Drummond Maxicut No. 2A Gear Shaper Machine

Name: Drummond Maxicut No. 2A Gear Shaper Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Drummond Maxicut No. 2A Gear Shaper Machine Specification

Color
Green

Dimension (L*W*H)
Approx. 2.4 m x 1.6 m x 2.1 m

Voltage
415V

Machine Type
Gear Shaper Machine

Condition
Used

Weight
Approximately 2800 kg

Capacity
Max. gear diameter 510 mm

Power
5 HP

Output
High accuracy gears, internal/external

Feature
Robust construction, high precision, durability

Used For
Cutting internal and external gears

Noise Level
Within industrial standards

Stroke Length
180 mm

No. of Teeth Cut
6 to 400

Drive Type
Belt drive

Table Feed
Manual/Automatic

Max Cutting Length
180 mm

Spindle Speed (RPM)
Variable up to 80 RPM

Operating Mode
Semi-automatic

Lubrication System
Centralized automatic

Base Type
Heavy-duty cast iron

Shaping Tool Diameter
Up to 120 mm

Chuck Size
On request

Table Diameter
660 mm

Drummond Maxicut No. 2A Gear Shaper Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Drummond Maxicut No. 2A Gear Shaper Machine

Make - Drummond (England)

Model - Maxicut No. 2A

Max. Gear Diameter - 180 mm

Max. Module - 4 module

Max. Stroke Length - 50 mm

Stroke Rate - 160 strokes/min to 550 strokes/min

- Complete with its Change Gears, Lots of Cutters & other accessories.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/7sFktStoSwY

Robust Construction & High Precision

Built from heavy-duty cast iron, the Drummond Maxicut No. 2A Gear Shaper Machine is designed for stability and longevity. Its precision engineering allows consistent, high-quality output, meeting the exacting standards of modern gear manufacturing. The machine is adept at producing both internal and external gears, ensuring versatility in various industrial settings.

Advanced Lubrication & Adjustable Features

A centralized automatic lubrication system reduces maintenance interruptions and prolongs equipment life. With variable spindle speed (up to 80 RPM) and adjustable chuck sizes available upon request, this gear shaper is adaptable for different gear profiles and sizes. Users can choose between manual and automatic table feeds, optimizing operations based on specific requirements.

Flexible Applications & Efficient Performance

The Maxicut No. 2A supports a wide range of gear sizescapable of shaping gears with 6 to 400 teeth and diameters up to 510 mm. The semi-automatic mode and belt drive provide effective control and smooth operation over high-precision gear cutting. This makes the machine suitable for both small and large-scale production environments across the UK and beyond.

FAQs of Drummond Maxicut No. 2A Gear Shaper Machine:

Q: How does the Drummond Maxicut No. 2A Gear Shaper Machine operate for gear cutting?

A: The machine employs a reciprocating shaping tool, driven by a belt and powered by a 5 HP motor, to accurately cut both internal and external gears. Operators can select between manual and automatic table feeds for optimal control during gear shaping.

Q: What types of gears can be produced with this machine and what is the capacity?

A: You can produce both internal and external gears with the Maxicut No. 2A. It is capable of handling gear diameters up to 510 mm and can cut gears with 6 to 400 teeth, with a maximum cutting length of 180 mm.

Q: When is the table feed switched between manual and automatic modes?

A: The operating mode for the table feed depends on the precision required and production scale. Manual feed is ideal for custom or intricate gears, while automatic feed provides efficiency and consistency for larger production runs.

Q: Where is this machine typically used or installed?

A: The Drummond Maxicut No. 2A is commonly found in gear manufacturing plants, repair workshops, and facilities involved in the production of high-precision transmission components, particularly across the United Kingdom.

Q: What is the process for setting up the machine for a new gear-cutting job?

A: To set up, operators mount the correct chuck (available on request), adjust the shaping tool diameter (up to 120 mm), set spindle speed and feed mode, input the gear specifications, and ensure the centralized lubrication system is active before commencing gear shaping.

Q: How does the centralized automatic lubrication system benefit the user?

A: The centralized automatic lubrication system helps reduce the need for manual maintenance, ensuring continuous operation and prolonging the lifespan of key components by providing consistent lubrication to moving parts during operation.

Q: What are the main benefits of using the Drummond Maxicut No. 2A Gear Shaper Machine?

A: This machine offers robust construction, high precision, durability, and flexible operation modes. With its variable speed, automatic lubrication, and adaptability to different gear sizes, it enables efficient, reliable production of high-quality gears.
