Colchester Master 2500 Lathe Machine

Name: Colchester Master 2500 Lathe Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Colchester Master 2500 Lathe Machine Specification

Product Type
Manual Centre Lathe

Material
Cast Iron, Alloy Steel

Cutting Thickness
Up to 10 mm (material dependent)

Cutting Speed
402000 RPM (Variable)

CNC Or Not
No (Manual)

Automatic Grade
Manual

Control System
Manual Control

Max. Swing Diameter
360 mm over bed

Voltage
415 V, 3 Phase

Weight (kg)
1315 kg (approx)

Dimension (L*W*H)
2025 mm x 952 mm x 1330 mm (approx)

Capacity
Medium Duty, General Engineering

Feature
Induction Hardened Bedways, Hardened and Ground Gears, High Accuracy

Color
Industrial Grey

Distance Between Centers
635 mm

Spindle Bore
40 mm

Chuck Size
200 mm (8")

Accessories Provided
3-jaw chuck, set of change gears, tool post, centres

Bed Length
1000 mm

Spindle Mount
Camlock D1-3

Surface Finish
Precision Ground

Threading Range
Imperial and Metric Thread Cutting Facility

Number of Spindle Speeds
12

Tailstock Quill Travel
127 mm

Leadscrew Diameter/Pitch
25.4 mm/4 T.P.I.

Feed Range
0.025 1.27 mm/rev

Power of Main Motor
2.2 kW / 3 HP

Tailstock Quill Diameter
44.45 mm

Colchester Master 2500 Lathe Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Colchester Master 2500 Lathe Machine

Make - Colchester (England)

Model - Master 2500

Center Height - 165 mm

Max. Length of Job - 1000 mm

Max. Job Diameter over Bed - 330 mm

Max. Job Diameter over Cross-Slide - 210 mm

Bed Width - 230 mm

Chuck Diameter - 200 mm

Max. Job Diameter in Gap - 480 mm

Spindle Speeds - 30 rpm to 2500 rpm

Spindle Bore - 40 mm

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/tr15U3sTCdo

Precision Engineering for Versatile Machining

The Colchester Master 2500 Lathe is designed for precision and reliability in general engineering tasks. Its medium-duty capacity and high accuracy are ideal for workshops looking for consistent and top-quality results. Induction hardened bedways and an alloy steel build contribute to durability and outstanding surface finish.

Flexible Manual Operation and Speed Control

Equipped with a 3 HP main motor and manual controls, the Master 2500 allows users to finely adjust cutting speeds between 40 and 2000 RPM. The spacious swing over bed and comprehensive feed/threading ranges enable machinists to work with diverse materials and dimensions, optimizing production for various job requirements.

Comprehensive Accessories and User-Friendly Features

Included with the machine are a 3-jaw chuck, a set of change gears, a tool post, centres, and precision-ground surfaces. These accessories facilitate immediate usage and enhance the operators experience. The control system is fully manual, making it easily adaptable for both novice and experienced users.

FAQs of Colchester Master 2500 Lathe Machine:

Q: How can I achieve high accuracy with the Colchester Master 2500 Lathe Machine?

A: High accuracy is achieved through features like induction hardened bedways, hardened and ground gears, and precision-ground surfaces. Regular calibration and proper usage of the provided set of change gears also contribute to maintaining precision.

Q: What types of threads can the Colchester Master 2500 cut?

A: This lathe offers both imperial and metric thread cutting facilities. Operators can select appropriate change gears from the provided set to machine a wide range of thread pitches required for various engineering applications.

Q: When should I use the maximum swing diameter over bed?

A: You should utilize the maximum swing diameter of 360 mm over bed when working on parts that require large diameters, such as flanges or sizeable cylindrical components, ensuring you remain within the lathes operational limits.

Q: Where is the Colchester Master 2500 most effectively used?

A: This lathe is best suited for medium-duty general engineering workshops, repair shops, and training centers, where versatility, reliability, and precision are required for processing different materials and job types.

Q: What is the process for changing spindle speeds on this machine?

A: The Colchester Master 2500 provides 12 spindle speeds adjustable between 40 and 2000 RPM. Operators change speeds manually by selecting the desired setting via the control levers, accommodating different material types and machining operations.

Q: How do the accessories enhance the usage of the lathe?

A: Included accessories such as the 3-jaw chuck, tool post, centres, and change gears streamline setup, improve workholding, and enable immediate switching between tasks. These components ensure versatility and efficiency in day-to-day operations.

Q: What are the benefits of the Colchester Master 2500s induction hardened bedways?

A: Induction hardened bedways resist wear and maintain accuracy over prolonged usage, ensuring that the lathe delivers precise machining and reduces maintenance needs, thereby extending the machines operational life.
