Send InquiryColchester Student Lathe Machine
Price 20000 INR/ Piece
MOQ : 1 Piece
Colchester Student Lathe Machine Specification
- Product Type
- Manual Centre Lathe
- Material
- Cast Iron Body, Hardened Bedways
- Cutting Thickness
- Up to 6 mm (varies with material and tooling)
- Cutting Speed
- 25 - 2000 RPM (Variable)
- CNC Or Not
- No (Conventional Lathe)
- Automatic Grade
- Manual
- Control System
- Manual Lever and Gearbox Controls
- Max. Swing Diameter
- 330 mm (over bed)
- Voltage
- 415 V (Three Phase)
- Weight (kg)
- Approximately 700 kg
- Dimension (L*W*H)
- 1670 x 660 x 1070 mm
- Capacity
- Between centres: 750 mm
- Feature
- Hardened bedways, Power feed, Taper turning attachment, Coolant pump
- Color
- Industrial Grey
- Lead Screw Diameter
- 25 mm
- Type of Chuck
- 3-Jaw Self Centring Chuck
- Motor Power
- 2.2 kW (3 HP)
- Threads Cutting Metric
- 0.2 - 14 mm
- Threads Cutting Imperial
- 2 - 72 TPI
- Bed Width
- 190 mm
- Surface Finish
- Precision Ground
- Application
- General Machining, Educational, Training, Toolrooms
- Coolant System
- Integrated, with pump
- Spindle Bore
- 40 mm
- Tailstock Travel
- 95 mm
- Spindle Speed Range
- 25 - 2000 rpm, 12 speeds
- Tool Post Type
- 4-way Tool Post
- Distance Between Centres
- 750 mm
About Colchester Student Lathe Machine
Make - Colchester (England)
Model - Student 1800
Center Height - 165 mm
Max. Length of Job - 650 mm
Max. Job Diameter over Bed - 330 mm
Max. Job Diameter over Cross-Slide - 210 mm
Max. Job Diameter in Gap - 480 mm
4-Jaw Chuck Diameter - 250 mm
3-Jaw Chuck Diameter - 200 mm
Bed Width - 230 mm
Spindle Speeds - 22 rpm to 1800 rpm
Spindle Bore - 40 mm
- Machine is in excellent working condition.
Video link - https://youtu.be/E3pzeLC5gfo
Versatile and Durable Machining
Designed with a hardened bedway and precision ground surface, the Colchester Student Lathe stands out for its durability and consistent performance. Its cast iron body ensures longevity while supporting a wide range of machining tasks, making it a great fit for educational institutions, toolrooms, and workshops.
Comprehensive Control and Flexibility
Featuring a manual lever and gearbox control system, the lathe offers adjustable spindle speeds between 252000 rpm and convenient 12-speed operation. The 4-way tool post, integrated coolant pump, and taper turning attachment enable users to handle complex turning operations efficiently.
Precision and Safety in Operation
Safety is paired with precision thanks to its robust construction, self-centering chuck, and efficient power feed mechanism. The lathes precision threading capabilities (0.214 mm metric, 272 TPI imperial) and max swing of 330 mm allow for detailed component production.
FAQs of Colchester Student Lathe Machine:
Q: How does the integrated coolant system benefit the machining process?
A: The integrated coolant system, complete with a pump, ensures components remain at optimal temperatures during operations, reducing tool wear and enhancing surface finishes for consistent, high-quality results.Q: What types of tasks or materials is this lathe designed to handle?
A: This lathe is suitable for general machining applications, including cutting, facing, threading, and turning tasks on various metals up to 6 mm thick, depending on the tooling and material hardness.Q: When should I use the power feed and taper turning attachment?
A: The power feed is ideal for repetitive or long cuts, providing smooth automatic movement of the carriage. The taper turning attachment is used when you need to create precise tapers or angled cuts on your workpiece.Q: Where can the Colchester Student Lathe Machine be utilized most effectively?
A: This lathe excels in educational settings, training centers, toolrooms, and workshops within manufacturing, repair, or prototyping environments where manual precision work is a priority.Q: What is the process of changing spindle speeds on this lathe?
A: Spindle speeds are adjusted manually using the gearbox control levers. You can select from 12 available speed settings, ranging from 25 to 2000 rpm, to match the material and type of operation required.Q: How does the 3-jaw self-centering chuck improve usability?
A: The 3-jaw self-centering chuck ensures that workpieces are securely held and automatically centered, saving setup time, reducing errors, and improving safety during turning or threading processes.Q: What are the main benefits of the Colchester Student Lathe for training purposes?
A: Robust design, comprehensive safety features, and versatile controls give trainees hands-on experience in traditional machining. Its adaptability to various operations prepares students for real-world shop environments.
