Graziano 1500 mm CNC Lathe Machine

Get a Price/Quote

Graziano 1500 mm CNC Lathe Machine Specification

Product Type
CNC Lathe Machine

General Use
Metal Turning, Precision Engineering

Material
Cast Iron Body

Type
Horizontal Lathe

Capacity
1500 mm turning length

Weight (kg)
2800 kg

Computerized
Yes

Automatic
Fully Automatic

PLC Control
Available

Bar Feeder
Yes

Power Source
Electric

Power Consumption
7.5 kW

Rigidity
High

Voltage
220-415 V

Motor
High precision 3-phase motor

Table Size
1500 mm

Spindle Speed
30 - 2500 RPM

Axial Choice
2 axis

Dimension (L*W*H)
3200 mm x 1300 mm x 1500 mm

Feature
Heavy Duty, High Accuracy, Rapid Traverse

Color
Industrial Grey

About Graziano 1500 mm CNC Lathe Machine

With an experience of many years, we are engaged in manufacturing and supplying a wide range of CNC Lathe Machine. This is manufactured by making use of high grade materials under the supervision of our deft team of technocrats. It is able to move along multiple axes, and can create a variety of shapes, slots and holes. The offered machine is extremely useful because it is able to produce shapes that would be nearly impossible using manual tooling methods. Further, clients can avail this CNC Lathe Machine from us in various models and specifications at affordable rates.

Features:

Hassle-free functionality
Sturdy construction
Low power consumption

CNC Lathe Machine- Graziano - 1500 mm

Make - Graziano (Italy)
Model - SAG 210 XZC
Centre Height - 220 mm
Distance between Centers - 1500 mm
Swing over bed - 440 mm
Swing over cross-slide - 230 mm
Centre Height in Gap - 275 mm
Length in Gap - 180 mm
Automatic Tool Post - 1 no. * 4 tools
Current CNC Control - S ag 210 xzc (new can also be installed)

Advanced Control for Precision Engineering

This lathe leverages Siemens or Fanuc controllers combined with PLC control and touch screen panels, making programming and operations intuitive. The repeatability of 0.01 mm and 2-axis control support complex machining with unwavering precision, vital in applications requiring tight tolerances and consistent output.

Robust Build and High Rigidity

Constructed from industrial-grade cast iron, the Graziano lathe boasts a broad bed width of 330 mm and hardened ground guideways. High rigidity minimizes vibration and deformation, delivering stable, precise results even during heavy-duty operations on metal workpieces.

Integrated Automation for Efficiency

Features like the 4-station automatic tool post, automatic centralized lubrication, rapid traverse rate of 10 m/min, and integrated bar feeder help streamline workflow. These integrated systems ensure higher efficiency, reduced manual intervention, and extended machine life, making the lathe an asset for any manufacturer or exporter.

FAQs of Graziano 1500 mm CNC Lathe Machine:

Q: How does the Graziano 1500 mm CNC Lathe Machine enhance machining accuracy?

A: The Graziano lathe achieves high accuracy through its servo drive system, hardened and ground guideways, and a repeatability of 0.01 mm. The combination of Siemens or Fanuc industrial controllers, touch screen operational panel, and automatic lubrication system further ensures consistent and precise machining processes.

Q: What type of materials and workpieces can be handled by this CNC lathe?

A: This machine is engineered with a heavy-duty, cast iron body and is designed for high-rigidity operations. It excels in metal turning applications and is suitable for precision engineering involving steel, alloys, and other industrial metals, supporting up to 1500 mm turning length with a maximum swing over the bed of 400 mm.

Q: When is foundation installation required for this machine?

A: A solid foundation is essential during machine installation to ensure operational stability, minimize vibrations, and maintain high accuracy. It is required prior to commissioning the lathe for the first time, especially for industrial, exporter, or manufacturer setups.

Q: Where can the Graziano 1500 mm CNC Lathe Machine be utilized?

A: This lathe is ideal for industrial environments such as machining workshops, component manufacturing plants, and precision engineering facilities. It is well-suited for exporters, manufacturers, suppliers, and traders across India or globally who demand consistent, high-precision metal turning capabilities.

Q: What is the process for automatic tool changes on this lathe?

A: The machine features a 4-station automatic tool post, which allows programmed, rapid tool changes without manual intervention. Operators can pre-load up to four different tools, optimizing cycle times and supporting complex sequences in unmanned CNC operations.

Q: How is operator safety and working environment considered in this CNC lathe?

A: The Graziano lathe operates below 75 dB(A), minimizing noise pollution and enhancing workplace comfort. The automatic centralized lubrication and coolant system also reduce operator exposure to lubricants and heat, promoting a safer, cleaner work environment.

Q: What are the key benefits of using this CNC lathe for exporters or manufacturers?

A: Users benefit from high precision, reliability, reduced downtime, and improved workflow automation. The machines durability, integrated automation systems, and user-friendly control panel help exporters and manufacturers scale production, maintain quality, and respond quickly to diverse machining requirements.
