Famup Italy Automatic Drilling and Tapping Machine

Send Inquiry

Request To Call Back

Famup Italy Automatic Drilling and Tapping Machine

Name: Famup Italy Automatic Drilling and Tapping Machine
Brand: Liberty Metal & Machines Private Limited
Price: 300000 INR
Availability: InStock

Price 300000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Famup Italy Automatic Drilling and Tapping Machine Specification

Spindle Speed
902800 RPM (variable)

Condition
New

Features
High repeatability, rigid construction, high-speed operation, user-friendly controls

Diameter
Drilling 20 mm; Tapping M16

Motor Power
2 HP

Frequency
50 Hz

Noise Level
Low

Table Size
400 x 400 mm

Cutting Area
Adjustable with table traverse movement

Machine Type
Automatic Drilling and Tapping

Dimension (L*W*H)
1200 x 800 x 1700 mm

Product Type
Automatic Drilling and Tapping Machine

Material
Heavy Duty Cast Iron Body

Computerized
No

Automatic Grade
Automatic

CNC Or Not
Not CNC

Control System
Electromechanical

Voltage
415 V

Power
2 HP

Power Source
Electric

Weight (kg)
Approx. 450 kg

Capacity
Drilling up to 20 mm; Tapping up to M16

Color
Famup Standard Grey/Green

Usage & Applications
For precise drilling and tapping operations in industrial manufacturing, workshops, and plant maintenance

Safety Features
Emergency stop, spindle guard, overload protection

Number of Spindle Speeds
8 or 16-speed gearbox

Mounting Type
Floor Mounted

Quill Travel
120 mm

Coolant Pump
Integrated

Chuck Size
316 mm

Feed Type
Automatic and Manual Option

Famup Italy Automatic Drilling and Tapping Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Famup Italy Automatic Drilling and Tapping Machine

Make - Famup (Italy)

Model - TCS 40

Drilling Capacity - 40 mm

Spindle Diameter - 70 mm

Spindle Travel - 130 mm

Spindle Taper - MT 4

Table Size - 800 mm x 255 mm

XYZ Travel of Table - 650 mm x 250 mm x 550 mm

Max. Distance between Table & Spindle - 650 mm

Spindle Speeds - 64 rpm to 2340 rpm

Spindle Feed Travel Rates - 0.05 / 0.10 / 0.20 mm/revolution

- Features like Automatic Drilling Cycle including Rapid Up/Down Travel of Spindle.

- Suitable for Drilling, Tapping, Boring, Milling, Reaming operations.

- Complete with Coolant Pump & Tank.

- Universal type Rotating Table.

- Operating Manual & Electrical Drawings are available.

- Complete with Vice, Tooling & many other accessories.

- Equipped with a 2-Axis DRO.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/VrRKqDqCbt0

Precision at Its Core

Designed by Famup Italy, this automatic drilling and tapping machine delivers unmatched precision for industrial applications. Its rigid construction, high repeatability, and table traverse movement provide flexibility and control, making it suitable for complex manufacturing requirements.

Efficiency with Safety

Outfitted with safety features such as an emergency stop, spindle guard, and overload protection, the machine ensures secure operation for users. Automatic and manual feed options, together with integrated coolant, ensure smoother workflow and longer tool life.

Versatile Industrial Applications

This equipment is perfect for workshops, factories, and maintenance departments needing reliable drilling and tapping capacity. Suitable for heavy-duty environments, it supports adjustable cutting areas and variable speed, accommodating diverse materials and processes.

FAQs of Famup Italy Automatic Drilling and Tapping Machine:

Q: How does the Famup Automatic Drilling and Tapping Machine enhance operational accuracy?

A: The machines electromechanical control system, high repeatability, and precise spindle speeds ranging from 90 to 2800 RPM enable consistent, accurate drilling and tapping operations across various industrial applications.

Q: What are the available feed options for this machine?

A: Operators can choose between automatic and manual feed options, allowing flexibility depending on the complexity and precision required by the task.

Q: Where is this machine most commonly used?

A: Ideal environments include manufacturing plants, workshops, and plant maintenance settings where precise and repetitive drilling and tapping operations are essential.

Q: What safety mechanisms are integrated into the machine?

A: Safety features include an emergency stop button, spindle guard, and overload protection system, ensuring safe operation during use.

Q: What is the process for adjusting spindle speeds?

A: The machine is equipped with either an 8 or 16-speed gearbox, allowing users to select and fine-tune spindle speeds from 90 to 2800 RPM to securely process different materials and thicknesses.

Q: What benefits does the integrated coolant pump provide during operation?

A: The integrated coolant pump helps maintain optimal tool temperature, reduces wear, and enhances both tool longevity and cutting quality during high-speed operations.
