Oerlikon UB2 Universal Drilling and Boring Machine
Oerlikon UB2 Universal Drilling and Boring Machine

Oerlikon UB2 Universal Drilling and Boring Machine

Price 40000 INR/ Piece

MOQ : 1 Piece

Oerlikon UB2 Universal Drilling and Boring Machine Specification

  • Table Size
  • 1000 x 400 mm
  • Features
  • Swiveling Work Table, Tiltable Head, Robust Construction, Longitudinal and Cross Movement
  • Dimension (L*W*H)
  • 1850 x 1150 x 2150 mm
  • Spindle Speed
  • 40 - 2000 RPM (12 Steps)
  • Diameter
  • Drilling Diameter up to 50 mm
  • Machine Type
  • Column Type Universal Drilling & Boring Machine
  • Motor Power
  • 3 HP
  • Cutting Area
  • Variable (Depends on Table Movement)
  • Noise Level
  • Standard/Low
  • Frequency
  • 50 Hz
  • Condition
  • Used/Good
  • Product Type
  • Universal Drilling and Boring Machine
  • Material
  • Heavy-Duty Cast Iron
  • Computerized
  • No
  • Automatic Grade
  • Semi-Automatic
  • CNC Or Not
  • Not CNC
  • Control System
  • Manual
  • Voltage
  • 400V / 50Hz (Three Phase)
  • Power
  • 2.2 kW
  • Power Source
  • Electric
  • Weight (kg)
  • Approx. 1600 kg
  • Capacity
  • Drilling up to 50 mm (Steel)
  • Color
  • Green
  • Usage & Applications
  • General Industrial Drilling, Boring, Reaming, Tapping and Counterboring
  • Table Cross Travel
  • 400 mm
  • Number of Spindle Feeds
  • 9
  • Model
  • UB2
  • Max Distance Spindle to Table
  • 800 mm
  • Max Distance Spindle to Base
  • 1150 mm
  • Quill Travel
  • 180 mm
  • Coolant System
  • Provided
  • Clamping Type
  • Manual Clamping
  • Swing Over Table
  • 900 mm
  • Spindle Taper
  • Morse Taper No. 4
  • Table Longitudinal Travel
  • 700 mm


Oerlikon UB2 Universal Drilling and Boring Machine Trade Information

  • Minimum Order Quantity
  • 1 Piece
  • Main Domestic Market
  • All India


About Oerlikon UB2 Universal Drilling and Boring Machine

Make - Oerlikon (Switzerland)

Model - UB2

Spindle Taper - MT 3

Spindle Diameter - 60 mm

Vertical Travel of Arm (Up/Down) - 590 mm

Longitudinal Travel of Head (In/Out) - 390 mm

Spindle Feed Travel - 150 mm

Spindle Speeds - 25 rpm to 2560 rpm

Spindle Feed Travel Rate - 0.06 / 0.12 / 0.25 mm/rev

Table Size - 700 mm x 880 mm

- Complete with Clamping Table, Vice and accessories.

- Machine is in excellent working condition.


Video of The Machine -

https://youtu.be/G70v4STOka8



Enhanced Precision and Versatility

The Oerlikon UB2 features a Morse Taper No. 4 spindle and offers nine spindle feed rates, making it highly adaptable for various drilling, boring, and tapping operations. Its universal design allows machinists to precisely handle complex jobs with ease while ensuring consistent outputs.


Robust Construction for Longevity

Manufactured with heavy-duty cast iron, the UB2 provides stability and longevity even under rigorous industrial conditions. Its solid build minimizes vibrations and ensures accurate machining outcomes, catering to demanding usage in workshops and manufacturing plants.


Flexible Table and Head Movement

The machine comes with a swiveling work table and tiltable head, allowing for flexible positioning and greater reach in challenging applications. With impressive longitudinal and cross travel capacity, it is ideal for varied machining requirements in both large and small parts.

FAQs of Oerlikon UB2 Universal Drilling and Boring Machine:


Q: How does the Oerlikon UB2 facilitate precise drilling and boring operations?

A: The UB2s Morse Taper No. 4 spindle, nine selectable spindle feeds, and a broad speed range of 402000 RPM (in 12 steps) ensure exact control over drilling and boring processes, enabling efficient machining of steel up to 50 mm diameter.

Q: What are the key applications for the Oerlikon UB2 Universal Drilling and Boring Machine?

A: This machine is designed for general industrial tasks such as drilling, boring, reaming, tapping, and counterboring. Its versatile features make it suitable for automotive, manufacturing, and workshop settings where precision and flexibility are required.

Q: When should the coolant system be utilized during operation?

A: The inbuilt coolant system should be activated whenever operating on tough materials or performing prolonged drilling or boring tasks. It helps dissipate heat, increases tool life, and maintains consistent performance.

Q: Where can the Oerlikon UB2 be installed for optimal results?

A: It is best installed in industrial workshops, manufacturing facilities, and engineering plants where space allows for movement around its substantial footprint (1850 x 1150 x 2150 mm) and electrical supply matches its 400V/50Hz requirement.

Q: What is the process for manual clamping on this machine?

A: Manual clamping is performed using the integrated clamps and fixtures on the worktable. Operators secure the workpiece manually before beginning machining, ensuring it remains stable and safely positioned throughout the operation.

Q: How can users benefit from the swiveling work table and tiltable head?

A: These features greatly enhance versatility, allowing users to adjust the table and head for angular drilling or boring tasks, reach complex workpieces, and improve access for setups that require precision from various orientations.

Q: Is the Oerlikon UB2 CNC-controlled or computerized?

A: No, the UB2 operates exclusively on manual controls and is not equipped with CNC or computerized automation. This offers direct hands-on operation suited for semi-automatic workflows.
