Athena Horizontal Rotary Surface Grinder

Send Inquiry

Request To Call Back

Athena Horizontal Rotary Surface Grinder

Name: Athena Horizontal Rotary Surface Grinder
Brand: Liberty Metal & Machines Private Limited
Price: 2500 INR
Availability: InStock

Price 2500 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Athena Horizontal Rotary Surface Grinder Specification

Model
Athena

Rotation
Horizontal

Product Type
Rotary Surface Grinder

General Use
Industrial Surface Grinding

Material
Cast Iron

Type
Horizontal Rotary Surface Grinder

Capacity
350 mm

Weight (kg)
2300 kg

Computerized
No

Automatic
Semi-Automatic

CNC Or Not
No

Control System
Manual

Table Size
350 mm

Table Slide Way
Hydraulic

Magnetic Chuck Size
350 mm

Grinding Wheel Size
355 mm x 38 mm x 127 mm

Grinding Wheel Speed
1450 RPM

Grinding Length
350 mm

Floor Space
1600 mm x 1100 mm

Fuel Tank Capacity
60 L

Spindle Speed
1450 RPM

Power
5 HP

Voltage
415 V

Dimension (L*W*H)
1600 x 1100 x 1750 mm

Feature
High Precision, Rigid Construction

Color
Grey and Blue

Lubrication System
Centralized

Working Speed
8-30 rpm

Table Rotation Speed
Variable

Surface Finish Quality
0.002 mm

Max Table Load
300 kg

Main Motor
3.7 kW

Coolant System
Provided

Chuck Control
Electromagnetic

Table Drive
Hydraulic Motor Driven

Athena Horizontal Rotary Surface Grinder About

Make - Athena (Italy)

Model - 175 / TGT

Rotary Table Diameter - 155 mm

Grinding Wheel Size - Diameter 178 mm x 20 mm Width

Max. Distance b/w Table Top & Spindle Axis - 200 mm

- Equipped with Wheel-Top Mounted Wheel Dresser.

- Infinitely Variable Table Rotation Speeds.

- Motorized Rapid Vertical Travel of the Wheel-Head.

- Electromagnetic type Rotary Table.

- Equipped with Coolant Tank & Pump.

- Operating Manual of the machine is available.

- Machine is in excellent working condition.

Video Link - https://youtu.be/ptV6oYXY7NQ

High-Precision Grinding Technology

Athena Horizontal Rotary Surface Grinder delivers an exceptional surface finish up to 0.002 mm thanks to its high-speed grinding wheel and electromagnetic chuck. The variable table rotation speed and hydraulic drive enable precise adjustment for different materials and tasks, guaranteeing both versatility and accuracy across industrial applications.

Robust Construction for Industrial Use

Manufactured with rigid cast iron and engineered for demanding environments, this grinder accommodates a maximum table load of 300 kg. With a semi-automatic manual control system and centralized lubrication, Athena provides durability and dependable operation, making it ideal for exporters, importers, and industrial suppliers.

Efficient Cooling and Lubrication

Equipped with a 60-liter fuel tank and a dedicated coolant system, the Athena grinder ensures optimal temperature management during prolonged workloads. The centralized lubrication minimizes wear and boosts operational lifespan, reducing the likelihood of unscheduled maintenance.

FAQs of Athena Horizontal Rotary Surface Grinder:

Q: How does the Athena Horizontal Rotary Surface Grinder achieve high-precision surface finishes?

A: The Athena grinder utilizes an electromagnetic chuck, variable hydraulic table rotation, and a fast-spinning grinding wheel to produce highly accurate surfaces with a finish quality of 0.002 mm. Its robust build and precise manual control facilitate exact adjustments, ensuring consistency in industrial surface grinding tasks.

Q: What materials can be processed with the Athena Surface Grinder?

A: Thanks to its rigid cast iron construction and powerful 3.7 kW main motor, the grinder can handle a wide range of metals and hard materials commonly used in manufacturing and industrial applications. The adjustable speed and hydraulic drive make it versatile for various workpieces.

Q: When is the coolant system activated during operation?

A: The coolant system operates throughout the grinding process, maintaining appropriate temperatures to prevent deformation of workpieces and protect the grinding wheel from excessive wear. It is activated as soon as the grinding wheel engages with the workpiece.

Q: Where is the Athena Horizontal Rotary Surface Grinder typically installed?

A: The grinder is mostly deployed in industrial fabrication units, manufacturing workshops, and production facilities. Given its considerable floor space requirement (1600 mm x 1100 mm) and weight, it is best suited for permanent installation in dedicated grinding areas.

Q: What is the benefit of having centralized lubrication?

A: Centralized lubrication ensures all moving parts and slide ways receive adequate lubrication, reducing friction and wear. This increases the machines operational reliability, minimizes downtime for maintenance, and extends its productive life.

Q: How is the table rotation speed controlled?

A: The table rotation is driven by a hydraulic motor and can be manually varied between 830 rpm based on the requirements of the job, enabling operators to optimize surface grinding for different materials and thicknesses.

Q: What process is used to hold workpieces securely during grinding?

A: The grinder features an electromagnetic chuck with a 350 mm diameter, which securely holds the workpiece in place during grinding. This ensures stability, reduces movement, and enhances the accuracy and quality of surface finishing.
