Huron MU66 2000 mm x 700 mm Universal Milling Machine

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Huron MU66 2000 mm x 700 mm Universal Milling Machine Specification

Model
Huron MU66

Rotation
360 rotating and swiveling milling head

Product Type
Universal Milling Machine

General Use
Industrial milling and metal machining

Material
Cast iron, solid steel

Type
Horizontal & Vertical

Capacity
Heavy duty - suited for large workpieces

Weight (kg)
Approx. 7600 kg

Computerized
No

Automatic
Semi-Automatic

CNC Or Not
Conventional (Not CNC)

Control System
Manual

Table Size
2000 mm x 700 mm

Table Slide Way
Box type, hardened and ground

Floor Space
4020 mm x 3190 mm

Spindle Speed
18 - 1800 RPM

Power
Main Motor 11 kW

Voltage
415 V, 3 Phase, 50 Hz

Dimension (L*W*H)
Approx. 4020 mm x 3190 mm x 2210 mm

Feature
Universal swiveling head, rapid traverse, power feed, rigid structure

Color
Grey & Blue

Huron MU66 2000 mm x 700 mm Universal Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Huron MU66 2000 mm x 700 mm Universal Milling Machine

Make - Huron (France)

Model - MU 66

Table Size - 2000 mm x 700 mm

XYZ Travel - 1500 mm x 1000 mm x 500 mm

Spindle Speeds - 30 rpm to 2066 rpm

Feed Rates - 1.6 mm/min to 820 mm/min

Max. Distance between Table to Spindle - 525 mm

- Equipped with a 3-Axis DRO.

- Double Swivel type Universal Milling Head.

- Suitable for Vertical, Angular & Horizontal Milling Operations.

- Can be operated from Front Side as well as Back Side.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/8qoIwYb_plw

Versatile Universal Milling Capability

The Huron MU66 boasts a unique swiveling and rotating milling head, enabling both horizontal and vertical machining. This versatility, paired with automatic and manual feed options, makes it ideal for various operations from slotting to surface finishing. Its universal design allows precise machining of complex workpieces, adapting seamlessly to dynamic industrial needs.

Heavy-Duty Construction and Performance

Built with cast iron and solid steel, the MU66 milling machine delivers outstanding vibration resistance and structural rigidity. The machines robust design supports a remarkable table load capacity of up to 2500 kg, ensuring stability and reliability even with large, heavy workpieces. This guarantees durability and consistent performance in demanding environments.

Efficient Operation and Maintenance

A centralized lubrication system and integrated coolant help extend lifespan and ensure smooth, accurate milling. The rapid traverse mechanism and automatic feeds improve productivity, reducing operator fatigue on intensive jobs. Practical maintenance features streamline regular upkeep, minimizing downtime and maximizing output for manufacturers and machinists alike.

FAQs of Huron MU66 2000 mm x 700 mm Universal Milling Machine:

Q: How does the universal milling head enhance machining operations on the Huron MU66?

A: The Huron MU66 features a universal milling head that can swivel and rotate 360 in two planes, allowing operators to perform both horizontal and vertical milling. This flexibility is crucial for machining complex parts, facilitating angled cuts, and tackling a wide range of industrial applications without repositioning the workpiece.

Q: What are the benefits of the heavy-duty construction of this milling machine?

A: The machines cast iron and solid steel construction provides exceptional strength and vibration resistance, crucial for precise and stable operations on large or dense workpieces. This rugged build enhances accuracy, supports long-term reliability, and enables the table to handle loads up to 2500 kg, ideal for heavy industrial use.

Q: When is the centralized lubrication system activated and what is its role?

A: The centralized lubrication system is designed for continuous or scheduled operation, ensuring that all moving parts, including slide ways and feed mechanisms, receive consistent lubrication. This reduces wear, maintains smooth motion, and minimizes maintenance requirements, promoting the longevity and optimal performance of the machine.

Q: Where can the Huron MU66 milling machine be installed given its dimensions and floor space requirements?

A: With an approximate dimension of 4020 mm x 3190 mm x 2210 mm and required floor space of 4020 mm x 3190 mm, the Huron MU66 best fits spacious industrial workshops or manufacturing plants. Its robust design and weight (approx. 7600 kg) require a stable, well-prepared foundation to ensure safe and effective operation.

Q: What processes is the Huron MU66 Universal Milling Machine suitable for?

A: The Huron MU66 excels at a variety of processes including heavy-duty milling, slotting, drilling, facing, and end milling. Thanks to its universal head and extensive table movements, it is particularly effective for large-scale precision machining, making it a preferred choice for metal fabrication and industrial component manufacturing.

Q: How does the rapid traverse and automatic feed system increase productivity?

A: The rapid traverse rate of 4000 mm/min along with the automatic and manual table feed options (151400 mm/min) allows operators to swiftly reposition workpieces and adjust feeds for efficient metal removal. This system reduces overall machining time, streamlines workflow, and helps handle high-volume production with less operator intervention.

Q: What advantages does the conventional (non-CNC) manual control system offer?

A: The MU66s manual controls provide users with direct, tactile engagement over machine settings, beneficial for custom and intricate operations. Skilled operators can precisely adjust speeds, feeds, and movements, making it ideal for both prototyping and small-batch manufacturing, where flexibility and immediate control are required.
