Csepel RHF 75/2000 Radial Drilling Machine

Name: Csepel RHF 75/2000 Radial Drilling Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Csepel RHF 75/2000 Radial Drilling Machine Specification

Spindle Speed
25 2000 rpm

Machine Type
Radial Arm Drilling

Table Size
900 x 800 mm

Diameter
Max. drill diameter 75 mm

Features
Robust construction, precision spindle, adjustable arm, high drilling capacity

Noise Level
Low

Motor Power
7.5 kW

Dimension (L*W*H)
3400 x 1300 x 3200 mm

Condition
New

Frequency
50 Hz

Cutting Area
Large working envelope

Product Type
Radial Drilling Machine

Material
Cast Iron & Steel

Computerized
No

Automatic Grade
Semi-Automatic

CNC Or Not
No

Control System
Manual

Voltage
400 V

Power
7.5 kW

Power Source
Electric

Weight (kg)
6500 kg

Capacity
Drilling capacity up to 75 mm

Color
Green / Grey

Usage & Applications
Heavy-duty industrial drilling, tapping, reaming

Vertical Movement of Arm
900 mm

Arm Length
2000 mm

Number of Spindle Speeds
16 steps

Column Diameter
360 mm

Protection Class
IP54

Distance Spindle to Base
2000 mm

Base Working Area
1800 x 950 mm

Quill Travel
400 mm

Coolant Pump
Integrated

Spindle Taper
Morse 5

Model
RHF 75/2000

Min/Max Distance Spindle to Column
400-2000 mm

Csepel RHF 75/2000 Radial Drilling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Csepel RHF 75/2000 Radial Drilling Machine

Make - Csepel (Hungary)

Model - RFH 75/2000

Drilling Capacity in Steel - 75 mm

Drilling Capacity in Cast Iron - 90 mm

Spindle Diameter - 95 mm

Arm Length - 2200 mm

Spindle Taper - MT 5

Spindle Feed Travel - 380 mm

Spindle Speeds - 19 rpm to 1900 rpm

Vertical Travel of Arm - 1020 mm

Feed Travel Rates - 0.047 mm/rev to 2.00 mm/rev

Table Size - 1010 mm x 755 mm

Max. Height between Base to Spindle - 1750 mm

Clamping Type - Hydraulic

- Machine is in excellent working condition.

Video of the Machine -

https://youtu.be/cryq_tJ8-cA

Precision and Power for Heavy-Duty Drilling

With a maximum drilling capacity of 75 mm and a robust 7.5 kW motor, the Csepel RHF 75/2000 is built to handle intensive industrial applications. Its cast iron and steel frame assures stability during operation, while precision spindle and adjustable arm enable accurate drilling, tapping, and reaming. The spacious base and arm offer a large working envelope for versatility and ease of use.

Versatile Workflow and Optimized Performance

Equipped with 16 spindle speeds and a vertical arm travel of 900 mm, this radial drilling machine adapts easily to various workpiece sizes and materials. The integrated coolant pump maintains optimal temperatures during prolonged use, supporting continuous, high-quality drilling. Manual controls give operators flexibility and precise command over all drilling parameters.

FAQs of Csepel RHF 75/2000 Radial Drilling Machine:

Q: How does the Csepel RHF 75/2000 Radial Drilling Machine achieve high drilling accuracy?

A: The machine features a precision spindle, adjustable arm, and smooth vertical movement. These attributes allow for accurate positioning and drilling, even with large or heavy workpieces. The robust build further minimizes vibrations, enhancing precision.

Q: What types of materials and industries is this drilling machine suitable for?

A: Designed primarily for heavy-duty industrial use, the Csepel RHF 75/2000 is ideal for drilling cast iron, steel, and similar materials. It is suitable for workshops, manufacturing plants, and applications requiring high capacity and reliability.

Q: When is it appropriate to use the integrated coolant pump?

A: The integrated coolant pump should be used during extended or high-speed drilling operations to manage heat generated by friction. This helps preserve the cutting tools lifespan, improves finish quality, and ensures safety.

Q: Where can the Csepel RHF 75/2000 be installed for optimal performance?

A: For best results, install the drilling machine in a stable, well-ventilated industrial workshop or factory space with appropriate electrical supply (400 V, 50 Hz) and sufficient floor space to accommodate its dimensions (3400 x 1300 x 3200 mm).

Q: What is the process for adjusting the spindle speed and arm position?

A: Spindle speeds are manually adjusted through a straightforward control system, offering 16 different steps from 25 to 2000 rpm. The arm position and vertical travel can be set manually as well, enabling precise setup for any workpiece size.

Q: How can operators benefit from the RHF 75/2000s working area and adjustable arm?

A: The large base working area (1800 x 950 mm) and long adjustable arm (2000 mm) allow users to accommodate sizable workpieces and reach multiple drilling points without unnecessary repositioning, increasing productivity and ease of use.
