Jafo Jarocin FYD32 Vertical Milling Machine

Send Inquiry

Request To Call Back

Jafo Jarocin FYD32 Vertical Milling Machine

Get a Price/Quote

MOQ : 1 Piece

Jafo Jarocin FYD32 Vertical Milling Machine Specification

Rotation
Clockwise/Counterclockwise

Model
FYD32

Product Type
Vertical Milling Machine

General Use
Industrial Vertical Milling

Material
Cast Iron Structure

Type
Vertical

Capacity
Maximum Load 400 kg

Weight (kg)
2300 kg

Computerized
No

Automatic
No

CNC Or Not
Not CNC

Control System
Manual

Table Size
1320 x 320 mm

Table Slide Way
Box type, Hardened and Ground

Floor Space
2000 x 1800 mm

Spindle Speed
45 2000 RPM (12 steps)

Power
4 kW

Voltage
380V / 50Hz

Dimension (L*W*H)
2000 x 1800 x 2100 mm

Feature
Heavy Duty, Rigid Construction, Precision Feeding

Color
Blue / Grey

T-Slot Number/Size/Distance
3 T-slots; 16 mm width; 70 mm distance

Noise Level
75 dB

Longitudinal Table Travel
800 mm

Cross Table Travel
300 mm

Electrical Protection
Overload and Short-circuit Relays

Vertical Movement of Table
400 mm

Distance Spindle Axis to Table Surface
400 mm maximum

Lubrication System
Centralized Automatic Lubrication

Main Drive Motor
4 kW (5.5 HP)

Distance Spindle Axis to Column
300 mm

Quill Travel
110 mm

Spindle Taper
ISO 40

Coolant System
Integrated Coolant Pump

About Jafo Jarocin FYD32 Vertical Milling Machine

Make - Jafo Jarocin (Poland)

Model - FYD32

Table Size - 1250 mm x 315 mm

XYZ Travel - 850 mm x 250 mm x 440 mm

Spindle Speeds - 56 rpm to 1800 rpm

Spindle Taper - ISO 40

Table Feed Rates - 12 mm/min to 1120 mm/min

Head Rotation - +45 Degree to -45 Degree

Quill Travel - 75 mm

Quill Diameter - 140 mm

- Machine is in excellent working condition.

Video link - https://youtu.be/ZR1tI8tFPbg

Precision and Heavy-Duty Performance

The Jafo Jarocin FYD32 is engineered for consistent accuracy and robust operation, essential for demanding manufacturing environments. With features such as box-type, hardened and ground table slide ways, the machine guarantees both strength and precision. Its rigid cast iron body and 4 kW main drive motor enable reliable handling of heavy workpieces up to 400 kg, making it ideal for repetitive, precise machining.

Comprehensive User and Operator Safety

Safety is integral to the FYD32s design. Equipped with overload and short-circuit relays, the machine minimizes operational risks, ensuring protection for both the equipment and the operator. The centralized automatic lubrication system also reduces the possibility of mechanical wear, extending the lifespan of key components while maintaining optimal machine performance.

User-Friendly Manual Controls for Versatility

This vertical milling machine is operated completely manuallyno CNC or computerized controlsallowing skilled machinists to directly manipulate all milling processes. The ergonomic layout and clearly marked controls facilitate intuitive operation, and the dual spindle rotation direction enhances machining flexibility for various industrial tasks.

FAQs of Jafo Jarocin FYD32 Vertical Milling Machine:

Q: How do I use the Jafo Jarocin FYD32s T-slots for workpiece mounting?

A: The FYD32s table is fitted with three T-slots, each 16 mm wide and spaced 70 mm apart, allowing secure workpiece clamping. Use appropriate T-slot nuts and clamps to mount your material firmly, ensuring stability during milling operations and accommodating a wide range of fixture setups.

Q: What is the maximum travel range for each axis on this milling machine?

A: The longitudinal travel (X-axis) is 800 mm, the cross travel (Y-axis) is 300 mm, and the vertical movement (Z-axis) of the table is 400 mm. The quill itself has a travel of 110 mm, providing ample reach and flexibility for most industrial milling tasks.

Q: When should the integrated coolant system be used during machining?

A: You should activate the integrated coolant pump during prolonged or heavy-duty milling operations, especially when machining hard metals or running at higher spindle speeds. The coolant protects the tool and workpiece from overheating, helps maintain precision, and extends tool life.

Q: Where is the Jafo Jarocin FYD32 most commonly utilized?

A: This vertical milling machine is widely used in industrial workshops, metal fabrication plants, toolrooms, and manufacturing facilities, especially where heavy-duty and precise manual milling is required with high material tolerances and large workpiece capacities.

Q: What maintenance processes are in place for the FYD32?

A: The FYD32 is equipped with a centralized automatic lubrication system, ensuring all critical moving parts are consistently lubricated without needing manual intervention. Routine checks of coolant levels and regular inspection of the box-type table slide ways also help maintain the machines integrity.

Q: What are the main benefits of using this vertical milling machine?

A: Key benefits include its heavy-duty build capable of supporting up to 400 kg, precision feeding with hardened and ground slide ways, simple manual operation, and robust safety features. Its adaptability across various milling tasks makes it a reliable asset for industrial manufacturers.
