Sculfort Heavy-Duty Lathe Machine
Sculfort Heavy-Duty Lathe Machine

Sculfort Heavy-Duty Lathe Machine

MOQ : 1 Piece

Sculfort Heavy-Duty Lathe Machine Specification

  • Product Type
  • Heavy-Duty Lathe Machine
  • Material
  • Cast Iron, Hardened Steel
  • Cutting Thickness
  • Up to 80 mm
  • Cutting Speed
  • 301500 RPM
  • CNC Or Not
  • No, Manual Lathe
  • Automatic Grade
  • Manual
  • Control System
  • Manual
  • Max. Swing Diameter
  • 660 mm
  • Voltage
  • 415 V / 3 Phase
  • Weight (kg)
  • 3000 kg
  • Dimension (L*W*H)
  • 3750 x 1200 x 1450 mm
  • Capacity
  • Suitable for heavy duty turning operations
  • Feature
  • High-precision, robust construction, geared headstock, hardened bed ways
  • Color
  • Industrial Blue & White
  • Spindle Nose
  • A2-8
  • Applications
  • Shaft turning, machining large workpieces, general engineering work
  • Main Motor Power
  • 7.5 kW
  • Tool Post Type
  • Four-way
  • Chuck Size
  • 400 mm
  • Tailstock Quill Diameter
  • 75 mm
  • Tailstock Quill Travel
  • 200 mm
  • Number of Spindle Speeds
  • 18
  • Distance Between Centers
  • 2000 mm
  • Drive Type
  • Geared Head
  • Bed Length
  • 3000 mm
  • Spindle Bore
  • 105 mm



About Sculfort Heavy-Duty Lathe Machine

  • Make - Sculfort (France)
  • Model - Maxicap
  • Center Height - 285 mm
  • Length of Job - 2000 mm
  • Max. Swing Diameter over Bed - 570 mm
  • Max. Swing Diameter over Cross-Slide - 350 mm
  • Job Size in Gap - 900 mm Diameter x 200 mm length
  • Bed Width - 475 mm
  • Chuck Diameter - 315 mm
  • Spindle Speeds - 12 rpm to 960 rpm
  • Spindle Bore - 70 mm
  • Complete with 1 nos. x  3-point steady.
  • -Machine is in excellent working condition.

Video link - https://youtu.be/2WocZalsv20



Robust Construction & Precision Engineering

The Sculfort Heavy-Duty Lathe Machine is built from high-quality cast iron and hardened steel, ensuring long-lasting durability and stability during heavy-duty operations. Its hardened bed ways and geared headstock contribute to precise machining, even when working with large, challenging components. Designed for demanding workshop environments, this lathe delivers both strength and fine detail.


Versatile Applications for Industrial Needs

This lathe excels in shaft turning, machining large workpieces, and general engineering applications. With its maximum swing diameter of 660 mm and 400 mm chuck size, it accommodates a wide range of materials and dimensions. Its capability to handle cutting thicknesses up to 80 mm makes it ideal for both intricate and heavy-duty projects in manufacturing and repair settings.


Efficient Manual Control & Operation

Operating on a manual control system, the Sculfort lathe puts precision in the hands of skilled users. Offering 18 spindle speeds and a four-way tool post, operators can adjust settings to match material and task requirements. The machines ergonomic design and clear control layout facilitate straightforward, safe, and efficient operation, ensuring consistent results.

FAQs of Sculfort Heavy-Duty Lathe Machine:


Q: How does the Sculfort Heavy-Duty Lathe Machine benefit large-scale machining operations?

A: Its substantial bed length of 3000 mm and distance between centers of 2000 mm enable machining of large workpieces, while the high-precision and robust construction ensures consistent accuracy over heavy-duty turning tasks.

Q: What materials and components can be processed with this lathe?

A: The lathe is suitable for machining cast iron, hardened steel, and similar robust materials. It excels at turning shafts, creating large components, and performing general engineering work.

Q: When is manual operation preferred over CNC for this lathe?

A: Manual operation is optimal when specialized or custom turning operations are required, allowing operators to make on-the-spot adjustments and maintain direct control over the machining process.

Q: Where is the Sculfort Heavy-Duty Lathe Machine typically installed?

A: It is generally installed in industrial workshops, manufacturing plants, and engineering facilities that require high-capacity, heavy-duty machining solutions.

Q: What is the process for changing spindle speeds?

A: Operators can select from 18 different spindle speeds using the geared head mechanism, adjusting the speed to match cutting requirements and material properties for optimal results.

Q: How is high-precision maintained during operation?

A: Precision is ensured by the lathes hardened bed ways, robust cast iron construction, and fine-tuned manual controls, which collectively minimize vibration and maintain alignment during machining.

Q: What are the main advantages of the machines geared headstock?

A: The geared headstock provides reliable power transmission, enables quick speed adjustments, and supports the high torque necessary for demanding turning tasks, enhancing both efficiency and durability.
