MAS BPV 300/1 Vertical Surface Grinder

Price 11000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

MAS BPV 300/1 Vertical Surface Grinder Specification

Model
MAS BPV 300/1

Rotation
Vertical axis

Product Type
Vertical Surface Grinder

General Use
Industrial Surface Grinding

Material
Cast Iron

Type
Vertical

Capacity
Heavy Duty

Weight (kg)
1800 kg

Computerized
No

Automatic
No

CNC Or Not
Not CNC (Conventional)

Control System
Manual

Table Size
600 x 300 mm

Table Slide Way
V & Flat

Magnetic Chuck Size
300 mm

Grinding Wheel Size
300 x 100 mm

Grinding Wheel Speed
1440 rpm

Grinding Length
600 mm

Floor Space
1800 x 1300 mm

Fuel Tank Capacity
Not Applicable (Electric powered)

Spindle Speed
1440 rpm

Power
5 HP

Voltage
415 V

Dimension (L*W*H)
1800 x 1300 x 2200 mm

Feature
High Precision, Rigid Construction

Color
White & Blue

MAS BPV 300/1 Vertical Surface Grinder Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About MAS BPV 300/1 Vertical Surface Grinder

Make - MAS (Czech Republic)

Model - BPV 300/1

Magnet Size - 300 mm x 1000 mm

Segmented Wheel Cup Diameter - 315 mm

No. of Segments - 8 pcs.

Max. Height of Job - 400 mm

- With Automatic Depth Adjustment "Auto-Cut".

- Equipped with a Wheel Dresser.

- Complete with Coolant Tank & Pump.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/sNQ6671yDT8

Efficient and Reliable Grinding Capability

Designed for heavy-duty industrial use, the MAS BPV 300/1 delivers consistent precision in surface grinding. Its robust construction, combined with the vertical axis rotation and 300 mm electromagnetic chuck, ensures stability and uniformity even under continuous operation. The spacious table (600 x 300 mm) accommodates larger workpieces, making the grinder suitable for varied applications while maintaining high productivity and accuracy.

Intuitive Manual Controls for Enhanced Operator Interaction

Unlike CNC grinders, the MAS BPV 300/1 emphasizes manual operation, empowering skilled technicians to leverage hands-on control over machining processes. With manual longitudinal and cross feed, users can finely adjust grinding parameters, offering flexibility for both complex and simple tasks. The hand-operated centralized lubrication and variable feed ensure consistent performance with minimized downtime.

Safety, Compliance, and Durable Construction

Manufactured in the Czech Republic, this machine adheres to strict safety regulations with CE marking and noise levels below 75 dB. Protective wrapping and a sturdy wooden crate safeguard the machine during transport. Its cast iron body and rigid structure enhance both operational precision and long-term durability, making it ideal for challenging workshop environments.

FAQs of MAS BPV 300/1 Vertical Surface Grinder:

Q: How does the built-in coolant system benefit the grinding process?

A: The built-in coolant pump continuously delivers coolant to the grinding area, reducing heat buildup, minimizing thermal distortion, and prolonging both grinding wheel and workpiece life. This ensures smoother finishes and protects components from excessive wear.

Q: What types of workpieces can the MAS BPV 300/1 handle?

A: This grinder is suited for heavy-duty industrial work, accommodating workpieces up to 350 mm in height and 200 mm in grinding depth. Its spacious 600 x 300 mm table and electromagnetic chuck support a wide variety of ferrous components requiring high-precision surface finishing.

Q: Where should the MAS BPV 300/1 grinder be installed?

A: The machine is designed for floor-mounted installation and is ideal for spacious workshops or industrial environments. Ensure the floor space meets its footprint dimensions (1800 x 1300 mm) for safe and convenient operation.

Q: When should the lubrication system be serviced or operated?

A: The centralized hand-operated lubrication system should be activated before starting daily operations and periodically during use, especially for prolonged grinding tasks. Regular maintenance of the lubrication ensures smooth movement and helps prevent premature wear on sliding parts.

Q: What are the main advantages of using manual controls instead of CNC on this grinder?

A: Manual controls provide operators with direct feedback and adaptability during grinding. This is particularly valuable for custom or one-off jobs, or when a high degree of operator intuition and adjustment is needed to achieve optimal results.

Q: How can the electromagnetic chuck improve workholding during grinding?

A: The 300 mm electromagnetic chuck securely holds ferrous workpieces in place during grinding, reducing slippage and providing uniform magnetic force. This results in precise, repeatable grinding with minimal workpiece movement, crucial for achieving accurate surface finishes.
