Smart and Brown England Tool Room Lathe Machine

Price 22500 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Smart and Brown England Tool Room Lathe Machine Specification

Product Type
Precision Tool Room Lathe

Material
Cast Iron

Cutting Thickness
Up to 25 mm

Cutting Speed
Variable (up to 2000 RPM)

CNC Or Not
No, Conventional / Manual

Automatic Grade
Manual

Control System
Manual Mechanical Controls

Max. Swing Diameter
340 mm

Voltage
415V, 3 Phase

Weight (kg)
1300 kg

Dimension (L*W*H)
2000 mm x 900 mm x 1200 mm

Capacity
High precision, suitable for toolroom applications

Feature
Hardened and ground beds, accurate lead screw, robust construction

Color
Biege & Green

Smart and Brown England Tool Room Lathe Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Smart and Brown England Tool Room Lathe Machine

Make - Smart & Brown (England)

Model - 1024

Center Height - 140 mm

Max. Job Length - 600 mm

Max. Job Diameter over Bed - 280 mm

Max. Job Diameter over Cross-Slide - 160 mm

Spindle Speeds - 30 rpm to 2500 rpm

Bed Width - 285 mm

3-Jaw Chuck Diameter - 152 mm

4-Jaw Chuck Diameter - 152 mm

Spindle Bore - 38 mm

- Complete with a travelling type job-steady.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/1sByJhW4vBg

Precision Engineered for Tool Room Excellence

Designed for workshops and manufacturing environments, this conventional lathe machine features hardened and ground beds, enhancing both durability and precision. The sturdy cast iron construction and accurate lead screw ensure minimal deflection and superior results during even the most intricate machining processes. Suitable for high-precision turning, threading, and facing, it meets demanding toolroom standards.

Versatile Performance with User-Friendly Controls

Equipped with a 40 mm spindle bore and 1000 mm distance between centers, this machine offers great flexibility for a wide range of workpiece sizes. Variable cutting speeds up to 2000 RPM and 12 spindle speed settings allow users to tailor the operation as needed. The manual mechanical control system makes it easy to adjust parameters for different materials and machining tasks, maximizing efficiency in engineering and manufacturing settings.

FAQs of Smart and Brown England Tool Room Lathe Machine:

Q: How do I operate the manual controls on the Smart and Brown lathe machine?

A: The Smart and Brown lathe features a manual mechanical control system, allowing users to adjust speed, spindle direction, and feed manually. Familiarize yourself with the control levers and reference the user manual for guidance on setting spindle speed (12 available) and engaging the lead screw for threading or auto-feed operations.

Q: What types of materials can be machined with this lathe?

A: Thanks to its robust cast-iron build, variable speed up to 2000 RPM, and cutting thickness capacity up to 25 mm, the lathe is suitable for machining a wide range of metals and engineering materials commonly used in toolroom, workshop, and manufacturing applications.

Q: When should I use the integrated coolant system?

A: Activate the integrated coolant system during prolonged or high-speed machining operations to reduce heat buildup. This helps in maintaining tool life, achieving precision tolerances, and preventing thermal distortion on workpieces.

Q: Where can this lathe machine be effectively utilized?

A: This machine is ideal for engineering workshops, tool rooms, and manufacturing industries that require precise, manual turning and threading operations. Its compact footprint fits well in small to medium-sized production areas.

Q: What benefits do the hardened and ground beds provide?

A: Hardened and ground beds significantly enhance the durability and accuracy of the machine. They ensure smooth sliding of the carriage while reducing wear and maintaining precise alignment during extended use, crucial for toolroom applications.

Q: How does the tailstock travel support my machining process?

A: With a tailstock travel of 150 mm, you can accommodate longer or varying workpiece lengths for drilling or supporting operations, enhancing flexibility and stability during turning or facing processes.

Q: What safety precautions should be taken during use?

A: Always wear appropriate personal protective equipment, ensure all guards are in place, and double-check workpiece mounting before operation. Regularly inspect the mechanical components and coolant system for maintenance to ensure reliable and safe performance.
