Magnaghi Horizontal Broaching Machine

Name: Magnaghi Horizontal Broaching Machine
Brand: Liberty Metal & Machines Private Limited
Price: 15000 INR
Availability: InStock

Price 15000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Magnaghi Horizontal Broaching Machine Specification

Frame Type
Heavy Duty Fabricated

Control System
Manual with Electrical Controls

WorkingSpeed
Variable 115 m/min

Production Capacity
Up to 60 pieces/hour

Accuracy
0.05 mm

Machine Type
Horizontal Broaching

Operating Temperature
5C45C

Drive
Hydraulic

Lubricating System
Centralized Lubrication

Model No
Magnaghi HB-4000

Cooling System
Integrated Coolant System

Power Rating
7.5 kW

Motor Power
7.5 kW

Voltage
415 V

Noise Level
<80 dB

Frequency
50 Hz

Features
Robust Cast Iron Frame, Easy Tool Change, Safety Guards

Product Type
Horizontal Broaching Machine

Technology
Conventional Machining

Power Source
Electric

Operating Type
Semi-Automatic

Power
7.5 kW

Pressure
Standard Hydraulic Pressure

Surface Treatment
Painted

Dimension (L*W*H)
Approx. 4200 x 1100 x 1600 mm

Weight (kg)
Approx. 4000 kg

Color
Sky Blue & Grey

Usage & Applications
Internal and external broaching operations in metalworking industries

Broach Return Speed
Rapid reverse

Phase Indication
Yes

Operation Cycle Time
10-35 seconds per cycle

Electrical Protection
Overload and short circuit protected

Max Workpiece Diameter
250 mm

Hydraulic System
Closed loop with filter

Stroke Length
1200 mm

Table Size
1500 x 300 mm

Max Broaching Force
100 kN

Broach Holder
Quick change type

Magnaghi Horizontal Broaching Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Magnaghi Horizontal Broaching Machine

Make - Magnaghi (Italy)

Max. Power - 5 tons

Max. Tool Stroke - 600 mm

- Complete with coolant pump & tank.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/TnaQGGXVai4

Reliable Performance and High Accuracy

Engineered for versatility, the Magnaghi HB-4000 delivers precision with an accuracy of 0.05 mm and adjustable cycle times between 1035 seconds. Its heavy-duty construction ensures consistent operation while handling demanding workloads. The rapid reverse feature minimizes downtime, boosting productivity without sacrificing safety or performance.

Advanced Convenience and Safety Features

Equipped with a quick-change broach holder, electrical overload and short circuit protection, and phase indication, this broaching machine ensures quick maintenance and safe operation. Safety guards and a robust frame further enhance workplace safety, while the centralized lubrication and integrated coolant system provide sustained machine longevity.

FAQs of Magnaghi Horizontal Broaching Machine:

Q: How is the broaching process performed on the Magnaghi HB-4000?

A: The broaching process is conducted by securing the workpiece on the sizable table and utilizing the quick-change broach holder. The hydraulic drive moves the broach through the workpiece, facilitating precise internal or external cuts, with a rapid return to minimize cycle time.

Q: What applications is this machine best suited for?

A: The Magnaghi HB-4000 is ideal for internal and external broaching tasks, such as creating keyways, splines, and automotive components, making it a preferred choice in metalworking and manufacturing industries requiring high productivity and precision.

Q: When should maintenance be performed on the machine?

A: Regular maintenance should follow the manufacturers guidelines, with particular attention to the centralized lubrication, hydraulic system filter, and integrated coolant system. Routine checks ensure optimal performance and longevity.

Q: Where can the Magnaghi HB-4000 be installed?

A: This machine is suitable for installation in industrial workshops or factory floors with stable electric power (415 V, 50 Hz) and controlled environments maintaining temperatures between 5C and 45C.

Q: What is the process for changing broaching tools?

A: The machine is equipped with a quick-change broach holder, enabling operators to replace broaching tools swiftly and safely, which drastically reduces set-up times and supports frequent tool changes.

Q: How does the machine ensure operator safety?

A: Operator safety is prioritized with comprehensive guards, overload and short circuit protection, and clear phase indication. These features, combined with the robust frame and controlled access, reduce hazards and ensure safe usage.

Q: What are the key benefits of choosing this broaching machine?

A: Key benefits include high production capacity (up to 60 pieces/hour), excellent accuracy (0.05 mm), easy tool changes, rapid operation cycles, robust construction, and advanced safety features all contributing to reliable, efficient metalworking operations.
