Colchester Student 1800 Lathe

Name: Colchester Student 1800 Lathe
Brand: Liberty Metal & Machines Private Limited
Price: 6300 INR
Availability: InStock

Price 6300 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Colchester Student 1800 Lathe Specification

Product Type
Engine Lathe / Centre Lathe

Material
Cast Iron

Cutting Thickness
Up to 8 mm (metal) depending on material

Cutting Speed
25 to 2000 RPM

CNC Or Not
No (Manual/Conventional Lathe)

Automatic Grade
Manual

Control System
Manual

Max. Swing Diameter
280 mm (over bed)

Voltage
415 V / 3 Phase / 50 Hz

Weight (kg)
Approx. 850 kg

Dimension (L*W*H)
1676 x 965 x 1335 mm

Capacity
Between centres - 1000 mm

Feature
Gap bed, hardened & ground bedways, metric/inch threading

Color
Industrial Grey

Thread Cutting (Metric)
0.2 to 14 mm

Spindle Nose
Camlock D1-3

Spindle Bore
40 mm

Distance over Cross Slide
170 mm

Bed Width
191 mm

Centre Height
165 mm

Lead Screw Diameter/Pitch
25 mm / 4 mm pitch

Carriage Travel
885 mm

Coolant System
Fitted

Lighting
Fitted as standard

Thread Cutting (Imperial)
2 to 72 TPI

Chuck Size
6 inch (typically supplied)

Number of Spindle Speeds
12

Tailstock Taper
MT3

Spindle Motor Power
2.2 kW (3 HP)

Colchester Student 1800 Lathe Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

Colchester Student 1800 Lathe About

Make - Colchester (England)

Model - Student 1800

Center Height - 165 mm

Max. Length of Job - 650 mm

Max. Job Diameter over Bed - 330 mm

Max. Job Diameter over Cross-Slide - 210 mm

Max. Job Diameter in Gap - 480 mm

4-Jaw Chuck Diameter - 250 mm

3-Jaw Chuck Diameter - 200 mm

Face-Plate Diameter - 305 mm

Bed Width - 230 mm

Spindle Speeds - 22 rpm to 1800 rpm

Spindle Bore - 40 mm

- Machine is in excellent working condition.

Video link

https://youtu.be/jObiqZ8wj6o

Engineered for Precision and Reliability

The Colchester Student 1800 Lathe is designed to offer exceptional accuracy and reliability for professional metalworking. Its hardened and ground bedways, extensive spindle speed range, and robust cast iron construction make it suitable for a wide variety of applications. The manual controls and conventional setup allow precise operator input, enabling detailed craftsmanship for both small batch production and educational use.

Versatile Machining Capabilities

This lathe accommodates both metric and imperial threading (0.214 mm and 272 TPI respectively) and provides generous carriage travel of up to 885 mm. The 40 mm spindle bore supports larger workpieces while the maximum swing over bed of 280 mm ensures versatility. Coupled with a gap bed feature, machinists can undertake complex jobs such as faceplate and large-diameter operations with ease.

Features Designed for Operator Convenience

A fitted coolant system and integral lighting support a safe, comfortable, and efficient workspace. The control system is fully manual, providing tactile feedback ideal for training environments and hands-on tasks. The lathes compact footprint and approximate 850 kg weight make it a stable and practical investment for educational institutions, workshops, and industrial environments alike.

FAQs of Colchester Student 1800 Lathe:

Q: How is threading performed on the Colchester Student 1800 Lathe?

A: Threading on the Colchester Student 1800 Lathe can be executed in both metric (0.2 to 14 mm) and imperial (2 to 72 TPI) formats. You select the desired pitch through the lathes change gears and chart, enabling accurate thread cutting suitable for various applications.

Q: What types of materials can be machined with this lathe?

A: Due to its 2.2 kW motor and solid Cast Iron construction, the lathe is capable of handling various metals such as steel, aluminum, brass, and copper. The cutting thickness can reach up to 8 mm, depending on the hardness of the material.

Q: When should the coolant system be used during operation?

A: The fitted coolant system should be used during prolonged machining tasks, especially when working on metals prone to heat build-up. It helps dissipate heat, improves tool life, and results in a better surface finish on the workpiece.

Q: Where can this lathe be installed and who is it suitable for?

A: Thanks to its 415 V, 3 Phase configuration and compact size, the Colchester Student 1800 can be installed in most industrial workshops, training institutes, and engineering colleges. It is ideal for professionals, educators, and trainees.

Q: What benefits does the gap bed design offer?

A: The gap bed feature allows users to accommodate larger workpieces that would not fit within the standard swing diameter. This increases the range of jobs that can be performed, adding substantial flexibility to workshop operations.

Q: How does the manual control system benefit the user?

A: Manual controls deliver direct operator feedback and greater control over machining operations. This is especially valuable for training environments and skilled machinists seeking tactile interaction during production and prototyping.
