MSZ 560 mm Stroke Shaper Machine

Get a Price/Quote

MOQ : 1 Piece

MSZ 560 mm Stroke Shaper Machine Specification

Cooling System
Splash Lubrication

Motor Power
3 HP

Power Rating
2.2 kW

Features
Rigid Construction, Easy Operation, High Performance, Low Maintenance

Control System
Hand Operated / Electrical

Voltage
415 V

Lubricating System
Manual Oil Lubrication

Drive
Belt Driven

Accuracy
High Precision

Noise Level
Moderate

Model No
MSZ 560

Operating Temperature
Ambient

Production Capacity
Up to 10 pcs/hour (Approx.)

Frequency
50 Hz

Frame Type
Heavy Duty

Machine Type
Shaper

Product Type
Shaper Machine

Technology
Conventional

Power Source
Electric

Operating Type
Automatic

Power
3 HP

Surface Treatment
Paint Coated

Dimension (L*W*H)
1900 x 1030 x 1200 mm

Weight (kg)
1100 kg (Approx.)

Color
Blue & Silver

Usage & Applications
Metal Shaping, Slot Cutting, Keyways, Internal and External Grooving

Installation Type
Floor Mounted

Service Support
Available

Table Size (L x W)
560 x 315 mm

Main Spindle Speed
Variable, up to 450 RPM

Fuel Type
Electric Only

Table Feed
Automatic & Manual

Ram Adjustment
150 mm

Vibration
Low

Max Workpiece Height
315 mm

Shipping Package Size
2000 x 1200 x 1400 mm

Max Table Travel (Horizontal)
610 mm

Clamping System
Manual Vice

Number of Feeds
4

Tool Head Adjustment
45 Degrees

Maximum Stroke Length
560 mm

Max Table Travel (Vertical)
360 mm

MSZ 560 mm Stroke Shaper Machine About

Make - MSZ (Hungary)

Model - GH-560

Max. Stroke Length - 560 mm

Table Size - 560 mm x 400 mm

Stroke Rate - 12 strokes/min to 140 strokes/min

- Motorised Rapid Travel on both - Cross & Vertical - Travel of Table.

- Feed Travel on both - Cross & Vertical - Travel of the Table.

- With Automatic Depth Adjustment "Auto-Cut" of Tool.

- Machine is in excellent working condition.

Video link - https://youtu.be/z2RUH2QZ8yw

Precision and Power for Industrial Metal Shaping

The MSZ 560 mm Stroke Shaper Machine delivers high-precision shaping and grooving for diverse metalworking tasks. Its rigid, heavy-duty construction ensures durability, while the adjustable tool head and variable spindle speed offer versatility for complex jobs. Easy to operate, it provides automatic and manual feeds for flexible, efficient operation. This model is ideal for both light and heavy-duty production environments.

Advanced Features for Reliable Performance

Engineered with a robust belt-driven system, the MSZ 560 offers splash lubrication cooling and manual oil lubrication, ensuring smooth operation and longevity. The machines manual vice clamping and 3 HP electric power enable consistent high performance. Operating at ambient temperatures with low vibration and moderate noise, it maximizes productivity with easy maintenance.

Wide Range of Applications and Support

From keyways and slot cutting to internal and external grooving, the MSZ 560 is tailored for various shaping applications. Its spacious table dimensions and impressive table travel capacity handle large workpieces with ease. The floor-mounted installation, combined with comprehensive service support, allows for seamless integration into your production line.

FAQs of MSZ 560 mm Stroke Shaper Machine:

Q: How do I operate the MSZ 560 Stroke Shaper Machine safely and efficiently?

A: For safe and efficient operation, ensure the machine is properly installed on a level floor and connected to a 415V, 50Hz power source. Utilize the control system (hand operated or electrical) to adjust feeds and ram. Always secure your workpiece with the manual vice and use the splash lubrication system during operation. Review the user manual for detailed safety guidelines and operating procedures.

Q: What types of metalworking tasks can the MSZ 560 handle?

A: The MSZ 560 is suitable for shaping, slot cutting, keyway creation, and internal or external grooving on various metals. Its adjustable table and tool head accommodate a wide range of workpiece sizes and profiles, making it ideal for workshops and factories requiring versatile shaping solutions.

Q: When should I use the automatic versus manual table feed feature?

A: Use the automatic table feed for repetitive shaping operations or long cuts, which enhances production efficiency. Opt for the manual feed when handling intricate tasks or when greater control over feed rate is necessary for precision finishing.

Q: Where can I find installation and after-sales service support for this machine?

A: Comprehensive service support is available for the MSZ 560 across Hungary and internationally. Installation guidelines are included in the package, while technical assistance and maintenance services can be arranged through the manufacturer or local suppliers and traders.

Q: What maintenance process is required for optimal machine performance?

A: Routine maintenance includes regular oiling through the manual lubrication system, checking the fasteners, inspecting the belt drive, and cleaning the machine after use. Ensure the cooling system operates correctly to prevent overheating and refer to the maintenance schedule provided in the user manual.

Q: How does the machines design benefit my production process?

A: The MSZ 560s heavy-duty frame, adjustable tool head, variable speeds, and dual table feeds allow for high-precision work and adaptation to diverse projects. Its low vibration and robust construction ensure operational stability and minimal downtime, supporting up to 10 pieces per hour for increased productivity.
