Pfauter P400 Automatic Gear Hobbing Machine

Send Inquiry

Request To Call Back

Pfauter P400 Automatic Gear Hobbing Machine

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Pfauter P400 Automatic Gear Hobbing Machine Specification

Capacity
Workpiece diameter up to 400 mm

Used For
Precision gear hobbing operations

Weight
Approx. 8,000 kg

Color
Grey

Condition
Used

Dimension (L*W*H)
3200 mm x 1800 mm x 2100 mm

Output
High-precision gears

Power
15 kW

Feature
Automatic operation, high reliability, rigid construction

Machine Type
Automatic Gear Hobbing Machine

Voltage
380 V

Table Bore Diameter
100 mm

Max Module
Up to 8 module

Machine Accuracy
DIN 3962 Class 7

Floor Space Required
Approx. 10 sq.m

Table Load Capacity
500 kg

Max Hob Diameter
160 mm

Max Hob Shift
150 mm

Lubrication
Automatic centralized lubrication

Hob Arbor Diameter
32 mm and 40 mm

Spindle Speed
Variable, up to 500 rpm

Control Panel
Conventional operator panel

Coolant System
Integrated coolant system

Feed Range
0.05 to 2 mm/rev

Pfauter P400 Automatic Gear Hobbing Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Pfauter P400 Automatic Gear Hobbing Machine

Make - Pfauter (Germany)

Model - P400

Max. Module - 8 Modules

Max. Gear Diameter - 400 mm

Max. Vertical Travel of Hob Slide - 310 mm

Minimum Number of Teeth - 6

Max. Hob Cutter Diameter - 160 mm

Table Diameter - 400 mm

Table Bore - 80 mm

Max. Hob Cutter Shifting - 120 mm

Hob Cutter Speeds - 80 rpm to 500 rpm

- Completely new Electrical Panel equipped with PLC.

- Working in fully Auto-Cycle mode also capable of Double-Cut cycle.

- Electrical Drawings, Ladder Logic, & Operating Manual are available.

- Change Gears available and equipped with Chip Conveyor.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/Gf1bwYOWrc0

Engineered for Precision and Reliability

The Pfauter P400 guarantees high accuracy and consistent results in gear manufacturing. Thanks to its robust construction and automatic control features, this machine delivers precision gears in compliance with DIN 3962 Class 7 standards, even when handling large workpieces. The variable spindle speeds, integrated coolant system, and centralized lubrication ensure smooth operation and longevity, making it a preferred option for demanding industrial settings.

Versatile Application and User-Friendly Operation

With an ability to process gear modules up to 8 and accommodate different hob arbor diameters, the Pfauter P400 is adaptable to a range of production needs. The conventional operator panel and automatic operation streamline both setup and usage, minimizing operator effort while maximizing productivity. Its space-efficient design makes it suitable for various workshop layouts.

FAQs of Pfauter P400 Automatic Gear Hobbing Machine:

Q: How does the automatic operation of the Pfauter P400 enhance gear hobbing efficiency?

A: The automatic operation streamlines the hobbing process, reducing manual intervention. Features such as centralized lubrication and integrated coolant systems help maintain consistent performance, minimize downtime, and ensure higher throughput with supported automation.

Q: What types of gears can be produced with this machine and what is its maximum workpiece capacity?

A: The Pfauter P400 is designed for precision hobbing of gears up to 400 mm in diameter and a module of up to 8. It is ideal for manufacturing high-precision gears across automotive, industrial, and machinery applications.

Q: When is it recommended to use the variable spindle speed feature?

A: Variable spindle speeds, adjustable up to 500 rpm, should be used to optimize cutting conditions for different gear sizes and materials. Adjusting speed ensures optimum surface finish, tool life, and process efficiency depending on the specific requirements of the gear blank.

Q: Where can this machine be installed, considering its floor space requirements?

A: The Pfauter P400 requires approximately 10 square meters of floor space. It fits well within medium to large workshops or dedicated gear production facilities, accommodating its size and ensuring safe, efficient operation.

Q: What is the process for maintaining the Pfauter P400, and which systems support easy upkeep?

A: This machine features automatic centralized lubrication and an integrated coolant system, which simplify regular maintenance. Operators need to routinely check fluid levels and monitor for any wear, ensuring machine longevity and reliability.

Q: How does the Pfauter P400s construction benefit professional gear production environments?

A: Its rigid construction supports heavy table loads up to 500 kg and delivers stable, vibration-free performance. This enhances accuracy and repeatability during continuous operations, which is critical in high-quality gear production.

Q: What makes the Pfauter P400 suitable for exporters, manufacturers, and suppliers?

A: With high output precision, a user-friendly interface, and proven reliability, the Pfauter P400 meets the demands of large-scale exporters, manufacturers, and suppliers looking to produce gears to international standards, making it a valuable asset in the global gear market.
