MAS BPV 300 x 1500 Vertical Surface Grinder

Name: MAS BPV 300 x 1500 Vertical Surface Grinder
Brand: Liberty Metal & Machines Private Limited
Price: 33000 INR
Availability: InStock

Price 33000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

MAS BPV 300 x 1500 Vertical Surface Grinder Specification

Rotation
Manual/Automatic Table Movement

Model
MAS BPV 300 x 1500

Product Type
Vertical Surface Grinder

General Use
Precision surface grinding of large components

Material
Cast Iron, Steel

Type
Surface Grinding Machine

Capacity
300 x 1500 mm

Weight (kg)
Approx. 4,800 kg

Computerized
No

Automatic
No

CNC Or Not
Not CNC (Conventional)

Control System
Manual

Table Size
300 x 1500 mm

Table Slide Way
V and Flat Guideways

Magnetic Chuck Size
300 x 1500 mm

Grinding Wheel Size
350 mm diameter

Grinding Wheel Speed
1450 RPM

Grinding Length
1500 mm

Floor Space
3300 x 1800 mm

Fuel Tank Capacity
50 Litres (Hydraulic oil reservoir)

Spindle Speed
1450 RPM

Power
7.5 HP

Voltage
415 V, 3 Phase

Dimension (L*W*H)
3400 x 1800 x 2000 mm

Feature
High Precision Finish, Sturdy Construction

Color
Standard Grey

Chuck Magnetism
Electromagnetic

Coolant Motor
0.2 HP

Max Workpiece Height
350 mm

Minimum Feed Increment
0.002 mm

Spindle Motor
7.5 HP

Cross Feed Motor
0.75 HP

Lubrication System
Centralized lubrication

Grinding Accuracy
±0.002 mm

Vertical Feed Motor
0.5 HP

Hydraulic Pump Motor
1 HP

MAS BPV 300 x 1500 Vertical Surface Grinder Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About MAS BPV 300 x 1500 Vertical Surface Grinder

Make - MAS (Czech Republic)

Model - BPV 300/1.5

Magnet Size - 300 mm x 1500 mm

Segmented Wheel Cup Diameter - 315 mm

No. of Segments - 8 pcs.

Max. Height of Job - 400 mm

- With Automatic Depth Adjustment "Auto-Cut".

- Complete with a Wheel Dresser, Splash Guards etc.

- Complete with Coolant Tank & Pump.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/oxXzxKz5TuQ

Exceptional Accuracy and Build Quality

Built with high-grade cast iron and steel, the MAS BPV 300 x 1500 offers remarkable rigidity. Its surface grinding accuracy of 0.002 mm ensures exceptional finish quality for demanding industrial applications, while its electromagnetic chuck guarantees secure clamping of large workpieces.

Optimized for Large Workpieces

With a generous table and magnetic chuck size of 300 x 1500 mm and a maximum workpiece height of 350 mm, this machine is tailored for handling sizable components. The manual control and V and flat guideways provide smooth, consistent movement during the grinding process.

Enhanced Efficiency & Safety Features

The grinder features centralized lubrication and multiple motorized feeds (cross, vertical, hydraulic pump, and coolant) for reliable, continuous operation. A floor space of 3300 x 1800 mm and voltage requirements of 415V (3 phase) make it compatible with standard industrial environments.

FAQs of MAS BPV 300 x 1500 Vertical Surface Grinder:

Q: How does the MAS BPV 300 x 1500 achieve high precision in surface grinding?

A: The grinder achieves high precision primarily through its rigid construction, advanced V and flat guideways, and precise vertical and cross-feed increments of up to 0.002 mm. The electromagnetic chuck also enhances workpiece stability, contributing to the 0.002 mm grinding accuracy.

Q: What types of materials can be processed with this surface grinder?

A: It is suitable for grinding a range of ferrous and non-ferrous materials, including cast iron and steel, making it ideal for industrial components that require a precise, smooth finish.

Q: Where can the MAS BPV 300 x 1500 be effectively utilized?

A: This grinder is perfect for use in precision machine shops, heavy engineering workshops, and manufacturing plants involved in large component production. It is suitable for exporters, importers, manufacturers, suppliers, and traders focusing on high-accuracy surface finishing.

Q: When is manual operation preferable on this machine, given that it is not CNC-controlled?

A: Manual operation is advantageous for applications requiring direct control over the grinding process, quick setup changes, or for short production runs where programming CNC equipment may not be justified. It is ideal when operator expertise is essential for custom or intricate grinding tasks.

Q: What is the process for setting up a workpiece on the electromagnetic chuck?

A: To mount a workpiece, simply place it onto the electromagnetic chuck (300 x 1500 mm), ensure it is clean, and activate the electromagnetic chuck to secure it firmly. Adjustments are made manually to align and position the piece according to grinding requirements before starting the process.

Q: How does the centralized lubrication system benefit the machines longevity?

A: The centralized lubrication system ensures consistent and efficient distribution of lubricant to all critical moving parts, reducing wear and maintenance needs. This contributes to smoother operation, improved precision, and a longer service life for the grinder.
