G. Rastelli 300 mm x 600 mm Surface Grinder

Send Inquiry

Request To Call Back

G. Rastelli 300 mm x 600 mm Surface Grinder

Price 100000 INR/ Piece

Get a Price/Quote

G. Rastelli 300 mm x 600 mm Surface Grinder Specification

Model
G. Rastelli Surface Grinder

Rotation
Grinding Wheel Rotation Clockwise

Product Type
Surface Grinder

General Use
Industrial Surface Grinding

Material
Cast Iron

Type
Vertical Surface Grinder

Capacity
300 mm x 600 mm

Weight (kg)
Approx. 2000 kg

Computerized
No

Automatic
No

CNC Or Not
Not CNC

Control System
Manual

Table Size
300 mm x 600 mm

Table Slide Way
V and Flat

Magnetic Chuck Size
300 mm x 600 mm

Grinding Wheel Size
180 mm x 13 mm x 31.75 mm

Grinding Wheel Speed
2800 RPM

Grinding Length
600 mm

Floor Space
2400 mm x 1400 mm

Fuel Tank Capacity
40 Liters (Hydraulic Tank)

Spindle Speed
2800 RPM

Power
2 HP

Voltage
220/415 V

Dimension (L*W*H)
2400 mm x 1400 mm x 1800 mm

Feature
Precision Surface Finish, Heavy-Duty Construction

Color
Blue & White

G. Rastelli 300 mm x 600 mm Surface Grinder Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About G. Rastelli 300 mm x 600 mm Surface Grinder

Make - G. Rastelli (Italy)

Model - RT1

Capacity - 300 mm x 600 mm

Grinding Wheel Diameter - 300 mm

Grinding Wheel Width - 38 mm

Longitudinal Travel - 670 mm

Cross Travel - 340 mm

Max. Height between Magnet Top to Wheel Center - 435 mm

Current Magnet Size - 200 mm x 600 mm

- Equipped with a Wheel-Top mounted Hydraulic Wheel Dresser.

- Features like Automatic Depth Adjustment "Auto-Cut"

- Complete with Wheel Balancing stand and other accessories.

- Motorised Vertical Travel of the Wheel-Head.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/3rivlGWPEmM

Superior Surface Finish and Grinding Accuracy

Achieve exceptional surface finishes up to Ra 0.4 m and maintain grinding accuracy within 0.005 mm/m, making the G. Rastelli Surface Grinder well-suited for precise manufacturing tasks. Its robust engineering and finely graduated controls support exacting standards in modern industrial environments.

Heavy-Duty Construction for Industrial Demands

Built from high-grade cast iron and weighing approximately 2000 kg, this surface grinder offers substantial stability and vibration dampening. The 300 mm x 600 mm table size and 250 kg load capacity accommodate a wide range of workpieces, supporting reliable and efficient grinding for extended operations.

Efficient Hydraulic and Lubrication Systems

Benefit from automatic lubrication and a hydraulic table movement, which minimize manual maintenance and ensure smooth, uninterrupted table travel. These features contribute to a long service life and consistent grinding performance even during intensive industrial use.

FAQs of G. Rastelli 300 mm x 600 mm Surface Grinder:

Q: How does the hydraulic table movement benefit the operator during surface grinding?

A: The hydraulic table movement allows for smooth and consistent longitudinal motion during grinding, reducing operator fatigue and enhancing process precision. It eliminates manual effort, ensuring repeatable results and improving efficiency, especially during long production runs.

Q: What is the maximum workpiece that can be loaded on the surface grinders table?

A: The G. Rastelli surface grinder supports a table load capacity of up to 250 kg, which makes it suitable for handling sizable and heavy workpieces commonly encountered in industrial grinding applications.

Q: When should the lubrication system be maintained?

A: The automatic lubrication system is designed for continuous and reliable function, but regular checks are recommendedideally before each shiftto ensure adequate lubricant levels and system integrity for long-term, trouble-free operation.

Q: Where can this surface grinder be installed in a manufacturing facility?

A: With its floor space requirement of 2400 mm x 1400 mm, the surface grinder can be installed in most standard machining shops or manufacturing facilities. Ensure sufficient space around the machine for operation, maintenance, and material handling.

Q: What process steps are involved in operating the grinder manually?

A: Operation involves securing the workpiece to the magnetic chuck, setting feed rates using graduated dials for cross and vertical movements (0.01 mm/div), switching on hydraulics, coolant, and spindle, and manually controlling the grinding cycle while monitoring the process parameters for precision output.

Q: How does the machine achieve such a fine surface finish?

A: High rotational speed (2800 RPM), a stable cast iron frame, precision slide ways (V and flat design), and an efficient coolant system enable the grinder to deliver an ultra-smooth surface finish up to Ra 0.4 m consistently across a variety of materials.

Q: What benefits does this model offer for industrial exporters and manufacturers?

A: The G. Rastelli Surface Grinder is engineered for reliability, accuracy, and versatility. Its durable build, precise controls, and support for heavy-duty industrial loads make it a valuable addition for exporters, manufacturers, and suppliers aiming to deliver high-quality, precision-ground components.
