Graziano Sag Lathe Machine

Name: Graziano Sag Lathe Machine
Brand: Liberty Metal & Machines Private Limited
Price: 19000 INR
Availability: InStock

Price 19000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Graziano Sag Lathe Machine Specification

Product Type
Engine Lathe Machine

Material
Cast Iron

Cutting Thickness
Up to 10 mm (Dependent on Tool & Material)

Cutting Speed
Variable

CNC Or Not
No

Automatic Grade
Semi-Automatic

Control System
Manual

Max. Swing Diameter
400 mm

Voltage
415 V

Weight (kg)
Approx. 2000 kg

Dimension (L*W*H)
Approx. 2600 x 1000 x 1450 mm

Capacity
Medium Duty

Feature
Sturdy construction, High precision, Smooth operations

Color
Green / Grey

Lead Screw Diameter
34 mm

Spindle Nose
Camlock D1-6

Distance Between Centers
1500 mm

Bed Length
2000 mm

Motor Power
5 HP

Model
SAG

Cross Slide Travel
250 mm

Spindle Bore
55 mm

Thread Cutting Range
Metric & Inch, multiple pitches

Chuck Size
250 mm

Number of Spindle Speeds
12

Tailstock Quill Travel
200 mm

Longitudinal Feed
Variable

Graziano Sag Lathe Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Graziano Sag Lathe Machine

Make - Graziano (Italy)

Model - Sag 14

Center Height - 185 mm

Max. Length of Job - 900 mm

Max. Job Diameter over Bed - 370 mm

Max. Job Diameter over Cross-Slide - 210 mm

Max. Job Diameter in Gap - 500 mm

Spindle Speeds - 30 rpm to 1500 rpm

Bed Width - 280 mm

3-Jaw Chuck Diameter - 200 mm

4-Jaw Chuck Diameter - 310 mm

Spindle Bore - 50 mm

- Complete with steady rest, 4 sets of spare jaws.

- Machine is in excellent working condition.

Video of The Machine-

https://youtu.be/Aj6Y96emCas

High Precision Performance

The Graziano SAG Lathe Machine offers outstanding dimensional accuracy and stability, making it ideal for sophisticated machining applications that demand high precision. Its cast iron frame and robust spindle assembly reduce vibration and deliver consistent, smooth operations even with extensive use.

Versatile Machining Capabilities

This lathe accommodates both metric and inch threading and features variable cutting speeds. With a 400 mm maximum swing diameter and up to 10 mm cutting thickness, users can process diverse materials and component sizes to achieve excellent results.

Built for Efficiency and Reliability

Fitted with a 5 HP motor, 12 spindle speed options, and a variable longitudinal feed, the Graziano SAG permits rapid adjustments to match different materials and job requirements. Its semi-automatic, manual control enables precise operator control, minimizing errors and increasing productivity.

FAQs of Graziano Sag Lathe Machine:

Q: How is the Graziano SAG Lathe Machine typically used in workshops?

A: This lathe is used for turning, threading, and facing medium-sized workpieces. It is suitable for maintenance, manufacturing, and small-batch production, offering smooth operations and precision outcomes for a wide array of turning requirements.

Q: What benefits does the camlock D1-6 spindle nose provide?

A: The camlock D1-6 spindle nose allows for quick, secure chuck changes, enhancing setup efficiency and ensuring consistent alignment of workpieces during machining, which is crucial for maintaining precision.

Q: Where can the Graziano SAG Lathe Machine be installed?

A: It is best suited for installation in industrial machine shops, educational training centers, or manufacturing facilities that require medium-duty lathes for versatile machining tasks. Adequate space (at least 2600 x 1000 mm) and a 415 V power supply are necessary.

Q: When should the spindle speeds be adjusted?

A: Spindle speeds should be adjusted based on the material type and the cutting operation (turning, threading, or facing). Utilizing the correct speed ensures optimal finish quality, tool longevity, and safety during operation.

Q: How does the variable longitudinal feed enhance the machining process?

A: Variable longitudinal feed allows operators to manually adjust the feed rate during turning jobs. This adaptability facilitates finer surface finishes, precise control over tool paths, and efficient material removal based on specific job requirements.

Q: What is the process for cutting threads using this lathe?

A: To cut threads, the operator selects the appropriate lead screw pitch and spindle speed for the desired thread type (metric or inch). Then, using the manual controls, the tool is guided along the workpiece to generate accurate threads in various pitches.

Q: What are the advantages of the machines sturdy cast iron construction?

A: Cast iron construction ensures structural rigidity, minimizes vibrations, and supports stable cutting operations. This not only improves machining accuracy but also extends the lifespan of both the lathe and cutting tools.
