Caser All geared Radial Drill

Get a Price/Quote

MOQ : 1 Piece

Caser All geared Radial Drill Specification

Machine Type
Radial Drill Machine

Diameter
Drilling up to 50 mm

Condition
New

Motor Power
3 HP

Frequency
50 Hz

Spindle Speed
90 - 1800 rpm (variable speed)

Noise Level
Low

Features
Gear-driven, heavy duty, robust construction, automatic feed, adjustable arm

Table Size
600 mm x 450 mm

Cutting Area
Adjustable - Maximum 1200 mm radial range

Dimension (L*W*H)
2600 mm x 1100 mm x 2800 mm

Product Type
All Geared Radial Drill Machine

Material
Cast Iron, Steel

Computerized
No

Automatic Grade
Semi-Automatic

CNC Or Not
Not CNC

Control System
Manual Gear Control

Voltage
415V

Power
3 HP

Power Source
Electric

Weight (kg)
2150 kg

Capacity
Drilling up to 50 mm diameter (in steel)

Color
Blue & White

Usage & Applications
Industrial Drilling, Metal Fabrication, Heavy Engineering Workshops

Tapping Capacity
32 mm

Column Diameter
250 mm

Spindle Travel
300 mm

Chuck Capacity
Up to 16 mm

Drilling Head Movement
Along radial arm, manual

Max Distance Spindle Nose to Base
1200 mm

Arm Elevation
Motorized or Hand operated

Number of Spindle Speeds
8

Base Size
1400 mm x 700 mm

Arm Length
1200 mm

Spindle Taper
MT-4

Coolant Pump
Yes, Fitted as standard

Max Distance Spindle Center to Column
1200 mm

Drilling Accuracy
High Precision

About Caser All geared Radial Drill

Caser Radial Drill Machine

Make - Caser (Italy)
Drilling Capacity - 47 mm
Spindle Diameter - 65 mm
Arm Length - 1300 mm
Spindle Vertical Travel - 340 mm
Spindle Speeds - 26.5 rpm to 1750 rpm
Spindle Taper - MT4
Arm Vertical Travel - 650 mm
Cube Table Size - 550 mm x 750 mm
Clamping - Automatic ; Hydraulic.
Machine is in excellent working condition.

Exceptional Drilling Capacity and Versatility

The Caser All Geared Radial Drill is engineered for versatility, accommodating workpieces up to 1200 mm in diameter. Its powerful 3 HP motor and variable spindle speeds provide adaptability for various metals, making it suitable for demanding industrial environments. Enhanced with a maximum drilling capacity of 50 mm in steel, this machine is a reliable addition to metal fabrication shops and heavy engineering facilities.

Advanced Features for Precision and Ease of Use

Featuring high-precision drilling capabilities, this radial drill incorporates a gear-driven mechanism and an adjustable arm for maximum flexibility. The arm can be raised either manually or via a motorized system, and the drilling head moves smoothly along the radial arm. An integrated coolant pump and automatic feed further simplify operation and help maintain cutting accuracy during prolonged use.

Built for Durability and Heavy-Duty Applications

Constructed from premium cast iron and steel, the Caser radial drill guarantees exceptional durability under intensive workloads. Its robust frame minimizes vibration and ensures stability, while a large base and worktable offer ample support for oversized components. Designed for both exporters and manufacturers, this machine meets international standards of quality and performance.

FAQs of Caser All geared Radial Drill:

Q: How does the Caser All Geared Radial Drill accommodate large and heavy workpieces?

A: The machine features a long 1200 mm radial arm and a spacious base size of 1400 mm x 700 mm, allowing it to handle large workpieces. Its adjustable arm and drilling head movement along the radial arm provide flexibility to position the drill accurately over a wide area.

Q: What are the key benefits of the gear-driven mechanism in this radial drill?

A: The gear-driven system offers increased torque and consistent power transmission, which is essential for heavy-duty drilling tasks. It also enables smooth speed changes and enhances precision, making it ideal for high-accuracy industrial work.

Q: When is it advisable to use the coolant pump, and how does it enhance the drilling process?

A: The integrated coolant pump should be used during prolonged or intensive drilling operations. It helps dissipate heat, preserves tool life, and assures a smoother finish on the material, especially when working with hard metals.

Q: Where is the Caser All Geared Radial Drill best utilized?

A: This radial drill is well-suited for industrial drilling applications, metal fabrication units, heavy engineering workshops, and manufacturing environments where precision, robustness, and flexibility are required.

Q: What is the process for adjusting the arm elevation and drilling settings?

A: The arm elevation can be adjusted manually using a hand wheel or electrically via a motorized system, allowing easy alignment of the drill head. Speed and feed rates are set through the manual gear control, providing operators with complete control over drilling parameters.

Q: How does the machine ensure high drilling accuracy and precision?

A: The Caser radial drill incorporates a stable cast iron frame, minimal vibration, precision-machined components, and adjustable arm positioning. These factors work together to maintain high drilling accuracy, even during challenging operations.
