Graziano Italy 3000 mm Thread Milling Machine

Send Inquiry

Request To Call Back

Graziano Italy 3000 mm Thread Milling Machine

Name: Graziano Italy 3000 mm Thread Milling Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Graziano Italy 3000 mm Thread Milling Machine Specification

Model
Graziano Italy 3000 mm

Rotation
Spindle Rotates Clockwise & Counterclockwise

Product Type
Thread Milling Machine

General Use
Thread Milling for Various Industrial Applications

Material
Cast Iron Body

Type
Horizontal Thread Milling

Capacity
Up to 3000 mm Thread Length

Weight (kg)
Approx. 6500 kg

Computerized
No

Automatic
No

CNC Or Not
No

Control System
Manual

Table Size
400 mm x 320 mm approx.

Table Slide Way
V & Flat

Floor Space
4800 mm x 1400 mm approx.

Spindle Speed
Approx. 20 - 400 RPM (Variable)

Power
7.5 kW

Voltage
415 V / 50 Hz / 3 Phase

Dimension (L*W*H)
Approx. 4800 mm x 1400 mm x 1700 mm

Feature
Heavy Duty, Rigid Construction

Color
Industrial Green

Longitudinal Travel
3000 mm

Coolant System
Provided

Lead Screw Diameter
45 mm

Thread Pitch Range
1 mm to 50 mm

Lubrication
Centralized

Working Speed
Variable control

Chuck Type
3 Jaw Chuck

Max Thread Length
3000 mm

Accessories Supplied
Standard change gears set, Centres, Chuck Key, Tool Holder set

Max Workpiece Diameter
380 mm

Lead Screw Pitch
6 mm

Condition
Used, Good Working Condition

Number of Feeds
Multiple, Gearbox Controlled

Main Motor Make
SIEMENS / Equivalent

Max Swing Over Bed
Approx. 470 mm

Graziano Italy 3000 mm Thread Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Graziano Italy 3000 mm Thread Milling Machine

Make - Graziano (Italy)

Model - FFL 43

Center Height - 205 mm

Max. Working Length of Job - 3000 mm

Max. Job Diameter - 260 mm

Max. Swing Diameter over Bed - 400 mm

Max. Cutter Diameter - 125 mm

Cutter Speeds - 55 rpm to 250 rpm

Cutter Head Rotation - 55 degree LH to 96 degree RH

Max. Length of Job - 3100 mm

Chuck Diameter - 200 mm

- With 2 x Steady, Change Gears, Index Plates & other accessories.

- Operating Manual of the machine is available.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/1uNbd8SOZJE

Heavy-Duty Thread Milling Performance

Engineered for resilience, the Graziano Italy 3000 mm Thread Milling Machine delivers reliable and consistent threading for shafts and cylindrical parts up to 3 meters long. Its solid cast iron construction reduces vibrations, ensuring precise results, even with challenging materials and thread forms.

Versatile Manual Control and Variable Speed

Equipped with a manually controlled gearbox, users can adjust the machines parameters, including variable spindle speed and multiple feed options. This flexibility is ideal for handling diverse threading requirements, adapting to various material types and workpiece dimensions in industrial environments.

Complete Package for Industrial Applications

Supplied with standard change gear sets, centers, a chuck key, and a tool holder set, this thread milling machine arrives ready for immediate integration into your production workflow. Its centralized lubrication and robust coolant system further enhance operational efficiency and prolong equipment lifespan.

FAQs of Graziano Italy 3000 mm Thread Milling Machine:

Q: How does the Graziano Italy 3000 mm Thread Milling Machine operate?

A: This machine operates manually with a gearbox-controlled system, allowing users to adjust spindle speed and feed rates flexibly. The lead screw and robust gear system ensure accurate and repeatable threading across a wide range of thread pitches and lengths.

Q: What is the primary usage of this thread milling machine?

A: It is primarily used for cutting external threads on shafts and cylindrical workpieces up to 3000 mm in length. Its rigid construction and variable speed are suitable for various industrial applications, including heavy machinery manufacturing and repair.

Q: When should I use variable spindle speed during thread milling?

A: Variable spindle speed is essential when working with different materials, thread pitches, or sizes. Adjusting speed allows for optimal cutting conditions, minimizes tool wear, and enhances surface finish, ensuring precise and efficient thread production.

Q: Where can this machine be installed effectively?

A: Due to its size and approximate weight of 6500 kg, this thread milling machine is best installed in industrial workshops or manufacturing facilities with ample floor space (about 4800 mm x 1400 mm) and access to a 415V, 3-phase power supply.

Q: What is the threading process with this machine?

A: The operator mounts the workpiece using the 3-jaw chuck, sets the desired thread pitch via change gears, adjusts speeds and feeds, and then initiates the milling operation. The centralized lubrication and coolant systems assist in maintaining smooth operation and tool longevity.

Q: What benefits does a used Graziano Italy 3000 mm Thread Milling Machine offer?

A: A used model in good working condition offers robust performance at a reduced cost. Its heavy-duty build and standardized accessories ensure reliable operation for industrial threading tasks, making it a pragmatic choice for both exporters and manufacturers.
