Maho MH 600 Tool Room Universal Milling Machine
Maho MH 600 Tool Room Universal Milling Machine

Maho MH 600 Tool Room Universal Milling Machine

Price 100000 INR/ Piece

MOQ : 1 Piece

Maho MH 600 Tool Room Universal Milling Machine Specification

  • Model
  • MH 600
  • Rotation
  • Both Clockwise and Counter-clockwise
  • Product Type
  • Universal Milling Machine
  • General Use
  • Tool Room Milling Operations
  • Material
  • Cast Iron/Base Steel Construction
  • Type
  • Horizontal & Vertical Milling
  • Capacity
  • 700 mm Table Travel (Longitudinal)
  • Weight (kg)
  • Approx 1500 kg
  • Computerized
  • No
  • Automatic
  • Manual / Semi-automatic Feeds
  • CNC Or Not
  • Not CNC (Conventional)
  • Control System
  • Manual
  • Table Size
  • 700 x 250 mm
  • Table Slide Way
  • Precision Hardened and Ground
  • Floor Space
  • Approx 1.6 m x 1.7 m
  • Spindle Speed
  • 40 2000 rpm (Variable)
  • Power
  • 3 kW
  • Voltage
  • 380 415 V, 3 Phase
  • Dimension (L*W*H)
  • 1600 x 1700 x 1700 mm (Approx)
  • Feature
  • Swiveling Head, Universal Table, Rigid Construction, High Precision
  • Color
  • Industrial Green/Grey
  • Longitudinal Travel (X-Axis)
  • 400 mm
  • Cross Travel (Z-Axis)
  • 350 mm
  • Manufacturing Origin
  • Germany (MAHO)
  • Max. Distance Spindle Centre to Column
  • 300 mm
  • Number of Spindle Speeds
  • 18 Steps
  • Feed Range (mm/min)
  • Approx 25 630 mm/min
  • Main Motor
  • 3 kW / 4 HP
  • WorkingSpeed
  • Adjustable / per manual setting
  • Accessories
  • Drawbar, Swivel Table, Vertical Head, Manual Feed Handles
  • Table Load Capacity
  • Approx 250 kg
  • Number of Feed Rates
  • 18 Steps
  • Max. Distance Spindle Nose to Table
  • 400 mm
  • Spindle Taper
  • ISO 40
  • Vertical Travel (Y-Axis)
  • 320 mm
  • Electricals
  • Standard with Overload Protection
  • Coolant System
  • Provided
  • Quill Stroke
  • 60 mm
  • Lubrication System
  • Centralized


Maho MH 600 Tool Room Universal Milling Machine Trade Information

  • Minimum Order Quantity
  • 1 Piece
  • Main Domestic Market
  • All India


About Maho MH 600 Tool Room Universal Milling Machine

Make - Maho (Germany)

Model - MH 600

Table Size - 720 mm x 410 mm

XYZ Travels - 500 mm x 400 mm x 400 mm

Vertical Clamping Table - 250 mm x 1030 mm

Spindle Speeds - 40 rpm to 2000 rpm

Feed Rate - 5 mm/min to 500 mm/min (Infinitely Variable)

Spindle Taper - ISO 40

Spindle Automatic Feed Travel - 80 mm

- Table can be rotated as well as tilted along both axes.

- Hydraulic Locking of XYZ & B-Axis Movements of Table.

- Hydraulic Clamping of the Tool Holder.

- Equipped with 3-Axis DRO.

- Complete with its Operating Manual, Electrical Drawings etc.

- Machine is in excellent working condition.


Video of The Machine -

https://youtu.be/5gf6nwJD2ds



Engineered for Precision Tool Room Work

MAHOs MH 600 is crafted for accuracy and versatility. With a precision-hardened and ground slide way, 18 feed and speed steps, and high rigidity, its ideal for demanding tool room milling applications. Its universal design accommodates both vertical and horizontal setups, paired with a centralized lubrication system for smooth operation.


Flexible Operations and Adjustable Speeds

The MH 600 offers variable spindle speeds from 40 to 2000 rpm and a wide feed range for detailed and coarse milling. The swivel head and universal table expand processing capabilities, making complex angles and shapes achievable. Manual and semi-automatic feeds provide flexibility for different operator preferences and project types.


Robust German Construction and Easy Maintenance

Built from cast iron and base steel, the MH 600 is recognized for its stability and durability. The centralized lubrication and overload protection systems contribute to easier maintenance. Its clear operator controls and comprehensive accessories, including manual feed handles and a vertical head, support straightforward, reliable daily use.

FAQs of Maho MH 600 Tool Room Universal Milling Machine:


Q: How is the MAHO MH 600 milling machine typically used in a tool room environment?

A: The MAHO MH 600 is engineered for precise tool room milling tasks, including shaping, facing, slotting, and drilling of materials. Its universal design with both horizontal and vertical milling capabilities makes it suitable for producing complex parts, fixtures, and tools required in maintenance, prototyping, and small-batch manufacturing.

Q: What main features give the MH 600 milling machine its versatility?

A: Key features include its universal swiveling table, adjustable spindle speeds (18 steps from 40 to 2000 rpm), extensive travel ranges on all axes, and the capability to operate both clockwise and counterclockwise. The swiveling head and wide range of accessories further enhance its ability to tackle varied milling applications.

Q: Where is the MAHO MH 600 manufactured and what is its build quality like?

A: The MH 600 is manufactured in Germany by MAHO, known for high-precision engineering. Constructed from robust cast iron and base steel, it offers excellent rigidity, stable operation, and longevity, making it a reliable choice for professional tool rooms.

Q: What maintenance process does the MH 600 employ to ensure smooth operation?

A: The MH 600 features a centralized lubrication system that simplifies maintenance by providing consistent oiling to essential moving parts. Additionally, its overload protection in the electrical system helps safeguard the machine and prolong its life.

Q: How can the working speed and feeds be adjusted on the MH 600?

A: Working speeds and feed rates are manually adjusted through stepped selectors, offering 18 distinct settings each. This allows operators to closely match the machines performance to the material, tool, and machining operation, optimizing surface finish and efficiency.

Q: What benefits does the operator gain from the MH 600s design?

A: Operators benefit from high precision due to the precision-hardened slide ways, a universal table for flexible part positioning, and robust construction for vibration-free machining. The ergonomic layout and included accessories make operation straightforward for both routine and complex tasks.

Q: When is the MAHO MH 600 most advantageous to use compared to CNC alternatives?

A: The MH 600 excels in environments where manual adjustments and versatility are required, such as custom tool making, maintenance, repair, and prototyping. It is ideal for skilled machinists who need hands-on control for one-off parts or variable production, rather than fully automated CNC jobs.
