Mechanicy 1600 x 315 Universal Milling Machine

Get a Price/Quote

MOQ : 1 Piece

Mechanicy 1600 x 315 Universal Milling Machine Specification

Model
Mechanicy 1600 x 315

Rotation
Both Horizontal & Vertical

Product Type
Universal Milling Machine

General Use
Industrial Milling Operations

Material
Cast Iron & Steel

Type
Universal Milling

Capacity
Heavy Duty

Weight (kg)
Approx. 2500 kg

Computerized
No

Automatic
Semi-automatic

CNC Or Not
Not CNC

Control System
Manual

Table Size
1600 x 315 mm

Table Slide Way
Box type

Floor Space
Approx. 2300 x 2000 mm

Spindle Speed
30 - 1500 rpm (variable)

Power
4 kW

Voltage
415 V, 3 Phase, 50 Hz

Dimension (L*W*H)
Approx. 2300 x 2000 x 1700 mm

Feature
Universal Milling Head, Swiveling Table, Robust Construction

Color
Blue & White

About Mechanicy 1600 x 315 Universal Milling Machine

Make - Mechanicy (Poland)

Model - FWA32M

Table Size - 1600 mm x 315 mm

XYZ Travels - 850 mm x 250 mm x 400 mm

Spindle Speeds - 20 rpm to 1500 rpm

Spindle Taper - ISO 50

Table Feed Rate - 12 mm/min to 505 mm/min

- With 2 x Bracket, Bracket Support, & Arbour for Horizontal Milling.

- Complete With Vertical Milling Head.

- Machine is in excellent working condition.

Video link - https://youtu.be/cmuhhbbd2y4

Versatility Meets Performance

Operating on both horizontal and vertical axes, the Mechanicy 1600 x 315 Universal Milling Machine adapts easily to a variety of milling applications. Its swiveling table and variable spindle speeds enable intricate angles and precision in industrial projects. This flexibility, combined with substantial load capacity, ensures suitability for light to heavy-duty workpieces from different industries.

Robust Construction and User-Centric Design

Crafted from durable cast iron and steel, this machine boasts a dependably rigid structure. The box-type table slideway enhances stability during intense milling, while the centralized lubrication and supplied coolant system simplify regular maintenance. Manual control over feeds and spindle speeds provides operators with hands-on flexibility, catering especially to semi-automated and manual process requirements.

FAQs of Mechanicy 1600 x 315 Universal Milling Machine:

Q: How do I use the swiveling table for angled milling operations?

A: The table on the Mechanicy 1600 x 315 Universal Milling Machine can swivel 45, allowing you to set precise angles for complex milling tasks. To use the swivel feature, unlock the tables adjustment controls, set your desired angle using the calibrated scale, and lock it securely before starting the operation.

Q: What types of materials can the Mechanicy 1600 x 315 machine handle?

A: Designed with heavy-duty capacity and robust cast iron and steel construction, this milling machine is suitable for a broad range of materials, including ferrous and non-ferrous metals, alloys, and certain engineered plastics commonly used in industrial manufacturing.

Q: When should the centralized lubrication system be checked or refilled?

A: Regularly check the centralized lubrication system before each shift or after every 8 hours of operation. Maintaining consistent lubrication is crucial for smooth slideway movement and to reduce wear on the machines moving parts, ensuring sustained performance.

Q: Where is the spindle speed control located, and how is it adjusted?

A: The spindle speed control is manually operated and typically located on the machines main panel. Adjust the speed dial or lever to set the spindle between 30 and 1500 rpm according to your workpiece and tooling requirements for optimal results.

Q: What benefits does the ISO 40 spindle taper offer?

A: The ISO 40 spindle taper provides compatibility with a wide range of standard milling tools and accessories, facilitating quick tool changes and accommodating diverse machining needs, which increases efficiency and minimizes downtime.

Q: How much weight can I safely place on the milling table?

A: The sturdy table can safely support workpieces up to 400 kg, making it suitable for most heavy industrial milling applications. Always ensure that the load is distributed evenly and secured before machining to maintain safety and precision.
