Schutte WU32 Hydraulic Tool and Cutter Grinder

Name: Schutte WU32 Hydraulic Tool and Cutter Grinder
Brand: Liberty Metal & Machines Private Limited
Price: 20000 INR
Availability: InStock

Price 20000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Schutte WU32 Hydraulic Tool and Cutter Grinder Specification

Cutting Speed
Variable, Depending on Wheel and Tool

Cutter Type
End Mills, Reamers, Side & Face Cutters

Hardness
Not Applicable (N/A)

Features
Hydraulic Table Movement, High Rigidity, Adjustable Workhead, Coolant System, High Precision

Shape
Rectangular Base, Tool Grinder Form

Cutting Force
Hydraulic Driven

Length
Approx. 1200 mm

Tool Type
Tool & Cutter Grinder

Operation Type
Semi-Automatic

Cutting Capacity
Versatile, for Various Tool Sizes

Drill Bits Types
Supports Various End Mills, Drills, Reamers

Material
Cast Iron Body, Hardened Steel Components

Cutting Accuracy
High Precision

Machine Type
Hydraulic Tool and Cutter Grinder

Coating
Uncoated

Operate Method
Hydraulic & Manual Controls

Diameter
Standard Wheel: 200-250 mm

Processing Type
Grinding, Sharpening, Tool Preparation

Grinding Wheel Speed
Variable, up to 3500 rpm

Table Cross Travel
Approx. 210 mm

Make/Model
Schutte WU32

Accessories
Standard Grinding Attachments, Centers, Wheel Guards, Coolant System

Voltage
415 V, 3 Phase

Table Size
Approx. 900 mm x 135 mm

Table Longitudinal Travel
Approx. 400 mm

Swivel Range of Table
-30° to +30°

Headstock Swivel
360°

Net Weight
Approx. 1800 kg

Applications
Sharpening & Grinding of Cutting Tools, Milling Cutters, Reamers, End Mills, Form Tools

Cooling System
Integrated Coolant Pump

Schutte WU32 Hydraulic Tool and Cutter Grinder Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

Schutte WU32 Hydraulic Tool and Cutter Grinder About

Make - Schutte (Germany)

Model - WU 32

Table Clamping Size - 150 mm x 890 mm

Longitudinal Travel - 320 mm

Cross Travel - 255 mm

Vertical Travel - 275 mm

Spindle Speeds - 1100 rpm to 6000 rpm

Max. Swing Diameter on Work-Head - 240 mm

Rotating Angle of Wheel-Head - 360 degree

Tilting Angle of Wheel-Head - 15 degree to -15 degree

Max. Grinding Wheel Diameter - 200 mm

- Automatic Hydraulic Travels of the Table.

- Motorised Vertical Travel of the Wheel-Head.

- Wheel-Head can be Rotated as well as Titled.

- Equipped with Universal Work-Head with Indexing Feature.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/0ibfJpDukM0

Advanced Hydraulic Operation for Precision Grinding

Utilizing hydraulic table movement, the Schutte WU32 ensures smooth longitudinal and cross travel, allowing for high-precision tool grinding. The ergonomic control system accommodates both hydraulic and manual adjustments, delivering flexibility for complex tool geometries and varied tool types, including end mills, reamers, and side cutters.

Versatility and Enhanced Productivity

Designed to process a wide range of cutting tools, the Schutte WU32 supports sharpening, grinding, and tool preparation functions. Its adjustable workhead and variable speed control facilitate efficient handling of different tool sizes. The integrated coolant system maintains optimal temperature, preserving tool integrity and prolonging wheel life.

Reliable Structure and User-Friendly Design

Built with a sturdy cast iron base and hardened steel components, this machine offers outstanding rigidity and vibration damping. The 360 headstock swivel and table swivel range from -30 to +30 enable complex grinding processes, while standard accessories and safety features like wheel guards ensure streamlined operation and user safety.

FAQs of Schutte WU32 Hydraulic Tool and Cutter Grinder:

Q: How does the Schutte WU32 Hydraulic Tool and Cutter Grinder ensure high precision during tool sharpening?

A: The machine features hydraulic table movement and adjustable workhead, allowing fine control over tool positioning and grinding operations. Its high rigidity cast iron construction minimizes vibrations, and its variable grinding wheel speed allows optimal adaptation for different tool materials and geometries, resulting in consistently accurate sharpening.

Q: What types of cutting tools can be processed with the Schutte WU32?

A: The Schutte WU32 is engineered to handle a variety of cutting tools, including end mills, reamers, drills, side and face cutters, and form tools. Its adaptable fixtures and variable cutting speed accommodate various diameters and lengths, making it suitable for both standard and custom applications.

Q: When is it ideal to use the integrated coolant system on the Schutte WU32?

A: The coolant system should be employed during all grinding and sharpening processes to dissipate heat generated at the tool and wheel interface. This prevents thermal damage, maintains tool hardness, and improves surface finish, ensuring longer life for both tools and grinding wheels.

Q: Where can the Schutte WU32 be installed for optimal performance?

A: The machine is best suited for toolrooms, manufacturing workshops, and production facilities requiring precise tool preparation and maintenance. Its compact rectangular base and robust construction allow stable placement on workshop floors with access to 415 V, 3-phase power supply.

Q: What is the process for changing grinding wheels on the Schutte WU32?

A: To replace the grinding wheel, the operator must stop the machine, remove the wheel guard, and release the mounting fixture. Standard wheel sizes are 200250 mm in diameter. The coolant system should be checked and reactivated after installation for safe and effective operation.

Q: How do the hydraulic and manual controls contribute to the machines versatility?

A: The dual-mode operation (hydraulic and manual) gives users the flexibility to either automate repetitive grinding tasks or manually fine-tune positions for specialty tools. This versatility enhances productivity and enables precision in both high-volume and customized tool production.

Q: What are the main benefits of using the Schutte WU32 for tool preparation?

A: Key benefits include high precision, versatile tool compatibility, efficient coolant management, adjustable speed, and increased rigidity. These features collectively ensure consistent results, minimize tool wear, and support extended production cycles for various cutting applications.
