignment are key. Utilize the built-in coolant pump during extended use, and ensure the bed and lead screw are free from chips to maintain smooth, precise operation.

Q: What benefits does the hardened and ground bed provide in this lathe machine?

A: The hardened and ground bed ensures high wear resistance and maintains precise alignment over time, resulting in consistently high-accuracy machining and extended machine service life.
