Sachman Bed type Vertical Milling and Boring Machine

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Sachman Bed type Vertical Milling and Boring Machine Specification

Rotation
Spindle rotation clockwise/counterclockwise

Model
Sachman Bed Type

Product Type
Bed Type Vertical Milling and Boring Machine

General Use
Heavy duty milling and boring operations

Material
Cast iron and steel

Type
Milling and boring

Capacity
Heavy duty

Weight (kg)
Approx. 5200 kg

Computerized
No

Automatic
Manual operation

CNC Or Not
Not CNC (Conventional)

Control System
Manual control

Table Size
2000 mm x 510 mm (approx)

Table Slide Way
Hardened and ground box ways

Floor Space
3000 mm x 3400 mm (approx)

Spindle Speed
18 - 1800 rpm

Power
Approx. 7.5 kW main motor

Voltage
415 V, 50 Hz

Dimension (L*W*H)
Approx. 3000 mm x 3400 mm x 2500 mm

Feature
High rigidity, precision, durable

Color
Standard machine grey

T-Slot Size
18 mm

Working Speed
Variable, up to 1800 rpm

Lubrication System
Centralized automatic

Number of T-Slots
5

Spindle Taper
ISO 50

Vertical Travel (Z Axis)
1000 mm

Cross Travel (Y Axis)
800 mm

Quill Diameter
105 mm

Longitudinal Travel (X Axis)
2000 mm

Lighting
Worklight included

Table Load Capacity
2000 kg

Coolant System
Integrated

Sachman Bed type Vertical Milling and Boring Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Sachman Bed type Vertical Milling and Boring Machine

Make - Sachman (Italy)

Table Size - 1500 mm x 510 mm

Longitudinal Travel of Table (X Axis) - 1000 mm

Cross Travel of Table (Y Axis) - 500 mm

Max. Height between Table to Spindle - 570 mm

Spindle Speeds - 35 rpm to 2000 rpm

Spindle Feed Travel - 150 mm

Spindle Diameter - 130 mm

Table Feed Rates of Travel - 8 mm/min to 388 mm/min

Spindle Feed Rates of Travel - 0.038 mm/rev to 0.17 mm/rev

Head Rotation - +45 degree to -45 degree

- Equipped with 3-Axis DRO.

- Suitable for Milling, Boring & Drilling Work.

- Machine is in excellent working condition.

Video of the Machine -

https://youtu.be/itE5bOlIe4c

Heavy Duty Precision Engineering

Sachmans bed type milling and boring machine combines high rigidity with precise operation, making it ideal for demanding industrial machining. The hardened and ground box slide ways paired with a robust cast iron base help maintain accuracy across large components and extended work cycles, ensuring reliable performance for manufacturers, suppliers, and traders alike.

Versatile Manual Operation for Large Workpieces

With a wide table size and significant travels on all axes, this machine is built for versatility. Its ISO 50 spindle taper supports various heavy duty tooling options, while the centralized lubrication and integrated coolant system contribute to sustained smooth operation and lower maintenance. Manual controls allow operators to fine-tune the process for optimal results.

FAQs of Sachman Bed type Vertical Milling and Boring Machine:

Q: How does the Sachman Bed Type Vertical Milling and Boring Machine support heavy duty machining tasks?

A: The machine is engineered with a sturdy cast iron and steel build, allowing a table load capacity of up to 2000 kg and heavy duty spindle with ISO 50 taper. These features enable it to handle large and heavy workpieces efficiently during milling and boring operations.

Q: What are the benefits of the integrated coolant and centralized lubrication systems?

A: The integrated coolant system helps to manage tool temperature and remove chips, while the centralized automatic lubrication minimizes friction and wear in moving parts. These features extend the machines working life and promote consistent precision.

Q: When should I use this milling and boring machine over CNC alternatives?

A: Choose this conventional machine when you require manual control for specialized, complex, or custom jobs where CNC programming isnt necessary, or for environments valuing operator skill and flexibility over automation.

Q: Where is the Sachman Bed Type Machine manufactured and supplied from?

A: This model is manufactured in Italy and is available globally through exporters, importers, manufacturers, suppliers, and traders specializing in industrial machinery.

Q: What is the process for setting up fixtures on the table?

A: The table offers five T-slots of 18 mm size, allowing secure attachment of workpieces and fixtures. Proper fixture setup is essential for maintaining precision during heavy duty machining operations.

Q: How does manual control impact usage of this machine in a workshop?

A: Manual controls provide the operator with direct input over machine movements and speed, offering greater flexibility and hands-on adjustments during machining, which is beneficial for unique, non-repetitive tasks.

Q: What are the key benefits for exporters and industrial clients using this machine?

A: Clients benefit from a durable, high-capacity machine with proven precision and versatility, suitable for a wide range of heavy duty applications and adaptable to different manufacturing and machining sectors.
