Colchester Triumph 2500 Lathe Machine

Name: Colchester Triumph 2500 Lathe Machine
Brand: Liberty Metal & Machines Private Limited
Price: 1100 USD
Availability: InStock

Price 1100 USD ($)/ Piece

Get a Price/Quote

MOQ : 1 Piece

Colchester Triumph 2500 Lathe Machine Specification

Product Type
Manual Centre Lathe Machine

Material
High Grade Cast Iron

Cutting Thickness
Up to 12 mm

Cutting Speed
30 - 2500 RPM

CNC Or Not
Not CNC (Manual)

Automatic Grade
Semi-Automatic

Control System
Manual Lever and Wheel

Max. Swing Diameter
400 mm

Voltage
415V/3 Phase/50 Hz

Weight (kg)
Approx. 1500 kg

Dimension (L*W*H)
1910 x 990 x 1130 mm

Capacity
Standard Duty

Feature
Heavy Duty, Precision Ground Bedways, Hardened Gears

Color
Industrial Grey

Bed Type
Hardened and Ground, Double-Prismatic

Spindle Bore
54 mm

Tailstock Quill Travel
150 mm

Thread Cutting Range
Imperial: 2 to 72 TPI / Metric: 0.2 to 14 mm

Spindle Nose
D1-6 Camlock

Headstock
Hardened and ground gears with helical teeth

Chuck Size
250 mm

Cross Slide Travel
240 mm

Lubrication System
Automatic with Oil Pump

Number of Speeds
12

Distance Between Centres
750 mm (29.5 in)

Coolant System
Fitted as Standard

Bed Length
1000 mm (39 in)

Standard Accessories
3/4 Jaw Chuck, Steady Rest, Follow Rest, Toolpost, Change Gears, Safety Guard

Drive Motor Power
5.5 kW (7.5 HP)

Lead Screw Diameter
32 mm

About Colchester Triumph 2500 Lathe Machine

Make - Colchester (England)
Model - Triumph 2500
Center Height - 205 mm
Max. Length of Job - 1250 mm
Max. Swing over Bed - 410 mm
Max. Job Diameter over Cross-Slide - 245 mm
Spindle Speeds - 15 rpm to 2500 rpm
Bed Width - 315 mm
Chuck Diameter - 250 mm
Max. Swing Diameter in Gap - 585 mm
Spindle Bore - 55 mm
Equipped with Taper Turning Attachment.
Equipped with 2-Axis DRO.
Complete with 3-point steady, centers, safety covers etc.
Equipped with Drive for Spindle Motor for continuously variable spindle speeds.
Machine is in excellent working condition.

Video Link https://youtu.be/c86tgJisHws

Precision Engineering for Versatile Machining

The Colchester Triumph 2500 is engineered from high grade cast iron, providing a stable and vibration-resistant platform for turning operations. Its hardened, precision-ground bed and helical-geared headstock assure longevity and smooth running, making it suitable for producing parts requiring fine tolerances and repeatability. The standard-fit coolant and lubrication systems enhance tool life and part finish.

User-Friendly Features Boost Productivity

Designed for the manual machinist, the Triumph 2500 combines a semi-automatic operation with manual levers and wheels for intuitive control. Large cross slide and tailstock travel enable versatile setups, while quick-change gears simplify threading in both metric and imperial systems. The full suite of included accessories allows rapid start-up and comprehensive job handling from day one.

FAQs of Colchester Triumph 2500 Lathe Machine:

Q: How do I use the Colchester Triumph 2500 lathe for threading operations?

A: Threading on the Triumph 2500 is streamlined by the inclusion of change gears and a quick-change gearbox. Select the desired threading rangeimperial (2 to 72 TPI) or metric (0.2 to 14 mm)using the gear settings and feed levers. The manual lever and wheel controls allow precise engagement and disengagement of the lead screw for accurate thread turning.

Q: What materials can be machined using this lathe?

A: With its hardened bed and robust build, the Triumph 2500 is suitable for machining a broad variety of ferrous and non-ferrous metals. Its maximum cutting thickness of up to 12 mm and cutting speeds up to 2500 RPM accommodate steel, cast iron, brass, and aluminum, making it versatile for different machining tasks.

Q: Where is the Colchester Triumph 2500 manufactured and exported?

A: The Colchester Triumph 2500 is manufactured, supplied, and exported by companies based in the United Kingdom. It is distributed globally through a network of importers, exporters, suppliers, and traders.

Q: What are the key benefits of the automatic lubrication and coolant system on this machine?

A: The automatic oil pump ensures bedways and critical components are consistently lubricated, reducing wear and extending machine life. The standard coolant system improves chip evacuation, cools the cutting zone, and results in superior surface finish and tool longevity.

Q: When should I perform routine maintenance on the lathe?

A: Routine maintenance, including lubrication checks, cleaning, and inspection of gears and slides, should be conducted as per the manufacturers maintenance scheduletypically daily for cleaning and lubrication, and weekly or monthly for detailed inspections depending on usage intensity.

Q: What power supply is required to operate the Triumph 2500 lathe?

A: This lathe operates on a 415V, 3-phase, 50 Hz electrical supply, common in industrial settings. Ensure that your workshops power system meets these requirements before installation.
