Rigiva 900 x 225 Vertical Milling Machine

Price 20000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Rigiva 900 x 225 Vertical Milling Machine Specification

Rotation
Standard spindle rotation

Model
Rigiva 900 x 225

Product Type
Vertical Milling Machine

General Use
Precision metal milling applications

Material
Cast Iron

Type
Vertical

Capacity
900 mm working length

Weight (kg)
Approx. 1200 kg

Computerized
No

Automatic
No

CNC Or Not
Not CNC

Control System
Manual

Table Size
900 x 225 mm

Table Slide Way
Box type

Magnetic Chuck Size
900 x 225 mm

Grinding Wheel Size
Standard for model

Grinding Wheel Speed
Standard (as per model)

Grinding Length
900 mm

Floor Space
1750 x 1120 mm

Spindle Speed
Variable (as per model specifications)

Power
3 HP

Voltage
415 V

Dimension (L*W*H)
1750 x 1120 x 2050 mm

Feature
High precision, rigid construction, manual operation

Color
Standard (Machine Grey)

About Rigiva 900 x 225 Vertical Milling Machine

Make - Rigiva (Italy)

Table Size - 900 mm x 225 mm

XYZ Travel - 570 mm x 220 mm x 450 mm

Spindle Speeds - 50 rpm to 1600 rpm

Spindle Taper - ISO 40

Spindle Quill Diameter - 110 mm

Spindle Travel - 55 mm

Table Feed Rate - 35 mm/min to 1100 mm/min

Head Rotation - 90 Degree to -90 Degree

- Equipped with 2 Axis DRO.

- Machine is in excellent working condition.

Video link - https://youtu.be/mEDiNC4lcek

Unmatched Precision and Robust Build

The Rigiva 900 x 225 Vertical Milling Machine stands out for its exceptional surface finish accuracy under 0.015 mm and solid box-type table slide way. Constructed from durable cast iron, it offers remarkable rigidity and vibration resistance, ensuring consistently precise results suitable for fine milling in various industrial applications. Its manual lubrication system and fitted coolant equipment enhance operational longevity and maintain consistent performance.

Flexible Manual Operation for Skilled Machinists

With a variable spindle speed (per model specifications) and 8 manual feed steps, the Rigiva milling machine caters to skilled operators seeking full control over their machining tasks. The 45 vertical head swivel feature aids in handling complex workpieces, while the 127 mm quill travel adds versatility for diverse projects. Non-CNC, manual control makes it ideal for applications requiring user expertise and adaptability.

Optimized for Efficiency and Ergonomics

This machines practical design includes a spacious 900 mm table length and 380 mm height to the table, allowing effortless handling of medium to large workpieces. The fitted coolant system and central lubrication reduce maintenance hassles, keeping both the equipment and the workpieces in optimal condition. With standard magnetic chuck and grinding wheel sizes, setup and operation are smooth and reliable.

FAQs of Rigiva 900 x 225 Vertical Milling Machine:

Q: How do I operate the Rigiva 900 x 225 Vertical Milling Machine for precision milling?

A: To operate the Rigiva 900 x 225 for precision milling, you manually adjust the spindle speed and table feeds using the 8-step feed mechanism. Ensure correct tool mounting on the ISO 40 spindle taper, set workpieces securely on the magnetic chuck, and activate the fitted coolant system. Always check the central manual lubrication system before use for smooth motion and optimal accuracy.

Q: What types of materials can this milling machine process effectively?

A: The Rigiva 900 x 225 is suitable for precision machining of various metals, especially those found in typical engineering and fabrication workshops, including steel, aluminum, brass, and cast iron. Its sturdy construction and surface finish accuracy make it ideal for components demanding tight tolerances.

Q: When should I perform lubrication maintenance on this machine?

A: It is recommended to use the centrally fitted manual lubrication system before beginning each milling session or after every few hours of extended operation. Regularly maintaining lubrication keeps moving parts in optimal condition, reducing wear and supporting consistent machine performance.

Q: Where is the Rigiva 900 x 225 most effectively utilized?

A: This model is best utilized in precision engineering workshops, metal fabrication units, training institutes, and small to medium-sized manufacturing facilities, particularly where manual control and high surface accuracy are required.

Q: What is the process for changing or adjusting the spindle speed?

A: Spindle speed on the Rigiva 900 x 225 is manually adjustable according to the models specifications. Operators select the appropriate speed by adjusting the control levers or dials provided, while ensuring the machine is powered down during changes to prevent accidents.

Q: How does the manual feed system benefit users over CNC alternatives?

A: Manual feed gives skilled machinists comprehensive control over cutting speed, depth, and feed rate, allowing real-time adjustments for complex or sensitive workpieces. This flexibility is ideal for specialized parts or low-volume, high-precision applications where operator expertise is advantageous.

Q: What are the main benefits of the Rigiva 900 x 225s design and features?

A: Key benefits include its rigid cast iron construction for stability, high precision finish, versatile manual control, 45 head swivel, centrally fitted lubrication, and fitted coolant equipmentall of which contribute to extended equipment life, reliable performance, and the ability to handle a wide range of precision milling tasks.
