FAS Glowno 400 mm x 800 mm Surface Grinder

Send Inquiry

Request To Call Back

FAS Glowno 400 mm x 800 mm Surface Grinder

Name: FAS Glowno 400 mm x 800 mm Surface Grinder
Brand: Liberty Metal & Machines Private Limited
Price: 23000 INR
Availability: InStock

Price 23000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

FAS Glowno 400 mm x 800 mm Surface Grinder Specification

Rotation
Clockwise

Model
FAS Glowno 400x800

Product Type
Surface Grinder

General Use
Precision Surface Grinding

Material
Cast Iron, Steel

Type
Manual Surface Grinder

Capacity
Heavy Duty

Weight (kg)
Approx. 3200 kg

Computerized
No

Automatic
No

CNC Or Not
Not CNC (Conventional)

Control System
Manual

Table Size
400 mm x 800 mm

Table Slide Way
V and Flat

Magnetic Chuck Size
400 mm x 800 mm

Grinding Wheel Size
350 mm x 40 mm x 127 mm

Grinding Wheel Speed
1450 RPM

Grinding Length
800 mm

Floor Space
2500 mm x 2300 mm

Fuel Tank Capacity
60 L

Spindle Speed
1800 RPM

Power
7.5 HP

Voltage
415 V

Dimension (L*W*H)
2500 mm x 2300 mm x 2200 mm

Feature
High Rigidity, Precision Ground

Color
Blue & White

Cross Feed Graduation
0.01 mm

Spindle Motor Power
7.5 HP

Grinding Accuracy
±0.002 mm

Table Drive
Hydraulic & Manual

Work Table Movement
Hydraulic

Work Table Load Capacity
800 kg

Working Speed
Variable, Table Traverse up to 25 m/min

Main Motor Type
Induction Motor

Chuck Type
Electro-Magnetic

Coolant System
Integrated Coolant Pump

Standard Accessories
Wheel Balancer, Wheel Flange, Diamond Dresser, Toolkit, Manual

Vertical Feed Graduation
0.005 mm

Lubrication System
Automatic Lubrication

Max Grinding Height
450 mm

Hydraulic System
Included

FAS Glowno 400 mm x 800 mm Surface Grinder About

Make - FAS-Glowno (Poland)

Model - SPG 40 x 80

Magnet Size - 400 mm x 800 mm

Grinding Wheel Size - Diameter 400 mm x 75 mm Width

Cross Travel - 425 mm

Longitudinal Travel of Table - 925 mm

Max. Distance b/w Magnet Top to Wheel-Axis - 500 mm

Least Count - 1 Micron

- Equipped with top mounted Hydraulic Wheel Dresser.

- Micro-Feed Adjustments in Vertical & Cross Travels.

- Features like Automatic Depth Adjustment "Auto-Cut".

- Machine is in excellent working condition.

Video Link - https://youtu.be/r8QnccrQ1A8

Engineered for Precision and Heavy-Duty Performance

This surface grinder is designed for those who require reliable accuracy and substantial work capacity. With hydraulic table movement and integrated cooling, it ensures smooth, precise operations and extended machine life. The robust 3200 kg structure and precision ground components make it particularly effective for heavy industrial tasks involving cast iron or steel.

User-Friendly Manual Controls and Automatic Systems

While the FAS Glowno 400x800 is manual in operation, it streamlines work with features like automatic lubrication and hydration, minimizing user intervention. Its manual controls offer tactile precision, while the integrated coolant pump and electro-magnetic chuck improve workpiece quality and ease of handling.

FAQs of FAS Glowno 400 mm x 800 mm Surface Grinder:

Q: How does the automatic lubrication system benefit the FAS Glowno 400x800 Surface Grinder?

A: The automatic lubrication system ensures consistent and optimal distribution of lubricants to moving parts, minimizing friction and wear. This extends the machines lifespan, maintains high operational accuracy, and reduces the frequency of manual maintenance.

Q: What materials can be processed with this surface grinder?

A: The FAS Glowno 400x800 is designed to handle heavy-duty materials such as cast iron and steel. Its high rigidity and surface precision make it ideal for demanding industrial grinding tasks.

Q: When should the coolant system be used during grinding operations?

A: The integrated coolant pump should be active whenever grinding is underway. This helps to dissipate heat, prevent workpiece distortion, and extend grinding wheel life, ensuring high-quality surface finishes.

Q: Where is the FAS Glowno 400x800 recommended for installation?

A: This surface grinder is best installed in large industrial workshops or manufacturing plants. It requires ample floor space (2500 mm x 2300 mm) and access to a 415 V power supply for optimal operation.

Q: What is the process for adjusting the grinding accuracy and feed rates?

A: Manual controls allow operators to finely adjust cross feed (graduation 0.01 mm) and vertical feed (graduation 0.005 mm) for precise grinding. Variable working speed and hydraulic/manual table movement support customization per workpiece requirements.

Q: How does the electro-magnetic chuck function in the grinding process?

A: The electro-magnetic chuck securely holds ferrous workpieces in place during grinding. This ensures stable, precise operations, reduces manual clamping time, and minimizes vibration, resulting in smoother finishes.
