Colchester 1000 mm Length Lathe Machine

Name: Colchester 1000 mm Length Lathe Machine
Brand: Liberty Metal & Machines Private Limited
Price: 42500 INR
Availability: InStock

Price 42500 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Colchester 1000 mm Length Lathe Machine Specification

Product Type
Lathe Machine

Material
Cast Iron

Cutting Thickness
Up to 12 mm

Cutting Speed
252000 RPM (variable)

CNC Or Not
Conventional (Not CNC)

Automatic Grade
Manual

Control System
Manual

Max. Swing Diameter
350 mm

Voltage
415 V, 3 Phase

Weight (kg)
1150 kg

Dimension (L*W*H)
2050 x 1000 x 1350 mm

Capacity
1000 mm Center Distance

Feature
Precision engineering, Strong bed construction, Easy operation

Color
Standard Industrial Grey

Spindle Nose
Camlock type

Lubrication System
Manual/Hand pump

Spindle Bore
38 mm

Number of Spindle Speeds
12

Chuck Size
200 mm (3-jaw supplied)

Main Motor Power
3 HP

Thread Cutting Range
0.27 mm/rev (metric), 456 TPI (imperial)

Distance Between Centers
1000 mm

Tailstock Quill Travel
135 mm

Surface Finish
Ground and Hardened Bed

Bed Length
1000 mm

Max. Turning Diameter over Slide
210 mm

Lead Screw Diameter and Pitch
25 mm x 4 TPI

Coolant System
Provided

Colchester 1000 mm Length Lathe Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Colchester 1000 mm Length Lathe Machine

Make - Colchester (England)

Model - Master 2500

Center Height - 165 mm

Max. Length of Job - 1000 mm

Max. Job Diameter over Bed - 330 mm

Max. Job Diameter over Cross-Slide - 210 mm

Bed Width - 230 mm

Chuck Diameter - 200 mm

Max. Job Diameter in Gap - 480 mm

Spindle Speeds - 30 rpm to 2500 rpm

Spindle Bore - 40 mm

- Machine is in excellent working condition.

Vidoe of The Machine -

https://youtu.be/xcxnf49sxJA

Engineered for Precision and Durability

This Colchester lathe stands out for its strong cast iron construction and thoroughly ground, hardened bed, ensuring accuracy and long service life. With a cutting thickness of up to 12 mm and a max swing diameter of 350 mm, its designed to handle both routine and complex metalworking tasks with ease.

Flexible Operation and Versatility

Benefit from a manual control system combined with a 12-speed, variable RPM range. Whether threading, facing, or turning, the machine adapts to both metric and imperial threading needs. The 1000 mm distance between centers accommodates a variety of workpiece lengths.

Enhanced Safety and Maintenance Features

A manual lubrication system and integrated coolant feature optimize performance and tool life, while thoughtful bed design supports stable and vibration-free operation. Easy manual controls simplify machine handling for operators at every experience level.

FAQs of Colchester 1000 mm Length Lathe Machine:

Q: How is the Colchester 1000 mm Length Lathe Machine operated?

A: This lathe features a conventional manual control system, allowing operators to set spindle speeds, feed rates, and threading options using hands-on levers and dials. It is not CNC, making it straightforward for skilled machinists to adjust settings as needed for each job.

Q: What types of materials can this lathe machine process?

A: With its 3 HP main motor, variable spindle speed (252000 RPM), and robust construction, the machine is suitable for turning various metals such as steel, stainless steel, aluminum, and cast iron, supporting a maximum cutting thickness of up to 12 mm.

Q: When should I use the coolant and manual lubrication system?

A: The coolant system should be used during high-speed or heavy-duty operations to dissipate heat and prolong tool life. The manual lubrication system, operated by a hand pump, should be engaged as per recommended schedules to maintain smooth movement and prevent wear.

Q: Where can this Lathe Machine be installed and used effectively?

A: Its industrial-grade design, with a 415 V, 3-phase power supply requirement, is ideal for installation in machine shops, manufacturing plants, and tool rooms, particularly in environments requiring high precision machining and robust performance.

Q: What is the process for changing spindle speeds on this lathe?

A: Operators can manually select one of twelve spindle speeds using the machines gear levers, allowing RPM adjustments between 25 and 2000 to suit different cutting, facing, and threading tasks.

Q: What are the key benefits of the Colchester Lathe Machine?

A: Users benefit from high-precision machining, a wide threading range (metric and imperial), sturdy bed construction for vibration-free operation, and user-friendly manual controls. The ground-and-hardened bed increases accuracy and reduces maintenance needs.

Q: How does the machines thread cutting range enhance its usability?

A: With a thread cutting range from 0.27 mm/rev (metric) and 456 TPI (imperial), operators can efficiently turn a diverse array of screw threads, making the machine versatile for projects requiring international and specialized thread forms.
