Rambaudi 1300 mm x 300 mm Milling Machine
Rambaudi 1300 mm x 300 mm Milling Machine

Rambaudi 1300 mm x 300 mm Milling Machine

Price 35000 INR/ Piece

MOQ : 1 Piece

Rambaudi 1300 mm x 300 mm Milling Machine Specification

  • Model
  • Rambaudi 1300 x 300
  • Rotation
  • Universal Head (Manual Swivel)
  • Product Type
  • Vertical Milling Machine
  • General Use
  • Industrial Milling Operations
  • Material
  • Cast Iron
  • Type
  • Horizontal and Vertical Milling
  • Capacity
  • Heavy Duty
  • Weight (kg)
  • Approx. 2000 kg
  • Computerized
  • No
  • Automatic
  • No
  • CNC Or Not
  • Not CNC
  • Control System
  • Manual
  • Table Size
  • 1300 mm x 300 mm
  • Table Slide Way
  • Box Type
  • Magnetic Chuck Size
  • 1300 mm x 300 mm
  • Floor Space
  • Approx. 2000 mm x 1800 mm
  • Spindle Speed
  • Adjustable, 40-1600 rpm
  • Power
  • 3 to 5 HP
  • Voltage
  • 415V / 3 Phase
  • Dimension (L*W*H)
  • Approx. 2000 mm x 1800 mm x 2000 mm
  • Feature
  • Durable Construction, Precision Engineering, High Rigidity
  • Color
  • Light Green
  • Coolant System
  • Yes
  • Condition
  • Used/Refurbished
  • Working Speed
  • Variable
  • Lubrication System
  • Centralized
  • Spindle Taper
  • ISO 40
  • T-Slot Size
  • 16 mm
  • Main Motor
  • 3 HP
  • Longitudinal Travel
  • 1000 mm
  • Table Feed (X,Y)
  • Manual & Power Feed
  • Maximum Workpiece Height
  • 450 mm
  • Head Type
  • Universal Swivel Head
  • Number of T-Slots
  • 3
  • Vertical Travel
  • 420 mm
  • Cross Travel
  • 315 mm



About Rambaudi 1300 mm x 300 mm Milling Machine

Make - Rambaudi (Italy)

Model - AV-3

Table Size - 1300 mm x 300 mm

XYZ Travel - 950 mm x 280 mm x 500 mm

Spindle Speeds - 25 rpm to 1500 rpm

Spindle Taper - ISO 50

Table Feed Travel Rates - 12 mm/min to 550 mm/min

- Complete with Bracket for Horizontal Milling.

- Machine is in excellent working condition.


Video link - https://youtu.be/Nc7nVAGoe4I



Universal Swivel Head for Flexible Operation

The Rambaudi milling machine is equipped with a universal head, enabling manual swiveling for a wide range of complex milling angles. This feature enhances productivity in workshops that require both horizontal and vertical milling without changing machine setups.


Heavy Duty Construction and Precision Engineering

Constructed with high rigidity cast iron components and box-type slideways, this model ensures stability during heavy-duty operations. The robust build, combined with precision engineering, results in superior accuracy for intricate industrial milling tasks.


Advanced Feed and Lubrication Systems

The dual feed system offers both manual and power options on X and Y axes, allowing operators to choose the most efficient method for their workflow. Centralized lubrication ensures smooth operation and reduces maintenance downtime, helping to prolong the machines operational life.

FAQs of Rambaudi 1300 mm x 300 mm Milling Machine:


Q: How does the universal swivel head benefit industrial milling operations?

A: The universal swivel head allows operators to adjust the spindle to variable angles manually, making the machine suitable for both horizontal and vertical milling as well as inclined surfaces. This flexibility reduces the need to reposition workpieces and enhances efficiency in multi-step operations.

Q: What materials and workpiece sizes can the Rambaudi 1300 x 300 milling machine handle?

A: Designed for heavy-duty performance, the machine accommodates workpieces up to 1300 mm x 300 mm and a maximum height of 450 mm. The cast iron table and robust build allow it to machine a range of metals and industrial materials.

Q: When should I use manual feed versus power feed on the table?

A: Manual feed provides precise control for delicate adjustments and finishing work. Power feed is recommended for consistent, repetitive milling tasks, improving efficiency and reducing operator fatigue during lengthy machining cycles.

Q: Where is the Rambaudi 1300 x 300 milling machine typically installed?

A: It is suited for industrial workshops, fabrication plants, and manufacturing units, requiring a floor space of approximately 2000 mm x 1800 mm. Its heavy-duty construction makes it ideal for demanding environments.

Q: What is the process for maintenance and lubrication on this milling machine?

A: The machine features a centralized lubrication system, making routine maintenance straightforward. Operators need to monitor lubrication levels and top up periodically to ensure optimal moving part performance and longevity.

Q: How does adjustable spindle speed enhance milling versatility?

A: Spindle speed adjustment from 40 to 1600 rpm allows users to tailor cutting conditions for different materials and milling processes, balancing surface finish quality with productivity.

Q: What are the main advantages of choosing a refurbished Rambaudi 1300 x 300 model?

A: Refurbished units offer high-quality original engineering at a lower cost compared to new machines. They undergo expert servicing to ensure reliability, while still providing the durable construction, precise operation, and advanced features expected from Rambaudi.
