Caber Italy Automatic Drilling and Tapping Machine

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Caber Italy Automatic Drilling and Tapping Machine Specification

Noise Level
Low

Spindle Speed
Variable, up to 2800 rpm

Motor Power
1.5 kW

Features
High precision, rapid tool change, durable construction, automatic operation, safety interlock

Table Size
500x400 mm

Machine Type
Bench/Vertical Mount

Cutting Area
Aprox. 500x400 mm

Frequency
50 Hz

Diameter
Max. 20 mm (drill); M16 (tap)

Condition
New

Dimension (L*W*H)
900x700x1700 mm

Product Type
Automatic Drilling and Tapping Machine

Material
Heavy Duty Cast Iron, Steel

Computerized
No

Automatic Grade
Automatic

CNC Or Not
Not CNC

Control System
Electromechanical

Voltage
400 V

Power
1.5 kW

Power Source
Electric

Weight (kg)
Approx. 300 kg

Capacity
Drilling up to 20 mm, Tapping up to M16

Color
Standard Machine Grey

Usage & Applications
Automatic drilling and tapping operations for metalworking, mass production, workshops

Coolant System
Integrated

Spindle Travel
120 mm

Work Table Movement
Manual/Automatic

Phase
Three Phase

Safety
Emergency stop, overload protection

Lubrication
Centralized automatic

Spindle Taper
MT2

Caber Italy Automatic Drilling and Tapping Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Caber Italy Automatic Drilling and Tapping Machine

Make - Caber (Italy)

Model - 60 R-I

Drilling Capacity - 60 mm

Spindle Diameter - 90 mm

Rotary Table Diameter - 600 mm

Max. Outside Diameter of Job - 1100 mm

Max. PCD of Drill Holes - 1000 mm

Spindle Taper - MT 5

Spindle Feed Travel - 200 mm

Spindle Speeds - 45 rpm to 1000 rpm

Max. Distance between Table Top & Spindle - 550 mm

- Can be used for Drilling or Tapping at any PCD.

- Working in Complete Auto-Cycle Mode.

- Automatic Indexing of the Rotary Table.

- Complete with lots of spare Index Plates.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/940o1Yf8r_k

Superior Precision and Durability

Built with heavy-duty cast iron and steel, this machine delivers long-lasting performance and accuracy. Its high-precision spindle and robust construction make it especially suited for demanding industrial applications and continuous usage in mass production settings.

Integrated Automated Features

Equipped with a centralized automatic lubrication system and integrated coolant, operational maintenance is minimized. The automatic grade and variable speed control facilitate seamless operation with rapid tool changes, enhancing productivity and reducing manual involvement.

Advanced Safety and Usability

With core safety features such as emergency stop and overload protection, the Caber Italy machine prioritizes operator security. The intuitive electromechanical control system ensures reliable and easy operation, while the low noise level creates a comfortable working environment.

FAQs of Caber Italy Automatic Drilling and Tapping Machine:

Q: How does the automatic drilling and tapping process work on this machine?

A: The machine uses an electromechanical control system to automate drilling and tapping operations. By setting the required parameters, operators can initiate the process, and the spindlesupported by a centralized lubrication and integrated coolant systemexecutes precise drilling or tapping cycles with minimal manual intervention.

Q: What materials can be processed with the Caber Italy machine?

A: This machine is designed to handle a variety of metals, including steel and other heavy-duty materials, thanks to its robust cast iron and steel construction. It is suitable for a range of metalworking applications in workshops and mass production lines.

Q: Where is this machine most effectively used?

A: The Caber Italy Automatic Drilling and Tapping Machine is ideal for metalworking industries, automotive component manufacturing, fabrication workshops, and production facilities that require reliable, high-volume drilling and tapping tasks.

Q: What are the benefits of the centralized automatic lubrication and integrated coolant system?

A: Centralized automatic lubrication and integrated coolant help extend the machines service life by ensuring critical moving parts are continuously lubricated and cooled. This reduces wear and heat generation, leading to smoother operation and less downtime for maintenance.

Q: When should emergency stop and overload protection features be used?

A: Emergency stop should be engaged during any unexpected malfunction or risk to operator safety. Overload protection activates automatically to prevent mechanical or electrical damage if the system detects excessive load during operation.

Q: How is the spindle speed controlled, and what is its maximum speed?

A: Spindle speed is variable and can be easily adjusted using the machines control system, allowing operators to match speed to material and process requirements. The maximum spindle speed reaches up to 2800 rpm, suitable for a wide range of drilling and tapping applications.
