Jones and Shipman 540P Surface Grinder Machine

Send Inquiry

Request To Call Back

Jones and Shipman 540P Surface Grinder Machine

Name: Jones and Shipman 540P Surface Grinder Machine
Brand: Liberty Metal & Machines Private Limited
Price: 37500 INR
Availability: InStock

Price 37500 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Jones and Shipman 540P Surface Grinder Machine Specification

Rotation
Clockwise

Model
540P

Product Type
Surface Grinder Machine

General Use
Surface Grinding

Material
Cast Iron

Type
Hydraulic

Capacity
Up to 540 mm

Weight (kg)
Approx. 1200 kg

Computerized
No

Automatic
Yes

CNC Or Not
Not CNC

Control System
Manual

Table Size
450 mm x 150 mm

Table Slide Way
Vee & Flat

Magnetic Chuck Size
450 mm x 150 mm

Grinding Wheel Size
180 mm x 13 mm x 31.75 mm

Grinding Wheel Speed
2800 RPM

Grinding Length
450 mm

Floor Space
1550 mm x 980 mm

Fuel Tank Capacity
40 Liters (Hydraulic Tank)

Spindle Speed
2800 RPM

Power
2 HP

Voltage
415V

Dimension (L*W*H)
1550 mm x 980 mm x 1650 mm

Feature
High Precision; Robust Structure

Color
Green/Grey

Grinding Accuracy
0.002 mm

Phase
Three Phase

Safety Feature
Emergency Stop

Table Longitudinal Travel
520 mm

Table Cross Travel
170 mm

Lubrication
Automatic

Vertical Feed
Micro Feed

Application
Tool Room, Precision Engineering

Chuck Type
Electromagnetic

Coolant Tank Capacity
40 Liters

Maximum Distance from Table Surface to Spindle Center
350 mm

Jones and Shipman 540P Surface Grinder Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

Jones and Shipman 540P Surface Grinder Machine About

Make - Jones & Shipman (England)

Model - 540P

Grinding Capacity - 150 mm x 450 mm

Longitudinal Travel - 480 mm

Cross Travel - 170 mm

Grinding Wheel Diameter - 178 mm

Current Magnet Size - 125 mm x 255 mm

- Micro Feed Adjustments in both Vertical & Cross Travel.

- Rapid Motorised Vertical Travel of Wheel-Head.

- Machine is in excellent working condition.

Video of the Machine -

https://youtu.be/8i98D1B_ZKc

Exceptional Precision and Performance

This surface grinder stands out for its grinding accuracy of 0.002 mm, ideal for tasks requiring demanding tolerances. The electromagnetic chuck and micro feed vertical adjustment provide precise control, while the hydraulic system maintains stable operation throughout prolonged use. Its high spindle speed allows for smooth surface finishes across diverse applications.

User-Friendly Manual Operation

Equipped with a manual control system and non-CNC setup, the 540P Surface Grinder is straightforward to operate, making it suitable for skilled machinists in tool rooms and general engineering settings. Safety is enhanced with an emergency stop feature, and routine lubrication is managed automatically to reduce maintenance efforts.

Robust Construction and Versatile Application

Constructed from cast iron, the Jones and Shipman 540P ensures long-lasting stability and resistance to vibrations. Its generous table and efficient coolant and hydraulic capacities make it adaptable for varied grinding tasks, from precision tool creation to everyday finishing jobs in engineering workshops.

FAQs of Jones and Shipman 540P Surface Grinder Machine:

Q: How does the Jones and Shipman 540P Surface Grinder maintain high grinding accuracy?

A: The machine features a robust cast iron body, micro feed vertical system, and precise electromagnetic chuck, allowing for controlled movements and stable workpieces. These design elements contribute to its impressive grinding accuracy of 0.002 mm.

Q: What safety features are included with the 540P Surface Grinder?

A: This surface grinder is equipped with an emergency stop button, ensuring immediate shutdown in case of unexpected events, thereby enhancing operator safety during grinding operations.

Q: Where is the Jones and Shipman 540P most effectively used?

A: The 540P Surface Grinder is particularly suitable for tool rooms, precision engineering environments, and workshops engaged in high-accuracy surface grinding tasks in the United Kingdom and worldwide.

Q: What is the process of table movement on this machine?

A: The table can traverse longitudinally up to 520 mm and crosswise up to 170 mm using manual controls. The vee and flat slideway supports smooth, consistent movement essential for precise grinding.

Q: When should the coolant and hydraulic tanks be refilled?

A: Refilling should occur whenever the 40-liter tanks reach low levels, which can be monitored regularly as part of routine maintenance to ensure optimal cooling and hydraulic system performance during operation.

Q: What type of chuck is provided with the 540P Surface Grinder?

A: The Jones and Shipman 540P is supplied with a high-quality electromagnetic chuck, measuring 450 mm x 150 mm, for secure and precise holding of workpieces during grinding.

Q: What are the main benefits of using this surface grinder in engineering workshops?

A: Users benefit from reliable high-precision grinding, robust machine construction, automatic lubrication, and efficient manual operation, all of which contribute to improved productivity and finished product quality.
