Gambin 3M Universal Milling Machine

Name: Gambin 3M Universal Milling Machine
Brand: Liberty Metal & Machines Private Limited
Price: 30000 INR
Availability: InStock

Price 30000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Gambin 3M Universal Milling Machine Specification

Rotation
Spindle Both Directions

Model
Gambin 3M

Product Type
Universal Milling Machine

General Use
Industrial Milling Operations

Material
Cast Iron Body

Type
Horizontal & Vertical

Capacity
Heavy Duty

Weight (kg)
Approx 3500 kg

Computerized
No

Automatic
Semi Automatic

CNC Or Not
Not CNC

Control System
Manual

Table Size
1600 mm x 400 mm

Table Slide Way
Double V and Flat

Floor Space
2500 mm x 2000 mm approx

Spindle Speed
35 to 1400 rpm (variable) approx

Power
7.5 HP / 5.5 kW

Voltage
415 V / 3 Phase

Dimension (L*W*H)
Approx 2500 mm x 2000 mm x 2100 mm

Feature
Swivelling Table, Universal Head, Rigid Structure

Color
Green/Grey

Overarm Travel
250 mm

Lubrication System
Centralized

Rapid Feed
Available

Table Longitudinal Travel
1200 mm

Number of Feed Rates
18

Main Motor
7.5 HP

Maximum Workpiece Weight
700 kg

Swivel Angle of Universal Table
+/- 45 degrees

Spindle Taper
ISO 50

Table Vertical Travel
400 mm

Coolant System
Provided

Table Cross Travel
400 mm

Quill Travel
100 mm

Condition
Used/Refurbished

Gambin 3M Universal Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Gambin 3M Universal Milling Machine

Make - Gambin (France)

Model - 3M

Table Size - 1520 mm x 385 mm

XYZ Travel - 1000 mm x 420 mm x 710 mm

Spindle Speeds - 25 rpm to 2000 rpm

Table Feed Rates - 12 mm/min to 630 mm/min

Spindle Taper - ISO 40

- Equipped with a 3-Axis DRO.

- Double-Swivel type Universal Milling Head.

- With Horizontal RAM travel in the Milling Head.

- Complete with Bracket for Horizontal Milling.

- Operating Manuals, Electrical Drawings etc. are available.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/rdrmxuH_Qto

Heavy-Duty Construction and Precision

Built from high-quality cast iron, the Gambin 3M ensures excellent stability and vibration dampening during milling. The double V and flat slide ways provide accurate table movement for precise machining, while the universal head and swivelling table enhance operational flexibility. Designed to withstand frequent industrial use, the machines structure supports demanding milling processes.

Versatile Milling Operations

With both horizontal and vertical capabilities, the Gambin 3M adapts to a multitude of milling tasks. The universal table swivels +/-45, supporting complex operations, while the ISO 50 spindle taper accommodates a broad range of tooling. Rapid feed and centralized lubrication systems further streamline workflow, making this milling machine ideal for varied industrial environments.

FAQs of Gambin 3M Universal Milling Machine:

Q: How is the Gambin 3M Universal Milling Machine typically used in industrial settings?

A: The Gambin 3M is primarily utilized for milling operations that require precision and flexibility. Its ability to work both horizontally and vertically, alongside a swivelling universal table, facilitates cutting, slotting, drilling, and shaping of large or complex workpieces.

Q: What are the main benefits of the Gambin 3Ms swivelling universal table?

A: The swivelling universal table, with a +/-45 angle range, allows operators to perform angled cuts and multi-face machining without repositioning the workpiece, thereby increasing productivity and enabling more intricate operations.

Q: When should you use rapid feed on the Gambin 3M Milling Machine?

A: Rapid feed is particularly useful when positioning the table or spindle quickly between milling operations, saving setup time and increasing overall efficiency during production runs.

Q: Where is the Gambin 3M best installed considering its floor space requirements?

A: Given its approximate dimensions of 2500 mm x 2000 mm x 2100 mm, the Gambin 3M should be installed in a spacious industrial workshop with adequate room for operator access, workpiece handling, and maintenance activities.

Q: What is the process for changing spindle speed on the Gambin 3M?

A: Spindle speed can be varied between 35 to 1400 rpm, typically via manual adjustment of control levers. This versatility enables optimal cutting conditions for different materials and tooling requirements.

Q: How does the centralized lubrication system improve machine operation?

A: The centralized lubrication system ensures all critical moving components receive consistent and adequate lubrication, reducing wear, minimizing maintenance, and promoting smoother machine operation.

Q: Why is the Gambin 3M suitable for heavy-duty industrial use?

A: Its rigid cast iron construction, high load capacity (up to 700 kg), robust spindle, and universal head make the Gambin 3M ideal for demanding environments where precision and durability are essential.
