Rosa RTRC 1200 Surface Grinding Machine

Price 45000 INR/ Piece

Get a Price/Quote

Rosa RTRC 1200 Surface Grinding Machine Specification

Model
RTRC 1200

Rotation
Reversible

Product Type
Surface Grinding Machine

General Use
Precision Surface Grinding

Material
Cast Iron, Steel

Type
Hydraulic & CNC

Capacity
Heavy Duty

Weight (kg)
5600 kg

Computerized
Yes

Automatic
Yes

CNC Or Not
CNC

Control System
Siemens PLC

Table Size
1300 mm x 400 mm

Table Slide Way
Hardened and Ground

Magnetic Chuck Size
1200 mm x 400 mm

Grinding Wheel Size
400 mm x 75 mm x 127 mm

Grinding Wheel Speed
1450 RPM

Grinding Length
1200 mm

Floor Space
3200 mm x 2600 mm

Fuel Tank Capacity
120 L

Spindle Speed
1450 RPM

Power
15 HP

Voltage
415 V / 50 Hz

Dimension (L*W*H)
3200 mm x 2600 mm x 2200 mm

Feature
High Precision, Low Vibration, Durable Structure

Color
Grey & Blue

Rosa RTRC 1200 Surface Grinding Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Rosa RTRC 1200 Surface Grinding Machine

Make - Ermando Rosa (Italy)

Model - RTRC 1200

Job Grinding Size - 450 mm x 1200 mm

Max. Cross Travel - 500 mm

Max. Longitudinal Travel - 1300 mm

Magnet Size - 400 mm x 1200 mm

Grinding Wheel Size - Diameter 400 mm x 50 mm Width

Max. Distance b/w Magnet to Wheel Center - 475 mm

Grinding Wheel Motor - 17.5 HP

- Complete with Coolant Filtration Unit and some other accessories.

- Equipped with a Wheel-Top Mounted Wheel Dresser.

- Complete with Operating Manual, Electrical Drawings etc.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/rfSiSamMh-A

Advanced CNC Control for Precision Grinding

The Rosa RTRC 1200 Surface Grinding Machine is equipped with a Siemens PLC control system, allowing CNC operation for intricate tasks. Its servo motor-driven work table provides smooth, automated feeds, enhancing repeatability and accuracy. Hardened and ground slide ways further improve stability during grinding, ensuring consistently high-quality surface finishes for demanding applications.

Optimized for Heavy-Duty Industrial Applications

Designed for industrial environments, this machine supports heavy-duty operations with a 15 kW motor and a robust cast-iron and steel build. Its automatic centralized lubrication system and integrated cooling system contribute to long-lasting performance and reduced maintenance requirements. Its versatility makes it suitable for precision grinding of various workpieces in manufacturing, exporting, or tool-room settings.

FAQs of Rosa RTRC 1200 Surface Grinding Machine:

Q: How does the machine ensure high surface finish accuracy?

A: The Rosa RTRC 1200 achieves high surface finish accuracy up to 0.002 mm through its precision-ground table slide ways, centralized lubrication system, and automatic CNC controls, which work together to minimize vibration and optimize grinding conditions.

Q: What materials can be ground using the RTRC 1200 Surface Grinding Machine?

A: This machine is suitable for grinding components made from cast iron and steel, owing to its heavy-duty design, durable structure, and adjustable grinding parameters.

Q: When should the centralized lubrication system be maintained?

A: While the lubrication system is automatic, it is recommended to periodically check the oil levels and system components according to the manufacturers schedule to ensure optimal machine performance and longevity.

Q: Where is this grinding machine typically used?

A: The RTRC 1200 is commonly found in precision manufacturing plants, export workshops, tool rooms, and other industrial settings requiring high-accuracy surface grinding of large workpieces.

Q: What process controls are available on this machine?

A: It features a Siemens PLC-based control system, providing advanced CNC programming, servo-driven table feed, and automation of key grinding parameters for consistent, repeatable results.

Q: How does the cooling system benefit grinding operations?

A: The built-in cooling system efficiently manages the heat generated during grinding, which helps maintain dimensional stability, prevents thermal damage to workpieces, and prolongs both tool and machine life.

Q: What are the main benefits of using this surface grinding machine?

A: Key advantages include exceptional precision, heavy-duty capacity, low vibration, reliable automation, and streamlined operations resulting in higher productivity, improved finish quality, and reduced operator intervention.
