Rivol High Production Lathe Machine

Get a Price/Quote

MOQ : 1 Piece

Rivol High Production Lathe Machine Specification

Product Type
High Production Lathe Machine

Material
Cast Iron, Alloy Steel

Cutting Thickness
Up to 10 mm (depends on material)

Cutting Speed
35 - 1800 RPM

CNC Or Not
No (Conventional Lathe)

Automatic Grade
Semi-Automatic

Control System
Manual

Max. Swing Diameter
300 mm

Voltage
415 V, 3 Phase, 50 Hz

Weight (kg)
1150 kg approx.

Dimension (L*W*H)
1800 x 870 x 1275 mm

Capacity
High Production

Feature
Heavy Duty, Accurate Turning, Long Operational Life

Color
Grey/Blue & White

Spindle Nose
A2-4

Speed Range
Variable

Tailstock Quill Travel
125 mm

Main Motor Power
3 HP

Spindle Bore
39 mm

Distance Between Centers
1000 mm

Number of Spindle Speeds
8

Bed Type
Hardened and Ground

Tailstock Quill Diameter
50 mm

Chuck Size
200 mm (8 inches)

About Rivol High Production Lathe Machine

Rivol High Production Lathe Machine

Make - Rivol (Italy)
Center Height - 185 mm
Max. Length of Job - 900 mm
Max. Job Diameter over Bed - 390 mm
Max. Job Diameter over cross-slide - 200 mm
Spindle Speeds - 35 rpm to 1800 rpm
Bed Width - 280 mm
3-jaw Chuck Diameter - 250 mm
4-jaw Chuck Diameter - 310 mm
Automatic Pneumatic 3-jaw chuck for fast clamping & de-clamping.
Hydraulic center of Tailstock.
Complete with accessories like spare tool holders, 4-jaw chuck etc.
Machine is in excellent working condition.

Video Link-https://youtu.be/bryIVF_Xr10

Precision and Heavy-Duty Performance

Engineered with a hardened and ground bed, the Rivol High Production Lathe Machine delivers high-precision turning even under continuous, demanding use. Its robust cast iron and alloy steel construction assures longevity, while variable speed control caters to a wide range of cutting requirements. This ensures optimal results in heavy-duty applications where accuracy and efficiency are paramount.

Versatility for Industrial Applications

Supporting a maximum swing diameter of 300 mm and a distance between centers of 1000 mm, this lathe is compatible with various workpiece sizes. The combination of an 8-speed spindle, 3 HP motor, and semi-automatic/manual controls allows machinists to tailor operations for specific tasks. High production capacity and adaptability make it a strong choice for manufacturers and traders.

FAQs of Rivol High Production Lathe Machine:

Q: How does the Rivol High Production Lathe Machine ensure precision and durability during operation?

A: The lathe features a bed that is both hardened and ground, providing a stable and accurate platform for machining. Its construction from high-quality cast iron and alloy steel enhances stability and longevity, minimizing vibrations and wear during heavy-duty cycles.

Q: What is the recommended process for setting spindle speeds and cutting thickness?

A: Operators can choose from 8 available spindle speeds, adjustable between 35 and 1800 RPM, according to material and cutting requirements. For optimal results, refer to the materials specifications to set the appropriate cutting thickness, which can go up to 10 mm, ensuring efficiency and surface finish.

Q: Where can the Rivol High Production Lathe Machine be employed most effectively?

A: This machine is ideally suited for industrial environments requiring high-volume turning, such as manufacturing plants, workshops, and fabrication facilities. Its design caters well to exporters, importers, manufacturers, and suppliers seeking reliable heavy-duty machinery for consistent output.

Q: When is maintenance recommended for this lathe machine to ensure long operational life?

A: Regular maintenance is vital. Lubricate moving parts and check the alignment and wear of critical components after every production cycle or as per manufacturer recommendations, typically every few months depending on intensity of usage, to preserve performance and accuracy.

Q: How does the manual control system impact the usability of the Rivol Lathe?

A: The manual control system offers exceptional flexibility, allowing machinists to make real-time adjustments during operation. This hands-on approach is particularly beneficial for customizing each job, ensuring precision and control over the turning process.

Q: What are the benefits of using a high production semi-automatic lathe like this model?

A: Users benefit from enhanced productivity, reliable performance, and precise turning. The semi-automatic features reduce operator fatigue, while high-capacity output and robust engineering minimize downtime and maintenance costs.
