Huron PU 771 Bed Milling Machine

Name: Huron PU 771 Bed Milling Machine
Brand: Liberty Metal & Machines Private Limited
Price: 26000 INR
Availability: InStock

Price 26000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Huron PU 771 Bed Milling Machine Specification

Model
PU 771

Rotation
360°

Product Type
Bed Milling Machine

General Use
Industrial Milling Operations

Material
Cast Iron Structure

Type
Horizontal Milling Machine

Capacity
Heavy Duty

Weight (kg)
6500 kg

Computerized
No

Automatic
No

CNC Or Not
No

Control System
Manual

Table Size
2100 x 500 mm

Table Slide Way
Box Type

Floor Space
3700 x 3150 mm

Spindle Speed
35 - 1500 RPM

Power
7.5 kW

Voltage
415 V

Dimension (L*W*H)
3700 x 3150 mm

Feature
High Precision, Heavy Construction, Rigid Design

Color
Green

Number of T-Slots
5

Lubrication System
Automatic Centralized

Coolant System
Included

Rapid Feed
Yes

Table Load Capacity
Up to 2000 kg

T-Slot Size
18 mm

Longitudinal Travel (X)
1600 mm

Spindle Taper
ISO 50

Cross Travel (Y)
900 mm

Manual Feed
Yes

Main Motor Power
7.5 kW

Vertical Travel (Z)
500 mm

Huron PU 771 Bed Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

Huron PU 771 Bed Milling Machine About

Make - Huron (France)

Model - PU 771

Table Size - 2235 mm x 700 mm

XYZ Travel - 1900 mm x 1000 mm x 1000 mm

Spindle Taper - ISO 50

Spindle Speeds - 30 rpm to 2066 rpm

Feed Rate - 8 mm/min to 850 mm/min (Continuously Variable)

Weight of Machine - 8.0 tons (Approx.)

- Equipped with 3-Axis DRO.

- Universal type Milling Head for Vertical, Horizontal and Angular Milling.

- Operating & Maintenance Manual, Electrical Drawings, etc are available.

- Complete with a Cube Table.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/zJKqzAqGaS0

Heavy-Duty Performance and Construction

With a solid cast iron structure and a table capacity of up to 2000 kg, the Huron PU 771 Bed Milling Machine is designed for enduring heavy loads without compromising on accuracy. The box-type table slideways ensure stability and rigidity, while its robust build supports precise machining for various industrial applications.

Precision and Versatility

This milling machine features manual controls with spindle speeds ranging from 35 to 1500 RPM, allowing operators to adapt effortlessly to diverse milling tasks. The spindle taper ISO 50 guarantees compatibility with a variety of tooling, enhancing versatility. Its 360 rotation capability also allows flexible orientation of the workpiece.

User-Friendly Operation and Maintenance

Equipped with both rapid and manual feeds and an automatic centralized lubrication system, the PU 771 minimizes manual intervention. The integrated coolant system maintains optimal temperatures, promoting tool life and consistent performance, making it suitable even for extended use in busy industrial settings.

FAQs of Huron PU 771 Bed Milling Machine:

Q: How is the Huron PU 771 Bed Milling Machine typically used in industrial environments?

A: This machine is commonly employed for heavy-duty milling, drilling, and cutting operations in manufacturing and metalworking industries, providing precise material removal and shaping for large or bulky workpieces.

Q: What benefits does the automatic centralized lubrication system offer?

A: The automatic centralized lubrication system ensures all vital moving parts are consistently lubricated, reducing wear, minimizing maintenance requirements, and extending the lifespan of the machine.

Q: When should the coolant system be used during operations?

A: The coolant system should be used during intensive milling, especially when working with hard materials or prolonged cutting, to dissipate heat, maintain machining accuracy, and prolong tool life.

Q: Where can the Huron PU 771 Bed Milling Machine be installed given its size and weight?

A: Due to its substantial weight of 6500 kg and floor space requirement of 3700 x 3150 mm, the machine should be installed on a solid factory floor in workshops or industrial facilities equipped to handle large machinery.

Q: What process advantages does the manual control system provide?

A: Manual controls offer operators direct oversight and fine-tuned adjustments, making it ideal for custom or low-volume jobs where real-time feedback and precision are paramount.

Q: How does the robust table design contribute to machining performance?

A: The tables 2100 x 500 mm dimensions with five T-slots and box-type slide ways provide stable support for heavy or irregular workpieces, reducing vibrations and ensuring high-precision results.
