Stanko 1100 mm x 250 mm Universal Milling Machine

Price 10500 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Stanko 1100 mm x 250 mm Universal Milling Machine Specification

Model
Stanko Universal 1100x250

Rotation
Both Horizontal and Vertical Axis

Product Type
Universal Milling Machine

General Use
Metalworking, Engineering Workshops

Material
Cast Iron Body, Steel Components

Type
Universal

Capacity
Heavy Duty, up to 500 kg workpiece

Weight (kg)
Approx. 1800 kg

Computerized
No

Automatic
No

CNC Or Not
Not CNC

Control System
Manual

Table Size
1100 mm x 250 mm

Table Slide Way
Box type

Floor Space
1850 mm x 1780 mm

Spindle Speed
45 to 2000 rpm (variable)

Power
5 HP

Voltage
380V / 415V

Dimension (L*W*H)
Approx. 1850 mm x 1780 mm x 1900 mm

Feature
Strong build, precision work, versatile operations

Color
Standard Industrial Green

Number of T-Slots
3

Lubrication System
Centralized

Main Motor Power
3.7 kW

Coolant System
Provided

Spindle Taper
ISO 40

Feed Range
Auto, 22 Steps

Longitudinal Travel (X-Axis)
800 mm

Max Distance from Spindle Nose to Table
420 mm

Cross Travel (Y-Axis)
250 mm

Swivel Table
±45 Degree

Vertical Travel (Z-Axis)
350 mm

Width of T-Slots
16 mm

Stanko 1100 mm x 250 mm Universal Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Stanko 1100 mm x 250 mm Universal Milling Machine

Make - Stanko (Russia)

Model - 6H81

Table Size - 1100 mm x 250 mm

XYZ Travel - 625 mm x 180 mm x 350 mm

Spindle Speeds - 65 rpm to 1800 rpm

Spindle Taper - ISO 40

Table Travel Feed Rates - 35 mm/min to 1020 mm/min

Table Rotation - +45 degree to -45 degree

- Machine is in excellent working condition.

Video of The Machine

https://youtu.be/MTZ4skS4fVg

Versatility for Diverse Applications

The Stanko Universal Milling Machine is engineered to accommodate a broad array of metalworking tasks. Its ability to operate both horizontally and vertically, along with a high table load capacity, makes it perfect for workshops requiring flexibility and adaptability in machining operations. Adjustable spindle speeds and a swiveling table enhance its suitability for intricate and large-scale work.

Built for Precision and Durability

Crafted with a robust cast iron body and precise steel components, this model ensures stable machining and extended equipment life. Its centralized lubrication and powerful 3.7 kW main motor help achieve smooth, reliable performance, even during prolonged heavy-duty cycles. Its sturdy structure supports accurate results in every pass.

FAQs of Stanko 1100 mm x 250 mm Universal Milling Machine:

Q: How do I operate the Stanko 1100x250 Universal Milling Machine for both horizontal and vertical milling?

A: The machine is designed for easy manual control, allowing you to switch between horizontal and vertical rotation by adjusting the spindle and table positioning mechanisms. The swiveled table (45) and manual control system enable efficient transitions between operations for precision machining.

Q: What workpiece capacities and applications is this milling machine best suited for?

A: The Stanko 1100x250 is ideal for engineering workshops and metalworking industries handling heavy-duty tasks. It can support workpieces up to 500 kg and is well-suited for precise shaping, slotting, drilling, and cutting of various metal materials, thanks to its robust build and variable spindle speeds.

Q: When should I use the automatic feed range, and how does it help?

A: The 22-step automatic feed range is advantageous when consistent feed rates are required during long or repetitive milling operations. This feature aids in achieving uniform cuts and high-quality surface finishes, reducing operator fatigue and ensuring precision across multiple passes.

Q: Where should the Stanko Universal Milling Machine be installed for optimal performance?

A: Install the machine in a well-ventilated, level, and stable industrial workshop environment. The required floor space is approximately 1850 mm x 1780 mm. Ensure that the area allows for safe movement and access during operation and maintenance.

Q: What process is involved in maintaining the centralized lubrication system?

A: Maintenance involves regularly checking lubrication levels, ensuring that the centralized system is delivering oil to all critical components, and inspecting for leaks. Scheduled maintenance maximizes the machines performance and prolongs its service life.

Q: How does the coolant system enhance the milling process?

A: The integrated coolant system keeps working temperatures low, minimizes thermal expansion, and helps flush away chips, contributing to a smoother surface finish and prolonging tool life. It is especially beneficial during intensive or prolonged milling sessions.

Q: What are the overall benefits of using this universal milling machine?

A: Key benefits include high versatility, robust construction, precise machining, easy manual operation, and the ability to handle heavy-duty workloads. These features make it a cost-effective solution for businesses seeking reliability and adaptability in various metalworking projects.
