Cincinnati Monoset Tool Cutter Grinder

Name: Cincinnati Monoset Tool Cutter Grinder
Brand: Liberty Metal & Machines Private Limited
Price: 20000 INR
Availability: InStock

Price 20000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Cincinnati Monoset Tool Cutter Grinder Specification

Shape
Rectangular Base with Articulated Movable Components

Coating
Uncoated/Ground Steel

Tool Type
Universal Tool Grinder

Operate Method
Manual with Handwheels and Lever Adjustments

Hardness
Up to 62 HRC (depends on component tooling)

Machine Type
Monoset Tool and Cutter Grinder

Drill Bits Types
Can grind various (twist, step, center, custom)

Features
Precision Indexing, Adjustable Head, Universal Tool Holding, Integral Motor

Material
Cast Iron, Steel

Cutting Speed
Variable Operator Controlled

Length
Machine: approx. 1600 mm x 1200 mm

Cutter Type
End Mills, Reamers, Form Cutters, Special Tools

Operation Type
Manual / Semi-automatic

Brooches Type
Suitable for various broach tools

Cutting Force
Operator Applied, manual

Cutting Capacity
Can grind tools up to 305 mm (12 inch) length

Cutting Accuracy
0.005 mm

Diameter
Workhead spindle accepts up to 4-inch (102 mm) diameter tools

Maximum Torque
Not specified (dependent on handle force)

Processing Type
Grinding / Sharpening

Table Movement (Longitudinal & Traverse)
Longitudinal: 406 mm, Traverse: 178 mm

Universal Swivel Head
180 Swivel

Model
Monoset

Spindle Motor Power
2 HP AC Induction Motor

Optional Attachments
Radius Grinding, Relief Grinding, Tooling Fixtures

Approximate Net Weight
1200 kg

Workhead Indexing
360 with Positive Stops

BladeSize
Not applicable accepts multiple tool sizes

Voltage
415V / 3 Phase / 50 Hz

Coolant System
Integrated Recirculating Coolant System

Application
Grinding and Re-sharpening of Cutting Tools

Wheel Diameter
Standard up to 150 mm

About Cincinnati Monoset Tool Cutter Grinder

Make - Cincinnati (USA)

Model - Monoset

Swing over main slide - 12"

Length b/w Spindle Nose and Tail Center - 6"

Max. Wheel Diameter - 3.5 "

Collet Work Diameter - 0.125" to 1.25"

Longitudinal Movement of Main Slide - 5.75"

Offset Slide Movement (either side of Center) - 2.25"

Angular Range of Work-Head Swivel Base - 235 degree

Work-Head Angular Adjustment in Vertical Axis - +40 degree to -40 degree

Vertical Slide of Wheel-Head (from Center) - above 4.25" to below 4.5"

Transversal Travel of Wheel-Head Slide - 7.5"

Longitudinal Travel of Wheel-Head Slide - 6"

- Automatic Generation of infinitely variable spiral leads for Flute Grinding.

- Brochure and Operating Manual of the machine is available.

- Machine is in excellent working condition.

Video link - https://youtu.be/Ar_iXvG9xcE

Engineered for Versatile Tool Grinding

The Cincinnati Monoset Tool Cutter Grinder is designed to handle a diverse array of cutting and shaping applications. Its combination of longitudinal and traverse table movements, variable operator-controlled speeds, and flexible tool holding capabilities enable precise handling of everything from twist drills to specialized cutters. The articulated, rectangular base ensures stability and accuracy during intricate grinding tasks.

Precision and Durability in Every Grind

Built from cast iron and ground steel, the Monoset delivers consistent hardness up to 62 HRC, with cutting accuracy maintained within 0.005 mm. The universal swivel head and 360 positive-stop workhead indexing provide precise angles and repeatability. The integrated coolant system optimizes cooling and debris removal for high-quality finishes and extended tool life.

Flexible, User-Centric Operation

Operators benefit from manual control via handwheels and levers, supporting both fine adjustments and efficient production runs. Optional attachments for radius and relief grinding expand capabilities, while the recirculating coolant system helps maintain a clean work environment and consistent grinding performance. This blend of manual finesse and robust design makes the Monoset indispensable for tool making and maintenance.

FAQs of Cincinnati Monoset Tool Cutter Grinder:

Q: How do I operate the Cincinnati Monoset Tool Cutter Grinder for sharpening various cutting tools?

A: Operation is manual using handwheels and lever adjustments. Secure the tool using the universal tool holding system, set the required angles via the 360 indexed workhead and 180 swivel head, and select the grinding wheel (up to 150 mm). Adjust the longitudinal and traverse tables (406 mm and 178 mm, respectively), and use the integral recirculating coolant system during grinding for optimal results.

Q: What types of cutting tools can the Monoset Grinder handle and what are the size limits?

A: The Monoset is a universal grinder capable of sharpening and grinding twist drills, end mills, reamers, broach tools, form cutters, and a variety of custom tools. It accepts tool diameters up to 102 mm (4 inches) and cutting tool lengths up to 305 mm (12 inches). The robust workhead and flexible fixtures support multiple tool shapes and sizes.

Q: When should I use the optional attachments available for this grinder?

A: Optional attachments, such as for radius and relief grinding or specialized tooling fixtures, are recommended when you need to produce or re-sharpen tools with complex profiles or non-standard geometries. They increase the versatility of the machine and are particularly useful for toolrooms handling a wide range of custom or specialized tools.

Q: Where can the Cincinnati Monoset Grinder be installed and what power requirements does it have?

A: This grinder is suitable for installation in toolrooms, machine shops, manufacturing facilities, and repair centers. It requires a 415V, 3-phase, 50 Hz power supply and should be placed on a stable, level floor capable of supporting its approximate net weight of 1200 kg. Adequate space for movementabout 1600 mm x 1200 mmis recommended.

Q: What is the process for achieving high-precision tool sharpening with the Monoset?

A: Begin by securely mounting your tool and configuring the swivel and workhead to the desired angle. Using the handwheel controls, set table movement and make precise incremental adjustments. Select suitable grinding wheels and engage the coolant system to maintain accuracy and surface quality. Follow recommended grinding speeds and regularly check dimensions to achieve tolerances within 0.005 mm.

Q: How does using the Monoset Grinder benefit my operation?

A: The Cincinnati Monoset offers flexible, precise, and repeatable tool sharpening, reducing tool replacement costs and extending tool life. Its robust construction, integrated coolant system, and adaptability for multiple tool types make it a cost-effective solution for workshops seeking high productivity and quality results.
