Ernault Somua Precision Lathe Machine

Get a Price/Quote

MOQ : 1 Piece

Ernault Somua Precision Lathe Machine Specification

Product Type
Precision Lathe Machine

Material
Cast Iron Body with Hardened and Ground Bed

Cutting Thickness
Adjustable, up to 15 mm depending on material

Cutting Speed
Variable up to 2000 RPM

CNC Or Not
Conventional (Not CNC)

Automatic Grade
Semi-Automatic

Control System
Manual Lever & Knob Control

Max. Swing Diameter
400 mm

Voltage
415 V, 3 Phase

Weight (kg)
1700 kg

Dimension (L*W*H)
2450 x 1050 x 1300 mm

Capacity
Heavy Duty, up to 1500 mm between centers

Feature
High Precision, Hardened Bed, Quick Change Tool Post

Color
Machine Grey with Blue Accents

Chuck Size
250 mm (3 Jaw)

Bed Width
325 mm

Spindle Bore Diameter
52 mm

Spindle Speed Range
30 to 2000 RPM (16 steps)

Tailstock Quill Travel
180 mm

Main Motor Power
5 HP

Longitudinal Feed Range
0.04 2.00 mm/rev

Tailstock Quill Diameter
60 mm

Cross Slide Travel
275 mm

Noise Level
Below 80 dB

Coolant System
Integrated Coolant Pump

Distance Between Centers
1500 mm

Lead Screw Diameter/Pitch
32 mm / 6 mm

Lubrication System
Centralized Lubrication

Thread Cutting Range
Metric 0.5-14 mm, Inch 2-56 TPI

Surface Finish
RA < 2.5 m

About Ernault Somua Precision Lathe Machine

Make - H. Ernault Somua (France)

Model - Cholet 435
Center Height - 205 mm
Length of Job - 1100 mm
Max. Swing over Bed - 410 mm
Max. Swing over Cross-Slide - 240 mm
Bed Width - 310 mm
Spindle Speeds - 32 rpm to 1600 rpm
Spindle Bore - 55 mm
Chuck Diameter - 250 mm
With Micro Feed Arrangement for Cross-Slide Movement for Precision Turning.
Complete with spare tool holders, face plate, leveling pads etc.
Machine is in excellent working condition.

High Precision Machining for Versatile Applications

This lathe delivers reliable surface finishes, adjustable cutting thickness up to 15 mm, and accommodates various materials thanks to its sturdy cast iron body and hardened bed. The centralized lubrication and integrated coolant systems optimize operation, safeguarding both machinery and workpiece. Ideal for workshops and industry settings.

User-Friendly Manual Controls and Semi-Automatic Operation

With its manual lever and knob controls, operators have fine control over parameters, including spindle speed, feed rate, and threading. The quick-change tool post expedites setup, while the spacious work area and ergonomic design improve workflow for detailed and repetitive jobs.

Efficient Thread Cutting and Feeding Capabilities

The machine supports a broad thread cutting rangemetric (0.514 mm) and inch (256 TPI)with longitudinal feed from 0.04 to 2.00 mm/rev, enabling precise and diverse threading and turning operations. Tailstock quill travel (180 mm) and generous cross slide movement facilitate adaptability to different job requirements.

FAQs of Ernault Somua Precision Lathe Machine:

Q: How does the Ernault Somua Precision Lathe Machine ensure a high-quality surface finish?

A: The machine features a hardened and ground bed, supported by a centralized lubrication system and integrated coolant pump, maintaining optimal temperature and lubrication. These qualities help achieve a surface finish of RA < 2.5 m.

Q: What is the process for threading on this lathe?

A: Threading is facilitated through manual lever and knob controls, with the machine supporting metric threads from 0.514 mm and inch threads from 256 TPI. Users select from 16 spindle speed steps and adjust feeds accordingly for precise results.

Q: Where can this lathe machine be used, and what materials can it process?

A: It is suitable for heavy-duty workshops, manufacturing units, and industrial settings. The cast iron body and adjustable cutting parameters allow processing a wide variety of ferrous and non-ferrous metals.

Q: When is it beneficial to use this model over a CNC lathe?

A: This conventional, semi-automatic lathe is ideal when manual precision, rapid setup changes, and tactile control are preferredespecially for custom, one-off jobs or environments where CNC automation is not needed.

Q: What are the main features that support heavy-duty operation?

A: Key features include a 1500 mm distance between centers, 5 HP motor, robust cast iron body, hardened and ground bed, and quick change tool postall designed for reliable, heavy-duty use.

Q: How does the integrated coolant system improve machine performance?

A: The integrated coolant pump actively reduces heat during machining, preserves tool life, and enhances surface quality, supporting consistent performance in prolonged operations.

Q: What benefits do users gain from the centralized lubrication system?

A: Centralized lubrication ensures even oil distribution to critical moving parts, reducing wear, minimizing maintenance, and prolonging the machines operational lifespan.
