Rambaudi Versamill Bed Milling Machine

Price 50000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Rambaudi Versamill Bed Milling Machine Specification

Model
Versamill

Rotation
360 (Universal Head)

Product Type
Bed Milling Machine

General Use
Industrial Milling Operations

Material
Cast Iron

Type
Horizontal & Vertical Milling

Capacity
Medium - Heavy Duty

Weight (kg)
Approx. 2800 kg

Computerized
No

Automatic
No

CNC Or Not
Not CNC

Control System
Manual

Table Size
1530 x 355 mm

Table Slide Way
Box Type

Floor Space
Approx. 2.5 x 2.2 m

Spindle Speed
36 - 1500 RPM (Variable)

Power
5 HP

Voltage
415 V, 3 Phase

Dimension (L*W*H)
2650 x 2300 x 1800 mm

Feature
Robust Structure, High Precision, Versatile Operation

Color
Gray

About Rambaudi Versamill Bed Milling Machine

Make - Rambaudi (Italy)

Model - Versamill

Table Size - 1600 mm x 510 mm

XYZ Travel of Table - 1200 mm x 700 mm x 900 mm

Spindle Taper - ISO 50

Spindle Speeds - 22 rpm to 2000 rpm

Table Feed Rate of Travel - 6 mm/min to 1000 mm/min

Ram Travel of Milling Head - 400 mm

- Double Swivel type Milling Head.

- Milling Head can be removed to do Horizontal Milling.

- Equipped with 3-Axis DRO.

- Machine is in excellent working condition.

Video link - https://youtu.be/NZ2egLohzCc

Superior Versatility and Precision

Designed for both horizontal and vertical milling, the Versamill offers a broad head swivel range (45) and universal head rotation. This enables users to perform intricate machining from multiple angles, supporting complex industrial components. Its precise feed rate (10 - 500 mm/min) combined with high table load capacity (500 kg) make it ideal for medium to heavy duty operations.

Robust Construction for Industrial Demands

Featuring a cast iron frame, box-type table slide ways, and a centralized lubrication system, the Rambaudi Versamill ensures structural strength and consistent operational reliability. With an approximate weight of 2800 kg, the machine maintains stability during demanding milling processes. It is expected to stand up to rigorous industrial use, promoting longevity and accuracy.

FAQs of Rambaudi Versamill Bed Milling Machine:

Q: How do I operate the Rambaudi Versamill Bed Milling Machine for various industrial milling tasks?

A: To operate the Versamill, adjust the manual controls to set spindle speeds (361500 RPM), feed rates (10500 mm/min), and head angles as needed for the desired milling procedure. Use the handwheels for traverseslongitudinal, cross, and verticalto position your workpiece. The robust structure and manual control facilitate versatile operations, supporting both horizontal and vertical milling.

Q: What types of materials can be processed with this milling machine?

A: Thanks to its cast iron construction and powerful 5 HP main motor, the Rambaudi Versamill is suitable for milling a wide range of industrial materials, including steel, cast iron, non-ferrous metals, and engineered plastics. It handles medium to heavy-duty workloads without compromising accuracy or structural integrity.

Q: When should the centralized lubrication system be used?

A: Centralized lubrication should be activated before starting any milling operation to ensure proper distribution of lubricant throughout the sliding ways and moving components. Regular lubricationpreferably at the beginning of each shiftreduces wear, promotes smooth operation, and extends the machines service life.

Q: Where is the best environment to install the Rambaudi Versamill Bed Milling Machine?

A: This machine should be installed in industrial workshops with sufficient floor spaceat least 2.5 x 2.2 metersand robust flooring to support its approximately 2800 kg weight. Proper electrical infrastructure (415V, 3 phase) and ventilation are recommended for safe and efficient operation.

Q: What is the machining process with the Versamills manual control system?

A: Operators set up the workpiece on the 1530 x 355 mm table, secure it, and manually adjust the feed and spindle speeds. The universal head allows for 360 rotation, enabling both horizontal and vertical milling. Select the desired feed (out of 18 options), engage the coolant system if needed, and proceed with gradual passes for precision results.

Q: How does the machines robust structure benefit industrial users?

A: The cast iron build and box-type slide ways ensure outstanding rigidity, reducing vibration and maintaining high precision even during intensive operations. This robustness allows users to execute complex milling tasks reliably, achieving consistent accuracy and surface finish across multiple applications.
