Foradia 50 mm Radial Drilling Machine

Price 8000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Foradia 50 mm Radial Drilling Machine Specification

Spindle Speed
702000 RPM

Noise Level
Low

Frequency
50 Hz

Dimension (L*W*H)
2200 x 900 x 2450 mm

Table Size
500 x 500 mm

Condition
New

Diameter
50 mm

Cutting Area
Large

Motor Power
3 HP

Features
Heavy duty construction, Geared head, Adjustable arm, High precision, Easy operation

Machine Type
Heavy Duty Radial Drilling

Product Type
Radial Drilling Machine

Material
Cast Iron

Computerized
No

Automatic Grade
Semi-Automatic

CNC Or Not
No

Control System
Manual

Voltage
415 V

Power
3 HP

Power Source
Electric

Weight (kg)
Approx. 1500 kg

Capacity
50 mm

Color
Green

Usage & Applications
Drilling, Boring, Reaming, Tapping in industrial metalworking

About Foradia 50 mm Radial Drilling Machine

Make - Foradia-Olcina (Spain)

Model - GH 50-1000

Drilling Capacity - 50 mm

Spindle Diameter - 80 mm

Arm Length - 1070 mm

Spindle Taper - MT 4

Spindle Speeds - 35 rpm to 1460 rpm

Spindle Feed Rate - 0.05 mm/rev to 0.35 mm/rev

Spindle Feed Travel - 245 mm

Vertical Travel of Arm - 575 mm

Table Size - 800 mm x 500 mm

Clamping Type - Manual

- Machine is in excellent working condition.

Video link - https://youtu.be/G19lvV5Olyg

Heavy Duty Construction

Built from premium cast iron, the Foradia 50 mm Radial Drilling Machine offers exceptional durability and stability. Its sturdy frame minimizes vibrations, ensuring precise results in demanding industrial drilling applications. The hydraulic clamping further enhances operational security and efficiency, allowing for steady work even with tougher metals and larger workpieces.

Precision and Versatility

The adjustable arm and column diameter of 250 mm allow for high-accuracy positioning, essential for complex drilling, boring, and tapping. Its maximum spindle travel of 250 mm and large base plate (1000 x 700 mm) accommodate substantial materials, making it suitable for wide-ranging industrial production needs and custom projects.

User-Friendly Operation

Operators benefit from its manual control system, straightforward interface, and semi-automatic operations. The geared head, low noise levels, and efficient coolant system contribute to a comfortable and safe work environment. The machine is easy to maintain and offers reliable performance even in continuous-use scenarios.

FAQs of Foradia 50 mm Radial Drilling Machine:

Q: How do you operate the Foradia 50 mm Radial Drilling Machine for maximum efficiency?

A: To maximize efficiency, ensure proper clamping using the hydraulic system, set the desired spindle speed (from 8 levels, 702000 RPM), and position the workpiece securely on the large base plate. Adjust the arm and spindle for optimal drilling angle and depth before starting the operation.

Q: What materials is this machine best suited for drilling?

A: The machine is ideal for drilling steel and other metals due to its heavy-duty build and 50 mm drilling capacity. It is also suitable for boring, reaming, and tapping applications in various industrial metalworking projects.

Q: When should the coolant system be used during drilling operations?

A: The integral coolant system should be activated during extended drilling, boring, or reaming operations to reduce heat buildup, prevent tool wear, and enhance cutting performance, especially when working with harder metals or deeper bores.

Q: Where is the Foradia 50 mm Radial Drilling Machine typically installed?

A: It is commonly installed in industrial manufacturing plants, metalworking workshops, and fabrication units. The sizeable dimensions and weight require a stable, level floor space with sufficient load-bearing capacity.

Q: What process does the hydraulic clamping system support?

A: The hydraulic clamping securely fastens the workpiece or arm, ensuring safety and stability during drilling processes, reducing vibration, and allowing for consistent, high-precision results.

Q: How does using this machine benefit industrial operations?

A: Benefits include increased productivity from its large cutting area, high drilling precision from its adjustable features, long-term durability, low operational noise, and easy maintenance. Its power and versatility streamline multiple metalworking processes, improving overall workflow.
