CIMA P3 Gear Hobbing machine

Name: CIMA P3 Gear Hobbing machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

CIMA P3 Gear Hobbing machine Specification

Machine Type
Gear Hobbing Machine

Color
Standard Industrial Grey

Power
4 kW Motor

Dimension (L*W*H)
1500 mm x 1100 mm x 1800 mm

Output
Up to 50 Gears per Hour

Voltage
415 V, 3 Phase

Used For
Gear Cutting Operations

Condition
Used

Capacity
Up to 250 mm Gear Diameter

Feature
High Precision, Robust Construction

Weight
Approximately 1500 kg

Min Gear Module
0.5 Module

Table Bore Diameter
70 mm

Hob Head Swivel Angle
±45 Degrees

Max Gear Module
6 Module

Model
CIMA P3

Control Type
Manual

Max Centre Distance Table-Hob
250 mm

Coolant System
Integrated

Min-Max Number of Teeth
6 to 180

Max Axial Travel of Hob
140 mm

Table Traverse
Automatic

Spindle Speed Range
40 - 400 RPM

Max Table Diameter
330 mm

CIMA P3 Gear Hobbing machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About CIMA P3 Gear Hobbing machine

Make - Cima (Italy)

Model - P3

Max. Module - 3 Module

Max. Gear Diameter - 155 mm (with Tail-Stock)

Vertical Travel of Hobbing Head - 200 mm

Max. Hob Cutter Diameter - 80 mm

Table Diameter - 150 mm

Max. Distance between Table Top & Center - 390 mm

- Rapid Motorised Travels on Vertical & Table Travel.

- Complete with Change Gears, Mandrels & other accessories.

- Operating Manual of the Machine is available.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/GljPJ05msnQ

Versatile Gear Cutting for Various Applications

The CIMA P3 Gear Hobbing Machine is engineered to handle a wide variety of gear cutting tasks. With a capacity for gear modules ranging from 0.5 to 6 and the ability to create gears with 6 to 180 teeth, it is suitable for both small and large production batches. The automatic table traverse and integrated coolant system further enhance operational efficiency and surface finish quality.

Precision Built with Durable Construction

Built to last, the CIMA P3 boasts a robust design and high-precision components. Its manual control interface enables skilled operators to fine-tune processes, while the adjustable hob head swivel of 45 degrees accommodates versatile gear designs. This heavy-duty machine (weighing approximately 1500 kg) is tailored for industrial environments demanding continuous gear production without compromising on quality.

FAQs of CIMA P3 Gear Hobbing machine:

Q: How does the CIMA P3 Gear Hobbing Machine operate for gear cutting?

A: The CIMA P3 utilizes a rotating hob to cut gear teeth into a workpiece mounted on the table. The machines automatic table traverse synchronizes movement with the hob, ensuring even and precise gear tooth formation. Operators control the process manually to ensure optimal accuracy.

Q: What types of gears can be produced with this machine?

A: With its wide module capacity (0.5 to 6) and tooth range (6 to 180), the CIMA P3 is capable of producing a broad spectrum of gears, including spur and helical gears up to a 250 mm diameter, suited for automotive, industrial, and mechanical applications.

Q: When should the integrated coolant system be used?

A: The coolant system should be used during gear cutting operations to minimize heat generation, reduce tool wear, and improve surface finish. Activation during cutting enhances machine longevity and ensures quality gears.

Q: Where is the CIMA P3 Gear Hobbing Machine typically installed?

A: This machine is ideally installed in manufacturing plants, gear workshops, or industrial facilities that require medium- to high-volume gear production. Its robust build and dimensions (1500 mm x 1100 mm x 1800 mm) suit standard industrial environments.

Q: What is the process for setting up different gear modules and teeth numbers?

A: To accommodate various gear modules, operators adjust both the hob and table settings according to the desired gears specifications. The manual controls and hob head swivel (45 degrees) offer flexibility for a wide range of teeth counts and gear profiles.

Q: How does using the CIMA P3 benefit gear manufacturers and suppliers?

A: Manufacturers benefit from its high precision, reliable performance, and the ability to produce up to 50 gears per hour. The machines durability and output efficiency optimize operational cost and increase production capabilities for exporters, suppliers, and traders alike.
