Industrial Colchester Triumph 2500 Lathe Machine

Name: Industrial Colchester Triumph 2500 Lathe Machine
Brand: Liberty Metal & Machines Private Limited
Price: 3200 USD
Availability: InStock

Price 3200 USD ($)/ Piece

Get a Price/Quote

MOQ : 1 Piece

Industrial Colchester Triumph 2500 Lathe Machine Specification

Product Type
Industrial Lathe Machine

Material
Cast Iron Body, Steel Components

Cutting Thickness
Up to 25 mm (depends on tool and material)

Cutting Speed
Variable, up to 2000 rpm

CNC Or Not
Conventional (Non-CNC)

Automatic Grade
Semi-Automatic

Control System
Manual

Max. Swing Diameter
400 mm

Voltage
415 V / 3 Phase

Weight (kg)
1200 kg (approx.)

Dimension (L*W*H)
2060 mm x 1100 mm x 1040 mm

Capacity
1500 mm between centers

Feature
Hardened and ground bedways, high precision, geared headstock, large spindle bore

Color
Industrial Grey & Blue

Tailstock Quill Travel
150 mm

Spindle Mount
D1-6

Lubrication System
Centralized Automatic

Lead Screw Diameter
32 mm

Chuck Size
250 mm

Coolant System
Fitted

Number of Spindle Speeds
12

Model
2500

Thread Cutting Range (Metric)
0.2 to 14 mm

Thread Cutting Range (Inch)
2 to 72 TPI

Tailstock Quill Diameter
60 mm

Spindle Bore
54 mm

Surface Finish
Precision Ground

Motor Power
5 HP

Cross Slide Travel
250 mm

Bed Type
Induction Hardened

Maximum Distance Between Centers
1500 mm

Bed Width
245 mm

Industrial Colchester Triumph 2500 Lathe Machine About

Colchester (England) make Lathe Machine in excellent working condition. The model of this machine is Triumph 2500 and the Maximum Length of Job is 1250 mm. The technical details are as follows -

Make - Colchester (England)

Model - Triumph 2500

Center Height - 205 mm

Max. Length of Job - 1250 mm

Max. Swing over Bed - 410 mm

Max. Job Diameter over Cross-Slide - 245 mm

Spindle Speeds - 15 rpm to 2500 rpm

Bed Width - 320 mm

3-Jaw Chuck Diameter - 250 mm

4-Jaw Chuck Diameter - 315 mm

Max. Swing Diameter in Gap - 585 mm

Spindle Bore - 55 mm

- Complete with 3-point steady.

- Equipped with Drive for Spindle Motor for continuously variable spindle speeds.

- Machine is in excellent working condition.

Video Link -https://youtu.be/oHwfB1zCtRk

Exceptional Precision and Durability

The Colchester Triumph 2500 Lathe Machine boasts precision ground surfaces and induction hardened bedways, ensuring excellent accuracy and extended service life. Its robust cast iron body coupled with steel components makes it suitable for continuous industrial use. Automatic lubrication and a fitted coolant system further help maintain top-notch performance.

Versatile Metalworking Capabilities

Capable of handling materials with up to 25 mm cutting thickness, this lathe offers versatile thread cutting ranges (metric and inch) for varied applications. The large 54 mm spindle bore and variable speeds up to 2000 rpm enable efficient processing of different workpieces. The geared headstock and D1-6 spindle mount provide stability during heavy-duty operations.

FAQs of Industrial Colchester Triumph 2500 Lathe Machine:

Q: How does the Colchester Triumph 2500 Lathe Machine ensure high precision in operations?

A: High precision is achieved through features like a precision ground bed, induction hardened bedways, and a geared headstock, all of which contribute to stable and accurate machining. The centralized automatic lubrication system helps reduce wear, maintaining consistent performance over time.

Q: What types of threading can be performed with this lathe machine?

A: The Colchester Triumph 2500 supports both metric (0.2 to 14 mm) and inch thread cutting (2 to 72 TPI), offering flexibility for various industrial threading requirements. Its lead screw diameter of 32 mm and multiple spindle speeds further enhance threading precision.

Q: When should the coolant system be used during operation?

A: The fitted coolant system should be used whenever cutting or threading operations generate significant heat, especially during extended runs or with tougher materials. Using coolant helps prevent tool wear and enhances the surface finish of machined parts.

Q: Where is the best environment to install the Triumph 2500 Lathe Machine?

A: This lathe is ideal for installation in professional workshops, industrial settings, and manufacturing plants where large-scale metalworking tasks are common. Its dimensional footprint and sturdy design fit well in facilities equipped with a three-phase, 415 V power supply.

Q: What is the typical process for adjusting cutting speeds on this machine?

A: Cutting speeds can be adjusted by selecting from the 12 available spindle speed settings, allowing operators to match the speed with workpiece material and specific machining requirements. The variable speed capability, up to 2000 rpm, facilitates optimal cutting conditions.

Q: How does the centralized automatic lubrication system benefit machine maintenance?

A: This system automatically distributes lubricant to critical components, reducing manual intervention and ensuring consistent lubrication. It minimizes friction and prolongs the lifespan of moving parts, leading to lower maintenance costs and improved machine reliability.
