Pfauter CNC Gear Hobbing

Get a Price/Quote

MOQ : 1 Piece

Pfauter CNC Gear Hobbing Specification

Used For
Gear cutting and hobbing for automotive and industrial components

Capacity
Max wheel dia. 600 mm, Module up to 10

Output
High-precision gears, splines, and sprockets

Dimension (L*W*H)
3400 mm x 2200 mm x 2550 mm

Voltage
400 V, 50 Hz

Weight
Approx. 6500 kg

Feature
Precision cutting, fully automatic operation, programmable CNC controls

Color
White & Blue

Power
8 kW

Manufacturing Year
2010

Machine Type
CNC Gear Hobbing Machine

Condition
Used

Machine Operation
Touchscreen interface with manual override

Software
Pre-installed gear machining cycles

CNC Control Type
Siemens 840D

Min/Max Module
1 - 10 mm

Spindle Speeds
50 to 400 rpm

Tailstock Quill Stroke
100 mm

Coolant System
Integrated high-capacity coolant filtration

Max Table Load
800 kg

Max Workpiece Length
1000 mm

Max Hob Slide Travel
400 mm

Lubrication System
Centralized automatic lubrication

Clamping Table Bore
110 mm

Number of CNC Axes
4

Pfauter CNC Gear Hobbing Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cheque

Supply Ability
Piece

Delivery Time
1 Days

Packaging Details
Standard

Main Export Market(s)
Australia, North America, South America, Eastern Europe, Middle East, Africa, Western Europe, Central America, Asia

Main Domestic Market
All India

About Pfauter CNC Gear Hobbing

Established in the year 2015, we are a professionally managed venture affianced in manufacturing and supplying the best quality CNC Gear Hobbing Machine. This is usually used for cutting longer work pieces. It is a special type of milling machine. Available in different patterns, shapes and sizes, this is used for a broad range of parts and quantities. It is manufactured using high grade materials under the observation of deft technocrats as per the set international standards. We offer this CNC Gear Hobbing Machine at most reasonable price to our clients.

Features:

Robust design
Seamless finish
Anti corrosive

3-Axis CNC Gear Hobbing

Make - Pfauter (Germany)
Model - P253
Max. Gear Diameter - 250 mm
Max. Module - 6 module
Axial Slide Travel - 250 mm
CNC Control - Siemens Sinumerik Primo S
- Machine is in Excellent condition, the slides etc. are completely scratch less.

Advanced CNC Gear Hobbing Capabilities

With Siemens 840D CNC controls and four programmable axes, this gear hobbing machine offers exceptional flexibility in producing high-accuracy gears and spline components. Its automated cycles streamline the production process for a wide range of module sizes and workpiece dimensions.

Robust Construction & High-Capacity Operation

Engineered for high-load handling, it accommodates workpieces up to 800 kg and 1000 mm in length. The integrated coolant system and centralized lubrication ensure both optimal machining conditions and prolonged machine lifespan, even under continuous operation.

User-Friendly Controls and Efficient Workflow

Equipped with a modern touchscreen interface and manual override, this machine supports intuitive operation and rapid setup changes. Pre-installed software cycles enhance productivity, reducing downtime and improving overall gear-cutting efficiency.

FAQs of Pfauter CNC Gear Hobbing:

Q: How does the Siemens 840D CNC control enhance gear hobbing operations on this Pfauter machine?

A: The Siemens 840D CNC control system allows precise programming of gear-cutting cycles, offering efficient multi-axis movement and automation. This results in consistent, high-quality production and reduced manual intervention during the hobbing process.

Q: What types of gears and components can be produced with this CNC gear hobbing machine?

A: The machine is designed to cut a variety of gears, splines, and sprockets for automotive and industrial applications, supporting modules from 1 to 10 mm and wheel diameters up to 600 mm.

Q: When should the integrated coolant and lubrication systems be maintained?

A: Routine maintenance should be performed according to the manufacturers schedule, usually at regular working hour intervals, to maintain high filtration efficiency and ensure optimal lubrication for long-term reliability and performance.

Q: Where is the central lubrication system located, and what is its function?

A: The centralized automatic lubrication system is built into the machine to supply lubricant to all critical moving parts. This feature minimizes wear and streamlines maintenance tasks, located internally for easy access during service checks.

Q: What is the process for setting up a new gear cutting cycle on this machine?

A: Operators use the intuitive touchscreen to select and program machining parameters. The pre-installed gear machining cycles guide users through setup, making it straightforward to input data specific to each gear type and cutting requirement.

Q: How does the machine benefit gear manufacturers in terms of productivity and quality?

A: With features like high-precision CNC controls, robust handling capacity, and automated operation, this machine delivers consistent gear quality, reduces production time, and increases throughput for large and small batch manufacturing.

Q: In what usage scenarios does this Pfauter CNC Gear Hobbing Machine excel?

A: It is particularly well-suited for the automotive and industrial sectors, handling both single and repeated runs of high-precision gears, especially where heavy workpieces or complex profiles are required.
