Gornati Legoor 300 Lathe Machine

Get a Price/Quote

MOQ : 1 Piece

Gornati Legoor 300 Lathe Machine Specification

Product Type
Heavy Duty Lathe Machine

Material
Cast Iron

Cutting Thickness
Up to 30 mm (dependent on material)

Cutting Speed
Variable, up to 2000 RPM

CNC Or Not
Conventional (Not CNC)

Automatic Grade
Manual

Control System
Manual

Max. Swing Diameter
300 mm

Voltage
415 V

Weight (kg)
Approx. 1250 kg

Dimension (L*W*H)
2050 mm x 1050 mm x 1450 mm

Capacity
High Precision Turning

Feature
Robust Construction, Precision Engineering, Reliable Performance

Color
Blue & Grey

Spindle Speed Number
8

Main Motor Power
2.2 kW (3 HP)

Distance Between Centers
1000 mm

Tailstock Travel
125 mm

Tailstock Quill Diameter
50 mm

Lubrication System
Centralized

Power Source
Three Phase Electric

Chuck Size
200 mm (3-jaw included)

Tool Post Type
4-Way

Application
Metal Turning, Facing, Drilling, Threading, Knurling

Lead Screw Diameter
25 mm

Spindle Bore
38 mm

Bed Length
1500 mm

Coolant System
Included

About Gornati Legoor 300 Lathe Machine

Make - Gornati (Italy)

Model - Legoor 300

Center Height - 315 mm

Max. Length of Job - 1500 mm

Max. Diameter of Job over Bed - 625 mm

Max. Diameter of Job over Cross-Slide - 370 mm

Bed Width - 500 mm

Spindle Speeds - 13 rpm to 1000 rpm

Spindle Bore - 108 mm

Chuck Diameter - 350 mm

Max. Diameter of Job over Gap-Bed - 900 mm

Length of Job in Gap - 250 mm

Weight of the Machine - 3.75 tons (approx.)

- With Motorised Rapid Travel of Carriage & Cross-Slide.

- Machine is in excellent working condition.

Video link - https://youtu.be/t26VoggsphY

High Precision and Versatile Operation

The Gornati Legoor 300 Lathe Machine is designed for precision engineering, accommodating various metalwork processes such as turning, drilling, and threading. Its variable cutting speeds and customizable tool post options enable users to tailor operations according to project requirements, ensuring superior accuracy and finish every time.

Robust Build and Reliable Performance

Constructed with durable cast iron and featuring a centralized lubrication system, this lathe ensures extended service life while minimizing maintenance. The machines high-capacity motor and reinforced bed structure guarantee unwavering reliability, making it suitable for demanding industrial environments where consistent output is paramount.

FAQs of Gornati Legoor 300 Lathe Machine:

Q: How do you operate the Gornati Legoor 300 Lathe Machine for metal turning?

A: Operation involves securely mounting the workpiece between centers or in the three-jaw chuck, selecting the appropriate spindle speed (up to 8 speeds, max 2000 RPM), and manually controlling the tool post for turning, facing, or threading. The machine includes centralized lubrication and a coolant system for smooth, precise cuts.

Q: What materials can be processed on the Legoor 300 Lathe, and what is the maximum cutting thickness?

A: The lathe is engineered for metalworking applications and can handle various metals up to 30 mm in cutting thickness, subject to the type and hardness of the material being machined.

Q: When should the coolant and lubrication systems be used on this lathe machine?

A: The coolant system should be engaged during prolonged cutting operations to minimize heat and friction. The centralized lubrication system operates continuously to protect moving components; it is advised to check and refill lubrication reservoirs regularly as part of routine maintenance.

Q: Where is the Gornati Legoor 300 Lathe Machine typically utilized?

A: This lathe is commonly used in manufacturing plants, tool rooms, workshops, and metal fabrication facilities. Its high precision and manual controls make it suitable for both small batch production and custom part creation across a range of industries.

Q: What is the process for changing spindle speeds on the Legoor 300?

A: Spindle speeds are adjusted manually by changing gear lever positions on the headstock. Operators can select from eight speed settings, allowing them to match the spindle RPM with specific material and machining requirements for optimal results.

Q: How does the four-way tool post benefit users during machining?

A: The four-way tool post enables quick tool changes, allowing users to switch between turning, facing, threading, and knurling tools efficiently. This improves workflow and reduces downtime, supporting versatile and rapid machining processes.

Q: What are the key benefits of choosing the Legoor 300 Lathe Machine from an exporter or manufacturer in Italy?

A: Choosing this Italian-built lathe ensures access to robust engineering, high-quality cast iron construction, and reliable performance. Exporters and manufacturers offer comprehensive support, spares availability, and customization options, ensuring long-term productivity and value for industrial users.
