DSG England Type 21 Heavy Duty Lathe Machine

Name: DSG England Type 21 Heavy Duty Lathe Machine
Brand: Liberty Metal & Machines Private Limited
Price: 55000 INR
Availability: InStock

Price 55000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

DSG England Type 21 Heavy Duty Lathe Machine Specification

Product Type
Heavy Duty Lathe Machine

Material
High Grade Cast Iron

Cutting Thickness
Up to 30 mm

Cutting Speed
Variable up to 900 RPM

CNC Or Not
Not CNC

Automatic Grade
Manual

Control System
Manual

Max. Swing Diameter
530 mm

Voltage
415 V

Weight (kg)
3800 kg

Dimension (L*W*H)
3700 mm x 1100 mm x 1400 mm

Capacity
Large and Heavy Jobs

Feature
Robust Construction, High Precision, Long Service Life

Color
Green

Application
Industrial Metal Turning

Power Source
Three Phase Electric

Centre Height
265 mm

Number of Speeds
16

Machine Type
DSG England Type 21

Bed Length
3000 mm

Chuck Size
400 mm

Distance Between Centres
2000 mm

Leadscrew Pitch
4 TPI

Spindle Bore
76 mm

Tailstock Quill Travel
175 mm

DSG England Type 21 Heavy Duty Lathe Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

DSG England Type 21 Heavy Duty Lathe Machine About

Make - Dean Smith & Grace (DSG) (England)

Model - Type 21

Center Height - 290 mm

Max. Length of Job - 1220 mm

Max. Job Diameter over Bed - 570 mm

Max. Job Diameter over Cross-Slide - 380 mm

Max. Job Diameter over Gap - 900 mm

Bed Width - 465 mm

Spindle Speeds - 7.5 rpm to 600 rpm

Spindle Bore - 92 mm

4-Jaw Chuck Diameter - 560 mm

3-Jaw Chuck Diameter - 400 mm

Faceplate Diameter - 510 mm

Spindle Motor - 12.5 HP

- With 4-Jaw Chuck, 3-Jaw Chuck, Faceplate, 2 x Steady.

- Removable Gap-Bed piece is also available.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/LGJaiGTBTxM

High Precision Industrial Lathe

The DSG England Type 21 is engineered for high precision and durability in demanding industrial settings. Its large bed length of 3000 mm and 3800 kg weight ensure steady performance during heavy-duty operations. With a centre height of 265 mm and tailstock quill travel of 175 mm, it meets the requirements of various metal turning jobs with consistent accuracy.

Versatile and Reliable Operation

This lathe machine features a manual control system, offering operators full command over 16 speed settings up to 900 RPM. Its variable cutting speeds and robust construction allow for reliable processing of different metals, supporting both high volume production and custom jobs. The three-phase electric power source further guarantees stable operation for industrial usage.

Built for Longevity and Heavy Loads

Manufactured using high-grade cast iron, the Type 21 is built to withstand continuous heavy-duty use. The 400 mm chuck size, 76 mm spindle bore, and long bed make it suitable for processing large workpieces with a cutting thickness of up to 30 mm. Its manual mechanics also simplify maintenance, extending the machines service life.

FAQs of DSG England Type 21 Heavy Duty Lathe Machine:

Q: How does the manual control system benefit operators of the DSG Type 21 Lathe?

A: The manual control system provides operators precise hands-on control over all machining parameters, allowing for immediate adjustments and versatile handling of different job types, ensuring greater accuracy in metal turning tasks.

Q: What types of industrial applications is this lathe machine suitable for?

A: The DSG England Type 21 is ideal for industrial metal turning applications, especially where processing large and heavy workpieces is required, such as production workshops, repair facilities, and custom manufacturing for metal components.

Q: When should the variable speed function be used on this lathe?

A: Operators should utilize the variable speed capability to match the spindle speed with the material and specific turning operation, ensuring optimal cutting performance and extending tool life.

Q: Where is the DSG Type 21 Heavy Duty Lathe primarily manufactured and used?

A: This machine is manufactured in the United Kingdom and is widely used by exporters, suppliers, manufacturers, and traders engaging in heavy-duty industrial metalworking both domestically and internationally.

Q: What is the process for setting up and operating this heavy-duty lathe machine?

A: Set up involves installing the lathe on a stable, level surface, connecting to a 415 V three-phase power source, and calibrating the manual controls. Operators then mount the workpiece in the chuck, select desired speed, and adjust the leadscrew and tailstock for precise turning operations.

Q: How does the robust construction enhance the machines service life?

A: Its high-grade cast iron body provides outstanding stability and resistance to vibrations, significantly reducing wear over time and contributing to the machines long service lifeeven under continuous heavy-duty operation.

Q: What are the main benefits of using the DSG England Type 21 lathe?

A: Key benefits include handling of large and heavy jobs, variable cutting speeds, robust and reliable operation, high precision, and straightforward manual controls, all contributing to efficient and long-lasting performance in industrial environments.
