Ateliers Titan 3000 mm Lathe Machine
Ateliers Titan 3000 mm Lathe Machine

Ateliers Titan 3000 mm Lathe Machine

Price 100000 INR/ Piece

MOQ : 1 Piece

Ateliers Titan 3000 mm Lathe Machine Specification

  • Product Type
  • Heavy Duty Lathe Machine
  • Material
  • Cast Iron Body, Hardened Steel Bed
  • Cutting Thickness
  • Up to 45 mm
  • Cutting Speed
  • 302000 rpm (variable)
  • CNC Or Not
  • Conventional / Manual
  • Automatic Grade
  • Semi-Automatic
  • Control System
  • Manual with Mechanical Controls
  • Max. Swing Diameter
  • 750 mm
  • Voltage
  • 415 V / 3 Phase / 50 Hz
  • Weight (kg)
  • Approx. 3500 kg
  • Dimension (L*W*H)
  • 4700 x 1100 x 1500 mm
  • Capacity
  • 3 ton workload
  • Feature
  • Long bed length, steady rest, rapid traverse
  • Color
  • Industrial Grey / Blue
  • Chuck Size
  • 400 mm
  • Lubrication System
  • Automatic central lubrication
  • Bed Type
  • Hardened bed
  • Coolant Pump
  • Included
  • Spindle Bore
  • 105 mm
  • Tool Post Type
  • Four-way tool post
  • Surface Finish
  • Precision ground ways
  • Number of Speeds
  • 16
  • Distance Between Centers
  • 3000 mm
  • Tailstock Quill Diameter
  • 75 mm
  • Application
  • Turning, Facing, Thread Cutting, Drilling
  • Lead Screw Pitch
  • 6 mm
  • Main Motor Power
  • 7.5 kW


Ateliers Titan 3000 mm Lathe Machine Trade Information

  • Minimum Order Quantity
  • 1 Piece
  • Main Domestic Market
  • All India


About Ateliers Titan 3000 mm Lathe Machine

Make - Ateliers Titan (France)

Center Height - 400 mm

Max. Length of Job - 3000 mm

Max. Job Diameter over Bed - 800 mm

Max. Job Diameter over Cross-Slide - 600 mm

Max. Job Diameter over Gap Bed - 1125 mm

4-Jaw Chuck Diameter - 600 mm

3-Jaw Chuck Diameter - 380 mm

Face Plate Diameter - 1100 mm

Bed Width - 450 mm

Spindle Speeds - 8 rpm to 625 rpm

- Complete with Steady Rest and lots of other accessories etc.

- Machine is in excellent working condition.


Video of The Machine -

https://youtu.be/T5H1btrLA68



Superior Precision and Durability

Built with a hardened steel bed and precision-ground ways, the Titan lathe delivers stable, accurate machining. Its sturdy cast iron construction and robust tailstock ensure minimal vibration, maximizing both safety and finish quality on demanding jobs.


Versatile Performance

With its four-way tool post and 16-speed transmission, the lathe adapts effortlessly to varied machining tasks, from heavy turning to fine thread cutting and drilling. Operators have control over speed and feed to match material and application needs.


Efficient Operation and Maintenance

Automatic central lubrication and rapid traverse features enhance operational efficiency, decrease wear, and simplify maintenance. The included coolant pump reliably supports prolonged machine use, maintaining consistent temperatures and optimal cutting conditions.

FAQs of Ateliers Titan 3000 mm Lathe Machine:


Q: How do I operate the Ateliers Titan 3000 mm Lathe for turning and facing tasks?

A: To operate the lathe, securely mount the workpiece using the 400 mm chuck and adjust the four-way tool post for your chosen cutting tool. Set the desired spindle speed using the manual controls, and select appropriate feed rates based on material and thickness. The machines rapid traverse and steady rest features support smooth, stable turning and facing operations.

Q: What types of materials can be machined using this lathe?

A: This lathe accommodates various metals, including mild steel, alloy steels, cast iron, and hardened materials. The cast iron body and precision-ground, hardened steel bed provide the stability and accuracy required for heavy-duty metalworking.

Q: When should the automatic lubrication system be checked or serviced?

A: Periodic inspection of the automatic central lubrication system is recommended, typically coinciding with routine maintenance checks every few months. Ensure oil levels are adequate and that distribution lines remain unobstructed for consistent machine performance and extended component life.

Q: Where is the Ateliers Titan Lathe best suited for use?

A: The lathe is ideal for industrial workshops, manufacturing plants, and tool rooms where high workloads and larger work pieces require precision and reliable performance. Its substantial capacity and robust design meet the needs of exporters, importers, manufacturers, and suppliers.

Q: What is the process for changing spindle speeds and feed rates?

A: Spindle speeds and feed rates are adjusted manually via the control levers and dials located on the machine panel. Sixteen speed options from 30 to 2000 rpm allow operators to tailor settings as needed for different machining operations and materials, optimizing both efficiency and surface finish.

Q: How does the included coolant pump benefit machining operations?

A: The supplied coolant pump manages heat buildup during cutting, prolonging tool life, reducing thermal distortion, and maintaining a high-quality finish. It enables continuous operation even with tough materials and prolonged jobs, enhancing overall productivity.
